Page 1: Rear Brake
TANGO 125 EURO 4 MANUEL DE PROPRIEÉTAIRE OWNER’S MANUAL MANUAL DEL PROPIETARIO... - Page 3 This manual has to be considered as an integrate component of the mortorbike and must remain part of the basic equipment, and handed over in the event of a change of vehicle ownership. In the event of any problems, please consult the RIEJU dealer who will assist you or check our web www.riejumoto.com.
-
Page 4: Table Of Contents
Out of gear (Neutral) indicator CLUTCH LEVER Temperature warning lamp FRONT BRAKE LEVER Headlight Main beam warning light REAR BRAKE PEDAL Direction indicator warning lamp GEAR BOX PEDAL Engine warning lamp PETROL TANK INSTRUMENT DESCRIPTION PETROL TAP ADJUST BUTTON FUNCTION INSTRUCTION Tango 125 E4... - Page 5 AIR FILTER WHEEL DIAMETER AND PULSES CLEANING AND STORAGE CLOCK SETTINGS CLEANING MOTORBIKE OPERATION LONG-TIME STORAGE STARTING AND RIDING CHECKS BEFORE USING MOTORCYCLE RUNNING IN TECHNICAL SPECIFICATIONS & CHARACTERISTICS 41 ACCELERATION MAINTENANCE TO BRAKE (SLOWING DOWN) STOPPING Tango 125 E4...
-
Page 6: Motorbike Description
The engine is anchored to a highly resistant perimeter type chassis, with tapered steering bearings. The front suspension in the Marathon 125 consists of a hydraulic fork with bars, The rear suspension with variable transmission consists of a shock absorber anchored to a progressive articulated rod system ( Tango 125 E4... -
Page 7: Delivery Of The Motorcycle
WARRANTY REGISTRATION – complete the necessary information, pass a copy to the owner, and return a copy immediately to your RIEJU distributor. OPERATION - Explain the functions & correct handling of the motorcycle. WARNINGS - Explain the importance of warning labels to ensure a long life of the motorcycle. - Page 8 REAR BRAKE LEVER ADJUSTMENT - Adjust to the correct height for the user. GEAR LEVER ADJUSTMENT- Adjust to the correct height for the user. WARNING: Changes on the bike don’t authorized by RIEJU, or use of parts that don’t are ORIGINAL SPARE PARTS from RIEJU on the warranty period.
-
Page 9: Identification Of The Motorbike
(Steering head.) is unique to every machine. This number is required to register your vehicle, this chassis or VIN number should be quoted when requesting warranty assistance or genuine Rieju spare parts. ENGINE IDENTIFICATION NUMBER The engine serial number is located on the top, left side bottom of the left crankcase. - Page 10 Periodically check the level of the brake fluid in the reservoir located on the top of the master cylinder of the rear brake and under the rear right panel, to recharge. ATTENTION: If the tank is empty, contact your official RIEJU dealer Brake fluid level and wear of brake pads Check that the brake fluid level is correct, otherwise check the brake pads for wear.
