- Page 1 HIGH EFFICIENCY AIRLESS CONTROL PRO 350 EXTRA SKID ORIGINAL- BETRIEBSANLEITUNG wagner-group.com...
- Page 2 Control Pro 350 Extra Skid HIGH EFFICIENCY AIRLESS CONTROL PRO 100 BETRIEBSANLEITUNG wagner-group.com...
- Page 3 Control Pro 350 Extra Skid SPRAY PRIME 0 = OFF PRIME SPRAY...
- Page 4 Control Pro 350 Extra Skid 20 - 25 cm 20 - 25 cm 20 - 25 cm 20 - 25cm...
- Page 5 Control Pro 350 Extra Skid HOUSEHOLD...
- Page 6 Control Pro 350 Extra Skid Translation of the original operating instructions Warning! Attention: Danger of injury by injection! Airless units develop extremely high spraying pressures. Danger Never put your fingers, hands or any other parts of the body into the spray jet! Never point the spray gun at yourself, other persons or animals.
-
Page 7: Explanation Of Symbols Used
Control Pro 350 Extra Skid Congratulations on your purchase of a WAGNER colour application device. You have purchased a proprietary device that requires careful cleaning and care to ensure trouble-free functioning. Read the operating instructions carefully before using the tool and observe the safety instructions. Keep the operating instructions in a safe place. -
Page 8: Flammable Materials
Control Pro 350 Extra Skid 3. Safety of Persons a) Be attentive. Pay attention to what you are doing and work sensibly with a power tool. Do not use the tool if you are tired or under the influence of drugs, alcohol or medication. Just a moment of inattentiveness while using the tool can lead to serious injuries. -
Page 9: Explosion Protection
Control Pro 350 Extra Skid Explosion protection Do not use the unit in work places which are covered to the explosion protection regulations. Danger Danger of explosion and fire through sources of flame during spraying work There may be no sources of flame such as, for example, open fires, smoking of cigarettes, cigars or tobacco pipes, sparks, glowing wires, hot surfaces, etc. - Page 10 197 kΩ/m (60 kΩ/ft.). For reasons of function, safety and durability, only use genuine WAGNER high-pressure hoses and spray nozzles. For overview see „Spare parts lists“.
-
Page 11: Coating Materials Not Suitable For Use
Flammable materials, materials containing acetone or cellulose thinner In order to ensure compatibility of the coating substance with the materials used to manufacture the device, please contact Wagner Service in cases of doubt. Field of application Coating interior walls and outside objects (e.g. garden fences, garage doors, etc.). -
Page 12: Preparation Of The Coating Material
Control Pro 350 Extra Skid Preparation of the Coating Material Using Control Pro 350 Extra interior wall paints, varnishes and glazes can be applied by spraying without diluting them, or by diluting them slightly. Detailed information is available in the technical data sheet of the manufacturer ( Internet download). -
Page 13: Pressure Relief Procedure
Control Pro 350 Extra Skid Pressure Relief Procedure Be sure to follow the Pressure Relief Procedure when shutting the unit off for any purpose. This procedure relieves the pressure from the spray hose and the gun. Watch the pressure gauge ––> 0 bar Danger Secure the spray gun. -
Page 14: Spray Technique
Control Pro 350 Extra Skid Spray Technique Be sure to follow the Pressure Relief Procedure when shutting the unit off for any purpose. This procedure relieves the pressure from the spray hose and the gun. Watch the pressure gauge ––> 0 bar Danger Be sure that the paint hose is free of kinks and clear of objects with sharp cutting edges. -
Page 15: Interruption Of Work
Control Pro 350 Extra Skid HEA Filter Set Assembly The gun and high-pressure hose must be de-pressurised before the filter set is installed / removed. Danger 1. Disconnect the high-pressure hose from the gun (1). 2. If necessary, screw on the filter housing (2) and insert a filter (3) appropriate to the nozzle (the conical side (A) must point upwards). -
Page 16: Maintenance And Repairs
Control Pro 350 Extra Skid 11. Switch the device off and remove the power plug. 12. Turn the switch into the PRIME position (vertical). 13. Pull the trigger to relieve the pressure. 14. Secure the spray gun. 15. Separate the spray gun from the paint hose using wrenches (13). - Page 17 Gun extension (30 cm) 0517700 Gun extension (60 cm) 0517701 Easy Glide (118 ml) 0508619 Further information about the WAGNER range of products for renovating is available under www.wagner-group.com Technical Data Pump type Piston pump Power source 230 V 50 Hz/ 240 V...
-
Page 18: Environmental Protection
Control Pro 350 Extra Skid Information about the oscillation level The specified oscillation level has been measured according to a standard test procedure and can be used to compare against electric tools. The oscillation level is also for determining an initial assessment of the vibrational strain. - Page 19 Control Pro 350 Extra Skid Problem Cause Remedy • The paint pattern is The paint is too viscous or contaminated. ➞ Thin or strain the paint. • tailing. The spray nozzle is plugged. ➞ Clean the spray nozzle and use the HEA filter set.
- Page 20 If the check shows that the case is not a guarantee case, repairs are carried out at the expense of the buyer. Claims against Wagner that are based on or caused by the failure or insufficiency of a unit cannot be asserted.
