- Page 1 OWNER’S MANUAL MANUEL DU PROPRIÉTAIRE MANUAL DEL PROPIETARIO...
- Page 3 …for everyday adventure RIEJU S.A. is grateful for the confidence you have put in their company and would like to congratulate you on your choice of motorbike. are the resulted of the long-term experience that RIEJU has had in competitions, which has led to the development of a high performance vehicle.
- Page 4 …for everyday adventure The illustrations are for demonstration purposes only. They may not reflect the exact appearance of the actual product. Specifications are subject to change. Please read and understand the entire manual before allowing children to use this product! Carefully read the instruction manual, thoroughly inspect all parts to ensure the child's riding safety, and contact the dealer immediately if any issues are found.
- Page 5 …for everyday adventure NOTES : • The bike should be stored in a dry and ventilated place. • Disassembly and replacement of parts by non-professionals are prohibited. The bike needs to be assembled and adjusted by adults, and children are not allowed to operate it. •...
-
Page 6: Table Of Contents
…for everyday adventure CONTENTS PACKAGING DETAILS ROUTINE MAINTENANCE COMPLETE ASSEMBLY Electrical Component Maintenance Rear Shock Absorber Installation Brake Maintenance Instructions Front Shock Absorber Installation Mechanical Brake Maintenance Front Mudguard Installation Hydraulic Brake Maintenance Front Wheel Installation Transmission Maintenance Instructions Front Disc Brake Installation Suspension System Maintenance Instructions 17 Handlebar Installation Tire Maintenance Instructions... -
Page 7: Packaging Details
…for everyday adventure PACKAGING DETAILS Name Quantity Name Quantity Illustration 1 Complete Vehicle 1 Tool Kit 2 Tool Kit 3 Front Mudguard 4 Front Wheel 2 Front Mudguard Attachments (Front Wheel Axle, Front Mudguard, Installation Screws, Rear Shock Absorber Installation Screws) 6 Charger 3 Front Wheel 4 Attachments... -
Page 8: Complete Assembly
…for everyday adventure COMPLETE ASSEMBLY Rear Shock Absorber Installation Diagram Lift the rear of the bike. Align the lower end of the rear shock absorber with the mounting hole on the rear fork of the frame. Use a tool to tighten the rear shock absorber mounting bolt (10-12 Nm). -
Page 9: Front Mudguard Installation
…for everyday adventure COMPLETE ASSEMBLY Front Mudguard Installation Diagram Align the front mudguard limiter buckle towards the back and attach it to the lower fork board. Insert the limiter post of the front mudguard into Front Fender the inner limiter hole of the number plate. Use a tool to tighten the front mudguard screw into the lower fork board mounting hole (8-10 Nm). -
Page 10: Front Disc Brake Installation
…for everyday adventure COMPLETE ASSEMBLY Front Disc Brake Installation Diagram Remove the disc brake mounting screw from position ①. Rotate the disc brake to position ② and align the center hole. The disc brake caliper should align with the disc on the front wheel. Use the mounting screws to tighten the disc brake (8-10 Nm). -
Page 11: Brake Installation
Brake Installation Diagram Brake Cable Installation For model MX-12: Rotate the brake lever adjustment screw to align the opening with the cable outlet. Insert the brake cable head into the cable head seat of the brake lever. Pull the cable core into the brake lever outlet with a force. -
Page 12: Fastener Inspection
…for everyday adventure OPERATING INSTRUCTIONS Fastener Inspection Before using this vehicle, you should inspect all fasteners as shown in the diagrams to ensure they are not loose. This is essential to prevent any safety hazards due to loosened fasteners. Name Torque Value ①... -
Page 13: Speed Adjustment
…for everyday adventure OPERATING INSTRUCTIONS Speed Adjustment This series of products has two gear adjustment methods, which can be used for second or third gear speed regulation. Figure 1 shows the second gear speed regulation button, the switch is pressed to the "I" position for first gear, and the switch is pressed to the "O"... -
Page 14: Charging Instructions
…for everyday adventure OPERATING INSTRUCTIONS Charging Instructions To charge this product, connect the charger to the input end, then plug the input end into a household socket, and insert the output end into the charging port shown in the diagram to start charging the vehicle. Output end Input end Connecting part... -
