- Page 1 SOLIDS PUMPING SYSTEMS SV200-SPDK-CF Operations Manual 201 First Avenue - Bribie Island - QLD 4507 - Australia +61 456 000 665 / info@solidsvac.com / www.solidsvac.com ISSUED DATE - 140421 V 1.2 LAST REVISED - 140421...
-
Page 2: Table Of Contents
2. Design Registration 3. Technical Data 4. Accessories 5. Pump Set-Up 6. Operation 7. Maintenance 8. Adjusting the LOAD and DISCHARGE cycles 9. SV200-SPDK-CF Schematic 10. Main Components 11. Notes Scan this QR Code for an electronic version of this Operations Manual... -
Page 3: Safety First
This manual contains important information concerning the installation, operation and maintenance of the Solidsvac Pump, Model SV200-SPDK-CF. To prevent injury to personnel or equipment damage, this manual should be read and understood by those responsible for the installation, operation and maintenance of the equipment. -
Page 4: Technical Data
Delivery to skip or conveyor. Tool Kit - Contains all you need for basic maintenance on your pump. Service Kit - Contains all you need for basic maintenance on your pump. telephone +61 456 000 665 email info@solidsvac.com page 4... -
Page 5: Pump Set-Up
*Always position hoses out of walkways where possible. 3) E nsure the main air valve is in the off position and attach the 51 mm (2”) air hose to the Solidsvac Pump and fit appropriate safety clips. 4) The pump is now ready for use. CAUTION: Solidsvac recommends that the SV200-SPDK-CF unit, should be operated firstly in the Manual setting. Manual operation will ensure safe & correct timing cycles are achieved. 6. OPERATION SAFETY FIRST Turn the air supply valve on at the source followed by the valve on the pump. -
Page 6: Maintenance
7. MAINTENANCE In use, the Solidsvac SV200-SPDK-CF requires no maintenance. However the following procedures are recommended in the event of any loss of vacuum when operating in either in-line or ETA (Exhaust to Atmosphere) mode. Prior to commencing each pumping operation: - Check that all fittings and connections are serviceable. Inspect exhaust box to ensure it is free from any carry-over material. -
Page 7: Adjusting The Load And Discharge Cycles
Note: Numbers found on cycle timers are a guide only. Pressure Relief Valve Cycle Control Timers SAFETY FIRST PRIOR TO COMMENCING ANY WORK ON THE UNIT, THE AIR SUPPLY VALVE MUST BE ISOLATED AND THE CONTROL SYSTEM TESTED DEAD www.solidsvac.com page 7... -
Page 8: Sv200-Spdk-Cf Schematic
10. MAIN COMPONENTS Exhaust Box Discharge Suction Control Box Air Supply Fork Skids telephone +61 456 000 665 email info@solidsvac.com page 8... -
Page 9: Notes
10. NOTES www.solidsvac.com page 9... - Page 10 Model Number Serial Number Date of Manufacture Inspected by 201 First Avenue - Bribie Island - QLD 4507 - Australia +61 456 000 665 / info@solidsvac.com www.solidsvac.com...
