VC-HS III
Studio Flash
Thank you for selecting this professional flash unit .
Please read these instruction carefully and keep them handy for your reference .
VCHH II series of flash light is powerful, flexible in positioning and ease of use,
meets the standards demanded in professional studios today .
Please ensure that you are completely familiar with the operations and features of
your new flash before using it .
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VISICO Excel Series
Summary of Contents for VISICO Excel Series
- Page 1 VC-HS III Studio Flash Thank you for selecting this professional flash unit . Please read these instruction carefully and keep them handy for your reference . VCHH II series of flash light is powerful, flexible in positioning and ease of use, meets the standards demanded in professional studios today .
- Page 2 Table of Contents 1/Safety notes When using this photo flash unit, basic safety precautions should always Description Page be followed, including the following: Safety Notes 1. Read and understand all instructions before using. 2. Close supervision is necessary when any appliance is used by or near Content of Carton children.
- Page 3 5/Prepare Flash for Use 3/Name of Parts A. Photocell 5-1 Fix flash on Light stand B. Handle Select a light stand or support system of suitable weight and dimensions C. LCD screen to ensure stable operation of the unit. Rotating “Light Stand Locking knob” D.
- Page 4 5-3 Install Standard Reflector 7/ Operating Modeling Lamp Install standard reflector where the protective cap was before. Align the Shortly press [MODEL] button, brightness three pegs on the reflector with the three slots, press the reflector in and of modeling lamp varies in sequence rotate clockwise until it locks in place(Figure 2a &...
- Page 5 12/ Wireless Radio Trigger The flash unit has 2.4G build-in radio receiver module, enable the flash to be triggered by VISICO transmitter (VC-816TX, VC-16TX, VC-801TX, VC-818TX, VC-818TX II and VC-818S). Transmitter doesn't include in the package, please purchase separately.
- Page 6 Note: 14 Flash Mode-Multi Stroboscopic Flash Use stroboscopic flash in a dark environment is more effective. According to one shutter signal, the flash will generate a series of fast Maximum output power of stroboscopic flash is 4.0. flashes, and multiply images will be integrated in one picture. It is useful to capture trajectory of a moving object.
- Page 7 17/Changing the Flash Tube 16/Use of Umbrellas and Softboxes Discharge the flash Unit An umbrella with a handle diameter of 8-10mm can be firmly secured The energy in the flash unit must be discharged before removing the flash tube. To discharge the Flash unit: in the umbrella holder.
- Page 8 20/Best Practices 18/ Changing the Fuse As with any flash units, the useful life of the flash tube and the unit as A fuse is mounted on the rear panel protects the circuitry of the flash unit. a whole depends on the way it is used. Avoiding excessive heat is the Turn off the studio flash, and disconnect the power supply before key to long life.
- Page 9 Beep Bowens mount 23/ USB Firmware Update Overheating protection 1）Visit VISICO official website (www.visico.com) to download the firmware upgrading drive and the firmware of the latest version. Flash tube Plug in tube (user replaceable) 2）Turn off the power, and press and hold [MODE] button, meanwhile,...
