- Page 1 SV10-AIR FOX Operations Manual U1/ 5-7 Boeing Place - Caboolture - QLD 4510 - Australia +61 456 000 665 / info@solidsvac.com / www.solidsvac.com...
-
Page 2: Table Of Contents
CONTENTS Page Description Safety First 1. Operation Overview 2. Technical Data 3. Pump Set-Up 4. Operation 5. Maintenance 6. Job Safety Analysis Scan this QR Code for an electronic version of this Operations Manual... -
Page 3: Safety First
The operator MUST ensure that an appropriate and adequate air supply is available depending on the model and Jet Pack in use. All Solidsvac Pumps require a minimum operating pressure of 500kPa and have a maximum operating pressure of 720kPa (105psi). -
Page 4: Technical Data
36” Width 200 mm 22” Diameter 1000 mm 40” Weight 15 kg 99 lb Air inlet 13 mm 1/2” BSP Suction inlet 50 mm 2” Discharge outlet 25 mm 1” telephone +61 456 000 665 email info@solidsvac.com www.solidsvac.com page 4... -
Page 5: Pump Set-Up
Before commencing operation, Solidsvac strongly recommends each user reads the Operation Manual supplied with each unit and available on line or via the QR code on pump. Note: No training is necessary to operate the SV10-AIR FOX however understanding the Operations Manual is essential to safe practice. - Page 6 Solidsvac recommends the hoses (Air Supply, Discharge) used in operation with the SV10-AIR FOX are to be made of anti-static material. If the hoses used in operation with the SV10-AIR FOX are not made of anti-static material, they MUST be braided to comply with requirements for Fire Resistance &...
-
Page 7: Operation
SOLIDSVAC recommends checking the pump discharge to ensure it remains correctly anchored at the exit. -
Page 8: Maintenance
5. MAINTENANCE In use, the Solidsvac SV10-AIR FOX requires little to no maintenance, however Solidsvac recommends that the following strict measures are taken to ensure pump remains in good working order. Maintenance, repairs, and the disassembling of the unit can be carried out by any qualified Fitter with a basic knowledge of pneumatics. - Page 9 SYSTEM TESTING PROCEDURES Pneumatic systems, like all machines, require routine maintenance to ensure reliability. However, there are still times when problems occur and MUST be located quickly and efficiently, especially in production applications. A step-by-step method has been devised as a way of finding and solving pneumatic problems quickly.
- Page 10 SYSTEM MAINTENANCE A pneumatic system is easy to maintain. However, like any other mechanism, it MUST be operated and maintained correctly. Pneumatic systems can be damaged by excessive pressures, fluid contamination and by high operating temperatures. Regular maintenance will reduce your pneumatic troubles. By using a regular maintenance programm(preventative maintenance) to care for a system, you can eliminate common problems and anticipate special ones.
- Page 11 PUMP PREVENTATIVE MAINTENANCE PROGRAM The following is the work to be performed to a SV10-AIR FOX Pump during Preventative Maintenance Check. All items, except annual checks (Tradesman), are to be carried out by a Competent Operator. Lock and tag out equipment...
- Page 12 Check airlines and Inspect airlines for any deterioration, check fittings for fittings cracks and leaking. Check bolts Check and secure all clamps and bolts. Conduct a full service on the pump Check control system www.solidsvac.com...
-
Page 13: Job Safety Analysis
JOB SAFETY ANALYSIS Note: It is recommended that a site-specific JSA is conducted prior to operation of the unit. - Page 14 SOLIDSVAC SV10-AIR FOX Date Of Audit – June 2020. Equipment/Task: Set-up and operate Solidsvac Solids/Slurry Pump. Note: Site Safety requirements MUST be adhered to at all times. Personal Protective Equipment including approved safety eyewear and hearing protection are to be worn at all times whilst operating this equipment.
- Page 15 SOLIDSVAC SV10-AIR FOX Date Of Audit – June 2020. Equipment/Task: Set-up and operate Solidsvac Solids/Slurry Pump. Note: Site Safety requirements MUST be adhered to at all times. Personal Protective Equipment including approved safety eyewear and hearing protection are to be worn at all times whilst operating this equipment.
- Page 16 Model Number Serial Number Date of Manufacture Inspected by U1/ 5-7 Boeing Place - Caboolture - QLD 4510 - Australia +61 456 000 665 / info@solidsvac.com www.solidsvac.com...
