VC-HH II
Thank you for selecting this professional flash unit .
Please read these instruction carefully and keep them handy for your reference .
VCHH II series of flash light is powerful, flexible in positioning and ease of use,
meets the standards demanded in professional studios today .
Please ensure that you are completely familiar with the operations and features of
your new flash before using it .
Advertisement
Related Manuals for VISICO Excel Series
Summary of Contents for VISICO Excel Series
- Page 1 VC-HH II Thank you for selecting this professional flash unit . Please read these instruction carefully and keep them handy for your reference . VCHH II series of flash light is powerful, flexible in positioning and ease of use, meets the standards demanded in professional studios today . Please ensure that you are completely familiar with the operations and features of your new flash before using it .
- Page 2 1/Safety notes Table of Contents Do not use your flash in an environment where moisture or flammable vapor is likely to come in contact with the unit. Page Description A fire hazard exists if flammable materials are placed in close proximity to either the flash tube or modeling lamp when the units is in use.
- Page 3 3/Name of Parts 5/Button Function A. Photocell Operation Button Function B. Handle Press Turn on and off optical slave C. LCD screen SLAVE D. Operation button Press and hold 3 Set preflash, channel, SLAVE E. Regulator seconds group F. Main power switch Press TEST Trigger the flash...
- Page 4 6-3 Install Standard Reflector 8/Sync cord connection Install standard reflector where the protective cap was before .Align the The "Sync Cord Input" on the flash may be used for direct connection three pegs on the reflector with the three slots ,press the reflector in and to a camera set to synchronization by a sync cord.
- Page 5 The flash unit has 2.4G build-in radio receiver module, enable the flash 1 time ,2 times,3 times ,4 times ,5 times and 6 times. Pressing [SLAVE] to be triggered by VISICO transmitter VC-816TXVC-801TXVC-16TX button 3 seconds to enter into preflashes setup "C".
- Page 6 13-2 Setting Group 15/ Use of Umbrella Set the flash into different groups so that An umbrella with a handle diameter of 8-10mm can be firmly secured in the transmitter VC-801TX and VC-818TX the umbrella holder. Firmly press the umbrella shaft through the holder . can control output power of every group The locking knob is located on the side.
- Page 7 18/ Changing Fuse 17/ Changing the Flash Tube A fuse is mounted on the rear panel protects the circuitry of the flash unit. 17-1 Discharge the flash Unit Turn off the studio flash and disconnect the power supply before changing The energy in the flash unit must be discharged before removing the flash tube.
- Page 8 The fast recycling feature allows a rapid sequence of high power flashes E2: This is error code can display after a long shooting session at high to be obtained. However this feature should be used sparingly since output or rapid sequence ,turn OFF the flash and allow it to rest 30 minutes. continuous rapid flashing can cause overheating and subsequent damage E3:This error code will display when the internal voltage of the flash is too to the flash tube and possibly the internal electronics.
- Page 9 VC-300HHII VC-400HHII VC-500HHII VC-600HHII VC-1000HHII Model Color 5600K±200K Temperature Flash Tube "plug-in" Tube (User replaceable) Triggering Voltage Cooling Fan Auto Power Dump Overvoltage/ overheating protection Acessories AC190-240V/50~60Hz or AC 100-130V/50~60Hz Included 3.3kg Weight 2.5kg 2.8kg Dimensions 30×13×13 32×13×13 38×13×13 Dimensions (cm) (without reflector) (without reflector) (without reflector)