Page 15: Usage Scenarios
…for everyday adventure USAGE SCENARIOS Usage Scenario Illustrations... -
Page 16: Routine Maintenance
…for everyday adventure ROUTINE MAINTENANCE Electrical Component Maintenance Instructions Lithium-ion batteries should be stored in a cool, dry, and ventilated environment, away from sources of fire and heat. The optimal storage temperature for batteries is 10-25°C, with the best humidity being 60±25%. Batteries should be stored at room temperature and charged to 20% to 40% of their capacity. -
Page 17: Hydraulic Brake Maintenance
…for everyday adventure ROUTINE MAINTENANCE Hydraulic Brake Maintenance Instructions When maintaining the brake, use a special tool to unscrew the disc brake lever oil filling port screw, and then inject oil into the oil pipe with a syringe to adjust the braking effect to an appropriate state; If the braking performance is still not ideal after oil injection, it is necessary to replace the disc brake pads to continue riding. -
Page 18: Tire Maintenance Instructions
…for everyday adventure ROUTINE MAINTENANCE Tire Maintenance Instructions Measure whether the tire pressure meets the tire label pressure; if not, adjust the pressure by inflating or deflating. After supplementing the pressure, ensure to put on the valve cap. Depending on the frequency of use, if the tire tread is severely worn, the tire needs to be replaced to continue riding. Whole Vehicle Appearance Maintenance Instructions After using the vehicle, first use a duster to remove surface dust, then wash with a water gun at low pressure, but was top to bottom and avoid important electrical parts such as the battery compartment, motor shaft, and... -
Page 19: Motor Troubleshooting
…for everyday adventure ROUTINE MAINTENANCE Motor Troubleshooting If there is not fault with the battery, display, or controller, and the motor operates normally when the throttle is turned, then motor is normal; if the motor does not turn, then is a fault with the motor. Controller Troubleshooting If there is not fault with the battery and the display, and the motor operates normally when the throttle is turned, then controller is normal;... -
Page 20: Cleaning And Storage
…for everyday adventure CLEANING AND STORAGE Cleaning the vehicle Regular and proper cleaning of your vehicle will extend its life of service Preparation • Wait until the motor cools down. • Close all covers and electrical connections to prevent from water. Do not use gasoline, rust remover, brake disc cleaner, etc. -
Page 21: Store The Vehicle For A Long Time
…for everyday adventure CLEANING AND STORAGE CAUTION: Salt is of extreme corrosion Therefore, these cleaning instructions shall be abided by: wait for the motor to be cooled, as well as use water and a mild detergent. Clean all metals and then treat parts with rust inhibiting spray, including inscriptions and nickel plated parts Clean the dirt with warm water, a mild detergent and a soft, clean sponge. -
Page 22: Short-Term Storage Of The Vehicle
…for everyday adventure CLEANING AND STORAGE CAUTION: Always keep the battery charged. Storing a depleted battery will cause permanent damage to the battery WARNING: If you are not familiar with the battery, please contact a specialist dealer. WARNING: To avoid over-discharge of the battery, it is recommended to charge and discharge the battery once every 3 months according to the standard charging and discharging method, and then charge the battery to 20%~40% of its capacity according to the standard charging method. -
Page 23: Warranty
The warranty period shall be governed by warranty law in the vehicle’s country of sale, in force at the time it is sold. Warranty claims for defects not brought to the attention of a RIEJU-authorised dealer before the end of the warranty period shall be excluded. - Page 24 WARRANTY d) Replacement parts not authorised for use by RIEJU have been used in maintenance or repair work on the vehicle, or if, and to the extent that, lubricants, or other liquids (including, but not limited to, cleaning products) that were not expressly mentioned in the User Manual’s instructions have been used on or in the vehicle.
- Page 25 RIEJU’S behalf. b) If there is doubt as to whether there is a defect or a visual or material inspection is required, RIEJU reserves the right to require that the parts being claimed under the warranty be sent to it, or to request that a RIEJU expert examine them.