-
Page 11: Main Elements Of The Motorbike
NOTE: Note that the button always returns to the central position, to switch off the direction indicators push button. 2.- Horn Button Press the button to activate the horn Tango 125 E4... -
Page 12: Main And Dip Beam Light Switch
WARNING: Once the motor has reached it’s normal working temperature, return the choke lever go back to it’s original position, otherwise it could cause the motor to misfire. Tango 125 E4... -
Page 13: Clutch Lever
The front brake lever is situated on the right-hand side of the handlebar. To activate the front brake, pull the lever towards the handlebar. REAR BRAKE PEDAL The rear brake pedal is on the right-hand side of the motorbike. To activate it, press downwards with the food. Tango 125 E4... -
Page 14: Gear Box Pedal
The capacity of the tank is 6 liters. CAUTION: Use only Unleaded petrol, without oil, the use of another type of fuel can damage the engine and this damages will not be considered as warranty. Tango 125 E4... -
Page 15: Petrol Tap
"ON" position, turn the lever to this position. Fill the tank as soon as possible, then it is important to remember to turn the lever back to "ON“. TIP: Do not drive normally in RESERVE position as you could run out of petrol. Tango 125 E4... -
Page 16: Routine Testing
Check operation of all lights, and direction indicators plus the oil warning lamp and petrol reserve panel lights. Replace bulbs as necessary. Start switch (2) This switch is used to start the engine, after verifying that the gear-change pedal is in the neutral position. Tango 125 E4... -
Page 17: Tyres
CAUTION: when the pressure is very high, the tyres can no longer absorb any shocks, transmitting any road sur- face defects directly to the chassis, handlebar and rider. Tango 125 E4... -
Page 18: Instrument And Indicators
ATTENTION: Do not use the bike with this warning light on, as this may cause serious damage to the engine, consult your RIEJU dealer as soon as possible. Tango 125 E4... -
Page 19: Headlight Main Beam Warning Light
This indicator comes on when on fail is detected on the engine. ATTENTION: Do not use the bike with this warning light on, as this may cause serious damage to the engine, consult your RIEJU dealer as soon as possible. Tango 125 E4... -
Page 20: Instrument Description
Display range 0-9999,9 Km (mile) 3 seconds in Trip A/B screen to reset. o Display Unit 0,1 Km (mile) o Press and hold the Adjust button for 3 seconds in Hour metter A/B screen to reset Tango 125 E4... -
Page 21: Selection Miles
Hold pressing the Adjust button for 3 seconds to reset the “TRIP A”. Press the Adjust button to switch from “TRIP A” to “TRIP B”. Hold pressing the Adjust button for 3 seconds to reset the “TRIP B”. Tango 125 E4... -
Page 22: Total Hour
Press the Adjust button to switch from hour meter A to hour meter B. Press and hold the Adjust button for 3 seconds to reset the hour meter A. Press the Adjust button to switch from hour meter B to back to the main screen. Tango 125 E4... -
Page 23: Select Button Function Instruction
12/24 hour mode. If 24 hour mode is chosen then the AM/PM symbol will not be displayed STOPWATCH: Press the Select button during main screen to switch from Clock to Stopwatch. Press and hold the Select button for 1 seconds to reset the Stopwatch Tango 125 E4... -
Page 24: Speed Record
Press and hold the Select button for 3 seconds to reset the Speed Record. Average speed and the Max speed display in the 3 seconds rotation. Press the Select button to switch from Speed Record back to main screen. Tango 125 E4... -
Page 25: To Enter The Setting Mode
Adjust Button for tree times to enter the sensing point setting. Press the Select button to move to the digit you want to set. Press Adjust button to go back to tire circumferences value & sensing point setting screen. Tango 125 E4... -
Page 26: Wheel Diameter And Pulses
The wheel diameter and the number of pulses will the following: TYRE DIAMETER PULSES Off-road 2075 Super 2030 Motard ATTENTION: Putdifferent values as indicates will produce that the speed show by the dashboard it will incorrect, any consequence produce by this issue iwill not a RIEJU responsability. Tango 125 E4... -
Page 27: Clock Settings
Press the Select button to enter the clock (Hour) setting. Press the Select button to choose the hour/minute you want to set. Press Adjust button to get back to Clock setting screen. ATTENTION: Other functions are the factory settings should not be changed. Tango 125 E4... -
Page 28: Motorbike Operation
(OUT) and ride away. Do not accelerate too much until the motor is warm enough ATTENTION: Before riding the motor should be warm, never accelerate or ride hard when the motor is cold. This will prevent pre-mature damage to your engine. Tango 125 E4... -
