- Page 1 SOLIDS PUMPING SYSTEMS Solidsvac Pumps SV20-SP Operations Manual Version 1 - Doc.SV20SP-13122018 201 First Avenue - Bribie Island - QLD 4507 - Australia +61 456 000 665 / sales@solidsvac.com / www.solidsvac.com...
-
Page 2: Table Of Contents
CONTENTS Description Page Safety First Operational Overview Design Registration Technical Data Schematic Accessories Pump Set-up Operation Maintenance Adjusting the LOAD and DISCHARGE cycles Main Components WARNING Compressed air can be dangerous. Correctly rated hoses and piping should be used in conjunction with the appropriate fittings and safety devices on all connections. -
Page 3: Safety First
This manual contains important information concerning the installation, operation and maintenance of the Solidsvac Pump, Model SV20-SP. To prevent injury to personnel or equipment damage, this manual should be read and understood by those responsible for the installation, operation and maintenance of the equipment. -
Page 4: Technical Data
Maximum solids 35 mm 1-1/2” Measured water throughput 200 lpm 53 gpm • Vessel and valves manufactured in 316 stainless steel • Individually adjustable load and discharge cycles 4. SV20-SP Schematic AIR SUPPLY SOLENOID ACTUATOR VENTURI VALVE DISC LOAD LOAD TIMERS... -
Page 5: Accessories
*Always position hoses out of walkways where possible Ensure the main air valve is in the off position and attach the 18 mm (3/4”) air hose to the Solidsvac Pump and fit appropriate safety clips. -
Page 6: Operation
Operation is automatic and the pump can be left running unattended indefinitely. NOTE: The Solidsvac Pump certified lifting point should be used as the units Earthing Point if required. Solidsvac Pumps recommend checking the pump out-line to ensure it remains correctly anchored at the exit. -
Page 7: Adjusting The Load And Discharge Cycles
Caution: It is recommended that only a quarter turn adjustment is made at a time. Cycle Control Timers Pressure Relief Valve SAFETY FIRST Isolate Air Supply Valve and have Air Supply Valve OFF before commencing any work on the unit REPORT ANY DEFECTS IMMEDIATELY telephone +61 456 000 665 email sales@solidsvac.com page 7... -
Page 8: Main Components
10. Main Components AIR SUPPLY EXHAUST DISCHARGE SUCTION www.solidsvac.com page 8... - Page 10 Model Number Serial Number Date of Manufacture Inspected by 201 First Avenue - Bribie Island - QLD 4507 - Australia +61 456 000 665 | sales@solidsvac.com www.solidsvac.com...
