- Page 1 MRT 50 EURO 4 MANUEL DE PROPRIEÉTAIRE OWNER’S MANUAL MANUAL DEL PROPIETARIO...
- Page 3 RIEJU S.A. is grateful for the confidence you have put in their company and would like to congratulate you on your choice of motorbike. The MRT 50 EURO 4 are the resulted of the long-term experience that RIEJU has had in competitions, which has led to the development of a high performance vehicle.
-
Page 4: Table Of Contents
CLUTCH LEVER Temperature warning lamp FRONT BRAKE LEVER Headlight Main beam warning light REAR BRAKE PEDAL Direction indicator warning lamp GEAR BOX PEDAL Engine warning lamp PETROL TANK INSTRUMENT DESCRIPTION PETROL TAP ADJUST BUTTON FUNCTION INSTRUCTION MRT 50 EURO 4... - Page 5 AIR FILTER WHEEL DIAMETER AND PULSES CLEANING AND STORAGE CLOCK SETTINGS CLEANING MOTORBIKE OPERATION LONG-TIME STORAGE STARTING AND RIDING CHECKS BEFORE USING MOTORCYCLE RUNNING IN TECHNICAL SPECIFICATIONS & CHARACTERISTICS 44 ACCELERATION MAINTENANCE TO BRAKE (SLOWING DOWN) STOPPING MRT 50 EURO 4...
-
Page 6: Motorbike Description
PRO models it is anchored to a progressive articulated rod system (Progressive Racing System - PRS) which provides great operational smoothness with variable transmission also incorporate a gas shock absorber. The front and rear brakes use a disc made of stainless steel and radial callipers. MRT 50 EURO 4... -
Page 7: Delivery Of The Motorcycle
WARRANTY REGISTRATION – complete the necessary information, pass a copy to the owner, and return a copy immediately to your RIEJU distributor. OPERATION - Explain the functions & correct handling of the motorcycle. WARNINGS - Explain the importance of warning labels to ensure a long life of the motorcycle. - Page 8 GEAR LEVER ADJUSTMENT- Adjust to the correct height for the user. WARNING: Changes on the bike don’t authorized by RIEJU, or use of parts that don’t are ORIGINAL SPARE PARTS from RIEJU on the warranty period. Release RIEJU from any responsibility on the damages produce on the bike and cancel the warranty.
-
Page 9: Identification Of The Motorbike
Rieju spare parts. ENGINE IDENTIFICATION NUMBER The engine serial number is located on the top, left side bottom of the left crankcase. The engine number will serve as a reference when requesting spare parts from the dealership. MRT 50 EURO 4... -
Page 10: Main Elements Of The Motorbike
NOTE: Note that the button always returns to the central position, to switch off the direction indicators push button. MRT 50 EURO 4... -
Page 11: Horn Button
When the motor is cold, the choke lever should be placed in the ON position. WARNING: Once the motor has reached it’s normal working temperature, return the choke lever go back to it’s original position, otherwise it could cause the motor to misfire. MRT 50 EURO 4... -
Page 12: Clutch Lever
The front brake lever is situated on the right-hand side of the handlebar. To activate the front brake, pull the lever towards the handlebar. REAR BRAKE PEDAL The rear brake pedal is on the right-hand side of the motorbike. To activate it, press downwards with the food. MRT 50 EURO 4... -
Page 13: Gear Box Pedal
The capacity of the tank is 6 liters. CAUTION: Use only Unleaded petrol E5, without oil, the use of another type of fuel can damage the engine and this damages will not be considered as warranty. MRT 50 EURO 4... -
Page 14: Petrol Tap
Fill the tank as soon as possible, then it is important to remember to turn the lever back to "ON“. TIP: Do not drive normally in RESERVE position as you could run out of petrol. MRT 50 EURO 4... -
Page 15: 2T Oil Tank
This damages will not be considered as warranty. TIP: Engine is optimized to use 2T semi-synthetic oil. RIEJU recommends use LIQUI MOLY MOTORBIKE 2T STREET. MRT 50 EURO 4... -
Page 16: Routine Testing
If there is air in the system the brakes will need to be bled. WARNING: Bled the baking system will do by one professional, Rieju recommend do this operation by your official RIEJU dealer. MRT 50 EURO 4... -
Page 17: Rear Brake
