Operating Instructions
Thread Depth Plug Gage "digital IW"
Made
In
Germany

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the digital IW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EMUGE digital IW

Summary of Contents for EMUGE digital IW

  • Page 1 Made Germany Operating Instructions Thread Depth Plug Gage “digital IW”...
  • Page 2 Operating Instructions Thread Depth Plug Gage “digital IW” Introduction The EMUGE thread depth plug gage “digital IW” permits gaging and measuring of threads in one single step. The thread depth plug gage complies with the DIN ISO 1502 criteria defined for thread plug gages.

  • Page 3: Table Of Contents

    Operating Instructions Thread Depth Plug Gage “digital IW” Content Page 1. Scope of delivery 2. Accessories for wireless transmission to a PC 3. Important hints prior to initial operation 4. Safety information 5. Technical data 6 - 7 6. Inserting / changing the battery 8 - 9 7.
  • Page 4 Operating Instructions Thread Depth Plug Gage “digital IW” 1. Scope of delivery The basic equipment of the thread depth plug gage “digital IW” consists of: Thread depth plug gage “digital IW” Battery (CR 2032, 3V, 230 mAh) Operating instructions 2. Accessories for wireless transmission to a PC Wireless receiver i-Stick Order no.: L0091500.01...
  • Page 5 Operating Instructions Thread Depth Plug Gage “digital IW” 3. Important hints prior to initial operation In order to ensure a long use of this tool, any contamination on the thread depth plug gage must be removed immediately after completion of usage. This can be done with a dry cloth. Subsequently, to conserve the metal components, they should be lightly oiled.
  • Page 6 Operating Instructions Thread Depth Plug Gage “digital IW” 5. Technical data Inductive measuring system .433" (11 mm) liquid crystal display Battery Lithium 3V, type CR2032, 230 mAh Operating time approx. 2 years* (2000 work. hrs/year) * is reduced when operating with the wireless interface Protection group IP67 acc.
  • Page 7 Operating Instructions Thread Depth Plug Gage “digital IW” 5. Technical data No additional transfer modules on the measuring tool are required thanks to the “Integrated Wireless” option Go gage body Data / Hold button Menu button / Preset activate Handle...
  • Page 8 Operating Instructions Thread Depth Plug Gage “digital IW” 6. Inserting / changing the battery...

  • Page 9: Functions

    Operating Instructions Thread Depth Plug Gage “digital IW” 6. Inserting / changing the battery 7. Functions 7.1 Auto ON / OFF Moving the sliding barrel will automatically switch the instrument ON. If the instrument has not been used for 8 minutes or more, it will be automatically switched OFF.

  • Page 10: On-Off / Reset

    Operating Instructions Thread Depth Plug Gage “digital IW” 7. Functions 7.2 ON /OFF / RESET RESET This function is recommended when the zero point is frequently repositioned (for example: comparative measurements)

  • Page 11: Data Function

    Operating Instructions Thread Depth Plug Gage “digital IW” 7. Functions 7.3 DATA Pressing this button while wireless mode is active, transmits the measured value. Note: When the wireless mode is not active, the measured value is frozen (see 7.4 HOLD function).

  • Page 12: Hold Function

    Operating Instructions Thread Depth Plug Gage “digital IW” 7. Functions 7.4 HOLD Note: When the HOLD function is activated, the “MENU” and “OI” are not available. The message “Hold” appears in the display.

  • Page 13: Menu Functions

    Operating Instructions Thread Depth Plug Gage “digital IW” 8. Menu functions Intuitive menu guidance Symbol Open the menu  Symbol  Change the value 8.1 Start menu 8.2 Lock function Note: When the LOCK function is activated the “MENU” and “OI” are not available.

  • Page 14: Enter Preset

    Operating Instructions Thread Depth Plug Gage “digital IW” 8. Menu functions 8.4 Enter PRESET 8.5 Wireless setup Note: The wireless setup takes place by pressing the Data / Hold button once the address has been assigned in the MarCom Software. Address will appear in the display.

  • Page 15: Channel Selection

    Operating Instructions Thread Depth Plug Gage “digital IW” 8. Menu functions 8.4 Channel selection Note: The standard factory setting is Channel CH 01. It is only necessary to change this wireless frequency when it conflicts with other devices. 8.7 Eco function Note: The rate of transmission is reduced in the ECO mode.

  • Page 16: Measuring Direction

    Operating Instructions Thread Depth Plug Gage “digital IW” 8. Menu functions 8.8 Measuring direction Note: Changes the counting direction of the measuring system. 8.9 Exit menu Note: Press and hold the MENU button to leave the menu at any time and/or to accept the selected changes.

  • Page 17: Call Up Preset

    All batteries can be recycled; raw materials such as iron, zinc or nickel can be obtained from recycled batteries, thus battery recycling helps with the protection of the environment. Used electrical devices put on the market by EMUGE can be returned to us. We will ensure an environmentally safe disposal.
  • Page 18 Operating Instructions Thread Depth Plug Gage “digital IW” Declaration of Conformity This device contains licence-exempt transmitter(s)/receiver(s) that complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference.
  • Page 20 EMUGE Corp. 1800 Century Drive West Boylston, MA 01583-2121 +1-508-595-3600, +1-800-323-3013 (Toll-Free) +1-508-595-3650 info@emuge.com www.emuge.com...
