Control Pro 350 Extra Cart
minutes. Eliminate the cause of heating, e.g. slots for air intake covered.
1 Hose holder
3 Telescopic handle
5 Pressure regulator with integrated ON/OFF switch
7 Selector switch
9 Pressure gauge
11 Return hose
13 Operating instructions
15 Gun extension (30 cm)
17 Nozzle 515 (for thick materials, e.g. interior wall paints)
19 HEA Filter Set
21 Nozzle 311 (for thin materials, e.g. lacquers)
* pre-installed in the filter housing
Coating Materials Suitable for Use
Dispersion and latex paints for interior use.
Water-based and solvent-containing lacquers and glazes. Paints, oils, release agents, synthetic enamels, PVC lacquers, undercoats,
base coats, fillers and anti-rust paints.
Another nozzle size and gun filter must be used, depending on the material to be processed.
i
Thin materials:
Thick materials:

Coating Materials Not Suitable for Use

Materials that contain highly abrasive components, facade paint, caustic solutions and acidic coating substances.
Flammable materials, materials containing acetone or cellulose thinner
In order to ensure compatibility of the coating substance with the materials used to manufacture the device, please
i
contact Wagner Service in cases of doubt.

Field of application

Coating interior walls and outside objects (e.g. garden fences, garage doors, etc.).
Required tools and auxiliary material
•
Wrench (13, 16, 17, 20) and/or adjustable wrench (2 pcs.) and hex key (10 mm)
•
Hex key (2.5 mm)
•
Empty container
•
A large piece of cardboard
•
Covering material

Preparation of the workplace

Sockets and plugs must be masked. Risk of an electric shock as a consequence of sprayed material entering the
socket!
Mask all the areas and objects that are not to be spray painted, or remove them from the work area.
No liability is assumed for damage due to overspray.
Silicate paint corrodes glass and ceramic surfaces upon contact! All such surfaces must therefore be completely
Danger
covered.
Nozzle 311

Nozzle 515/619

Description (Fig. 1)
2 Inlet valve pusher
4 Integrated toolbox for nozzles and small parts
6 Hose connection
8 Holder for paint container
10 Suction hose
12 Inlet filter
14 High-pressure hose
16 Spray Gun
18 Nozzle holder
20 Gun filter: red (1 pc.), white (1 pc.*)
22 Nozzle 619 (for thick materials, e.g. interior wall paints. For
coating larger surfaces)
Filter red
Filter white
GB
21
