NXR-ILM08C-ECT
Applicable Support Software
The following table shows support software that can be used in the system configured with the NXR-series EtherCAT IO-Link Master Unit. The
Support Software used depends on the scope of the applicable system. For versions of support software, refer to Version Information on page 13.
Destination to which IO-Link Master Unit is
connected
Controller
NJ/NX-series CPU Built-in EtherCAT ports on
Unit or NY-series NJ/NX-series CPU Unit or
Industrial PC NY-series Industrial PC
Controller from EtherCAT master from another
another company company
*1. From the controller from another company, make settings through message communications. Or use a commercially-available IO-Link USB
master to make settings from the CX-ConfiguratorFDT. For the commercially available IO-Link USB master, the following models are
recommended.
Model
USB-2-IOL-0002
IO-Link-Master02-USB
4
Creating the user
EtherCAT master
Sysmac Studio
Software from
another company
Manufacturer
TURCK
Pepperl+Fuchs
Applicable Support Software
Setting the PDO
program mapping
Sysmac Studio
Software from
another company
Setting up Setting and
IO-Link Master monitoring IO-Link
Unit devices
Sysmac Studio CX-ConfiguratorFDT
Software from
*1
another company
