Summary of Contents for Inovance SV670N Series

  • Page 2: Preface

    Introduction Thank you for purchasing the SV670N series servo drive developed by Inovance. The SV670N series servo drive is a high‑end servo drive designed based on global‑ leading standards and high‑end application needs. It is featured with high speed, high precision, high performance, and tuning‑free Function.
  • Page 3 Provides instructions on maintenance SV670N Series Servo Drive 19011864 and repair of the equipment. Maintenance Guide Presents the safety function and related SV670N Series Servo Drive Safety certifications and standards, wiring, 19011861 Guide commissioning process, troubleshooting, and functions. Provides information on selection,...

  • Page 4: Table Of Contents

    Table of Contents T T a a b b l l e e o o f f C C o o n n t t e e n n t t s s Preface ................1 1 Routine Maintenance .

  • Page 5: Routine Maintenance

    Routine Maintenance Routine Maintenance Routine Maintenance Standard operating conditions: Average annual ambient temperature: 30℃ Average load rate: ＜ 80% Daily operating time: ＜ 20 h 1.1.1 Routine Checklist Check the following items during routine inspection. Table 1–1 Routine checklist Routine Checklist Checked The ambient temperature and humidity are normal.

  • Page 6: Periodic Inspection

    To keep the servo drive and servo motor in good condition, perform parts replacement based on the replacement cycles listed in the following table. Contact Inovance or Inovance agent before replacement to double check whether the part needs to be replaced.
  • Page 7 Routine Maintenance Type Object Standard Replacement Interval Remarks Bearing 3 to 5 years (20,000 h to 30,000 h) Oil seal 5000 h 3 to 5 years (20,000 h to 30,000 h) Encoder Motor Depends on the operating Absolute encoder condition battery See the operation instructions for the encoder battery for details.

  • Page 8: Parts Replacement

    Parts Replacement Parts Replacement Replacing the Motor Flat Key Observe all the requirements presented in this chapter. Failure to comply may ● result in equipment fault or damage. Violent disassembly is not allowed. Take enough care during disassembly to ● prevent personal injury.

  • Page 9: Removing The Motor Oil Seal

    Parts Replacement Removing the Motor Oil Seal Tools needed: a pair of needle‑nose pliers, a pair of slip‑proof gloves, and a piece ● of cotton cloth. Disassembly procedure: ● 1. Put the cotton cloth onto the supporting point B to avoid the end cover from being scratched during disassembly.
  • Page 10 *19011864A01*...