WARNING: Brake fluid is corrosive and will damage paintwork, if spilt wash off with water immediately. TIP: Always remember that the above must be carried out by a RIEJU official service. MRT 50 EURO 4... -
Page 18: Throttle Twist Grip
The grip should return to closed position when released. Lights, indicators and warning lamps Check operation of all lights, and direction indicators plus the oil warning lamp and petrol reserve panel lights. Replace bulbs as necessary. MRT 50 EURO 4... -
Page 19: Tyres
CAUTION: when the pressure is very high, the tyres can no longer absorb any shocks, transmitting any road sur- face defects directly to the chassis, handlebar and rider. MRT 50 EURO 4... -
Page 20: Instrument And Indicators
ATTENTION: Do not use the bike with this warning light on, as this may cause serious damage to the engine, consult your RIEJU dealer as soon as possible. MRT 50 EURO 4... -
Page 21: Headlight Main Beam Warning Light
ATTENTION: If the tank is not filled the engine could be seriously damaged, warranty it will avoid for damages produced for run the bike without mix oil. MRT 50 EURO 4... -
Page 22: Instrument Description
Display range 0-9999,9 Km (mile) 3 seconds in Trip A/B screen to reset. o Display Unit 0,1 Km (mile) o Press and hold the Adjust button for 3 seconds in Hour metter A/B screen to reset MRT 50 EURO 4... -
Page 23: Adjust Button Function Instruction
Hold pressing the Adjust button for 3 seconds to reset the “TRIP A”. Press the Adjust button to switch from “TRIP A” to “TRIP B”. Hold pressing the Adjust button for 3 seconds to reset the “TRIP B”. MRT 50 EURO 4... -
Page 24: Total Hour
Press the Adjust button to switch from hour meter A to hour meter B. Press and hold the Adjust button for 3 seconds to reset the hour meter A. Press the Adjust button to switch from hour meter B to back to the main screen. MRT 50 EURO 4... -
Page 25: Select Button Function Instruction
12/24 hour mode. If 24 hour mode is chosen then the AM/PM symbol will not be displayed STOPWATCH: Press the Select button during main screen to switch from Clock to Stopwatch. Press and hold the Select button for 1 seconds to reset the Stopwatch MRT 50 EURO 4... -
Page 26: Speed Record
Press and hold the Select button for 3 seconds to reset the Speed Record. Average speed and the Max speed display in the 3 seconds rotation. Press the Select button to switch from Speed Record back to main screen. MRT 50 EURO 4... -
Page 27: To Enter The Setting Mode
Adjust Button for tree times to enter the sensing point setting. Press the Select button to move to the digit you want to set. Press Adjust button to go back to tire circumferences value & sensing point setting screen. MRT 50 EURO 4... -
Page 28: Wheel Diameter And Pulses
DIAMETER PULSES Off-road 2100 Super 2030 Motard ATTENTION: Put different values as indicates will produce that the speed show by the dashboard it will incorrect, any consequence produce by this issue iwill not a RIEJU responsability. MRT 50 EURO 4... -
Page 29: Clock Settings
Press the Select button to enter the clock (Hour) setting. Press the Select button to choose the hour/minute you want to set. Press Adjust button to get back to Clock setting screen. ATTENTION: Other functions are the factory settings should not be changed. MRT 50 EURO 4... -
Page 30: Motorbike Operation
(OUT) and ride away. Do not accelerate too much until the motor is warm enough ATTENTION: Before riding the motor should be warm, never accelerate or ride hard when the motor is cold. This will prevent premature damage to your engine. MRT 50 EURO 4... -
Page 31: Running In
ATTENTION: As indicate on the Service Manual you must done the firts Service at 500 Km in your Official rieju Workshop. Is essential done the services indicates on the Service Manual and equire the signature and stamp of the Workshop at time to pick up the bike. Don’t make the service as the Km indicates is reason for loss the vehicle warranty. -
Page 32: To Brake (Slowing Down)
Gear changing should be done carefully to ensure the gear you want is selected before releasing the clutch. MRT 50 EURO 4... -
Page 33: Carburettor
