MEMORY KEYPAD
User's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MEMORY KEYPAD and is the answer not in the manual?

Questions and answers

Related Manuals for MotionGrey MEMORY KEYPAD

Summary of Contents for MotionGrey MEMORY KEYPAD

  • Page 1 MEMORY KEYPAD User's Manual...

  • Page 2: Function Overview

    1. Function Overview Function 1. 3 memory positions. 2. Anti-collision stop feature. 3. Reset function. 4. Display lifting height with white LED. 5. Prevent frequent key presses to protect the system. 6. Switchable height display unit. 7. Power-down memory for position. 8.
  • Page 3 2. Definition of Keys and Display Help Display Help Display Description Troubleshooting Help Content Digit The current height of The unit will be set before the adjustable desk EX-factory (unit: inch/cm） Motor 1 Fault 1. Ensure that the cable of motor 1 is securely connected to the control box.
  • Page 4 Motor 2 Fault 1. Ensure that the cable of motor 2 is securely connected to the control box. Cause: The cable of 2. Check whether the cable of motor 2 is not motor 2 is undamaged. connected. 3. After troubleshooting, press any key (except M key) to clear the error code and return to normal operation.
  • Page 5 Motor 1 Over- 1. Reduce the load to stay within the maximum capacity, or Current troubleshoot any mechanical issues. Causes: Overload, 2. After 8 seconds, press any Mechanical Fault key (except M key) to clear the error code and resume normal operation.
  • Page 6 3. Operations • Press the UP key to raise the desk. Release the key to stop the desk's movement. • Press the DOWN key to lower the desk. Release the key to stop the desk's movement. • Reset: If it's the first time using the desk, if the desk becomes unbalanced, or if the LED displays incorrect height data, a reset is needed.
  • Page 7 Setting the Lower Limit: While holding down both the M key and the 1 key, the digital display will blink and show the real-time height. Use the UP or DOWN key to adjust to the desired minimum height, then press S key to confirm and save the setting.

  • Page 8: Precautions For Use

    4. Precautions for Use • Do not attempt to install or operate the product if it is damaged or if parts are missing. Doing so may result in equipment damage or personal injury. • Ensure that the control box is only connected to the specified voltage mentioned on the label.
