The recommended installation height is 1.3-1.5 meters above the oor. Install
the keypad on a at, vertical surface. This allows KeyPad TouchScreen to be
rmly attached to the surface and to avoid false tamper triggering.

Signal strength

The Jeweller and Wings signal strength is determined by the number of
undelivered or corrupted data packages over a certain period of time. The icon
on the Devices tab indicates the signal strength:
Three bars — excellent signal strength.
Two bars — good signal strength.
One bar — low signal strength, stable operation is not guaranteed.
Crossed out icon — no signal.
Check the Jeweller and Wings signal strength before nal installation. With a signal
strength of one or zero bars, we do not guarantee stable operation of the device.
Consider to relocate the device as repositioning even by 20 cm can signi cantly improve
the signal strength. If there is still poor or unstable signal after the relocation, use
radio signal range extender. KeyPad TouchScreen is incompatible with ReX radio signal
range extenders.
Do not install the keypad
1. Outdoors. This can lead to keypad failure.
2. In places where parts of clothing (for example, next to the hanger), power
cables or Ethernet wire may obstruct the keypad. This can lead to false
triggering of the keypad.
3. Nearby any metal objects or mirrors causing attenuation and screening of
the signal.
4. Inside premises with temperature and humidity outside the permissible
limits. This could damage the keypad.
5. Closer than 1 meter from the hub or radio signal range extender. This can
lead to a loss of communication with the keypad.
ReX 2