…for everyday adventure CARBURETTOR The carburettor provides the correct petrol air mixture to the engine. It the settings are tampered with poor performance and/or overheating may occur. If you have any problems please refer to your RIEJU dealer. MRT 50 EURO 4... -
Page 34: Front Suspension
• Pro models assembly upside down fork of Ø40 or Ø41 mm. • Basic models assembly on standard for of Ø37 mm. REAR SUSPENSION The rear suspension consists of a hydraulic monoshock absorber, on PRO models with separate gas reservoir and progressive articulated rod system (PRS). MRT 50 EURO 4... -
Page 35: Cooling System
Use only anti-freeze liquid. In this way we can avoid the water freezing causing damage to the water pump and water pipe ruptures. Do not top up with tap water as the calcium content could damage the radiator. MRT 50 EURO 4... -
Page 36: Spark Plug Check
Screw the spark plug in by hand, trying to make sure that it is not cross threaded finally tighten with the correct tool. MRT 50 EURO 4... -
Page 37: Checking & Filling The Engine Oil Level
10W/30, with a total gearbox capacity of 820c.c. WARNING: Change the oil will done with a specialist and do the correct treatment of the oil used according environmental laws. ADVICE: RIEJU recommend do the change of oil in a official RIEJU dealer. MRT 50 EURO 4... -
Page 38: Chain Adjustment And Tension
To do so use the rule marks on of the swing arm. 5 - Set the position using the 2 nuts (B) and tighten the nut (A) that secures the rear wheel axle MRT 50 EURO 4... -
Page 39: Air Filter
In order to access the air filter, disassemble the mortorbike seat, allowing free access to the filter box. Remove the cover, which is attached to the box by a screw (A), and remove the filter housing. MRT 50 EURO 4... - Page 40 After removal, check to see if the foam filter is blocked, in which case wash with specific product to clean foam filter, apply some air filter foam oil, Rieju suggest use LIQUI MOLY FOAM FILTER OIL, then squeeze the filter material between your hands to remove surplus oil.
-
Page 41: Cleaning And Storage
4- Remove the degreasing agent along with the dirt using a low pressure water source such as a hosepipe. ATTENTION: Rieju accepts no responsibility for the use of degreasing agents which stain and/or cause deterioration to the motorbikes components. Rieju accepts no responsibility for any possible damage resulting from the use of pressurized water to clean the motorbike. -
Page 42: Long-Time Storage
2- Lubricate all control cables. 3- Seal the exhaust pipe to prevent the entry of any moisture. 4- Remove the battery and charge at least once a month, be careful to ensure the battery is stored in the correct conditions. MRT 50 EURO 4... -
Page 43: Checks Before Using Motorcycle
Tension and condition of chain and sprocket Lubricate ATENCIÓN: Each time the vehicle is used, it should be checked as above. If during these checks any abnormality is established, it should be repaired before using the motorcycle. MRT 50 EURO 4... -
Page 44: Technical Specifications & Characteristics
Type 2 stroke water cooled Engine capacity 50 cm Model cylinders 1 inclined forwards Piston size 40,3 x39,0mm Compression ratio 12,0:1 Starting system Kick start PETROL Type Unleaded petrol FILTER Type Foam OIL PUMP Type Mechanic MRT 50 EURO 4... - Page 45 LIQUI MOLY MOTORBIKE GEAR OIL 10W-30 Quantity 820 cc SPARK PLUG Type NGK BR 9 ES Electrode Clearance 0,6-0,7mm WATER PUMP Type Mechanical Advice: Contact your authorized RIEJU workshop in case of any problem or breakdown of the vehicle. MRT 50 EURO 4...
-
Page 46: Maintenance
CL & L CL & L CL & L CL & L Inspect and adjust carburettor Inspect and adjust the sparkplug Inspect all nuts and bolts for the chassis and plastics C:CONTROL; R: REPLACEMENT; L:LUBRICATION; L=CLEANING MRT 50 EURO 4... - Page 47 Check the electrical System Inspect radiator liquid levels Inspect exhaust system Check oil pump operation Tyre C:CONTROL; R: REPLACEMENT; L:LUBRICATION; L=CLEANING CAUTION: Maintenance schedule can change on function of the bike use, conduction, environmental conditions, etc… MRT 50 EURO 4...