Page 29: Running In
ATTENTION: As indicate on the Service Manual you must done the firts Service at 500 Km in your Official rieju Workshop. Is essential done the services indicates on the Service Manual and equire the signature and stamp of the Workshop at time to pick up the bike. Don’t make the service as the Km indicates is reason for loss the vehicle warranty. -
Page 30: To Brake (Slowing Down)
Gear changing should be done carefully to ensure the gear you want is selected before releasing the clutch. Tango 125 E4... -
Page 31: Carburettor
CARBURETTOR The carburettor provides the correct petrol air mixture to the engine. It the settings are tampered with poor performance and/or overheating may occur. If you have any problems please refer to your RIEJU dealer. BATTERY (CHECKING THE BATTERY) If you see rust on the terminals and the ends of the terminals, they should be cleaned with a wire brush. -
Page 32: Front Suspension
REAR SUSPENSION The rear suspension consists of a gas-assisted hydraulic monoshock absorber with separate gas reservoir and spring preload adjustment via the nut located under the shock absorber spring by means of the PRS progressive articulated rod system. Tango 125 E4... -
Page 33: Spark Plug Check
Screw the spark plug in by hand, trying to make sure that it is not cross threaded finally tighten with the correct tool. Tango 125 E4... -
Page 34: Cooling System
(a). Oil below advised level, fill to the correct level. ADVICE: See technical specifications to check the recommend by RIEJU. WARNING: Drive with the bike at minimum level (a) can damage the engine. The damages produce by this cause it will not admit as warranty. Tango 125 E4... -
Page 35: Chain Adjustment And Tension
To do so use the rule marks on of the swing arm. 5 - Set the position using the 2 nuts (B) and tighten the nut (A) that secures the rear wheel axle Tango 125 E4... -
Page 36: Air Filter
In order to access the air filter, disassemble the mortorbike seat, allowing free access to the filter box. Remove the cover, which is attached to the box by a screw (A), and remove the filter housing. Tango 125 E4... - Page 37 After removal, check to see if the foam filter is blocked, in which case wash with specific product to clean foam filter, apply some air filter foam oil, Rieju suggest use LIQUI MOLY FOAM FILTER OIL, then squeeze the filter material between your hands to remove surplus oil.
-
Page 38: Cleaning And Storage
4- Remove the degreasing agent along with the dirt using a low pressure water source such as a hosepipe. ATTENTION: Rieju accepts no responsibility for the use of degreasing agents which stain and/or cause deterioration to the motorbikes components. Rieju accepts no responsibility for any possible damage resulting from the use of pressurized water to clean the motorbike. -
Page 39: Long-Time Storage
2- Lubricate all control cables. 3- Seal the exhaust pipe to prevent the entry of any moisture. 4- Remove the battery and charge at least once a month, be careful to ensure the battery is stored in the correct conditions. Tango 125 E4... -
Page 40: Checks Before Using Motorcycle
Tension and condition of chain and sprocket Lubricate ATENCIÓN: Each time the vehicle is used, it should be checked as above. If during these checks any abnormality is established, it should be repaired before using the motorcycle. Tango 125 E4... -
Page 41: Technical Specifications & Characteristics
SPECIFICATIONS ENGINE Type 4 stroke water cooled Engine capacity 124 cm Model cylinders 1 inclined forwards Piston size 56.5,0x49.5mm Compression ratio 11,20:1 Starting system Electrical PETROL Type Unleaded petrol OIL FILTER Type Paper OIL PUMP Type Mechanic Tango 125 E4... - Page 42 Sin sustitución del conjunto filtro aceite 0,95 I (1,00 US qt) (0,84 Imp. qt) Con sustitución del filtro de aceite 1,00 I(1,06 US qt)(0,88 Imp. qt) WATER PUMP Type Mechanical SPARK PLUG Type DR8 ES Electrode Clearance 0,6-0,7mm (0,028-0,031") Tango 125 E4...
-
Page 43: Maintenance
Cleaning and greasing of air filter CL & L CL & L CL & L CL & L Inspect and adjust carburettor Inspect and adjust the sparkplug Inspect all nuts and bolts for the chassis and plastics C:CONTROL; R: REPLACEMENT; L:LUBRICATION; L=CLEANING Tango 125 E4... - Page 44 Inspect radiator liquid levels Inspect exhaust system Check terminals and battery condition Check oil pump operation Tyre C:CONTROL; R: REPLACEMENT; L:LUBRICATION; L=CLEANING CAUTION: Maintenance schedule can change on function of the bike use, conduction, environmental conditions, etc… Tango 125 E4...
