https://www.phoenixcontact.com/us/products/2702530
Router - TC ROUTER 2002T-4G - 2702530
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Why buy this product
Industrial 4G mobile router (LTE)
Fallback to 3G (UMTS/HSPA) and 2G (GPRS/EDGE)
Mobile high-speed Internet connection up to 150 Mbps
Networking of VPN-capable end devices via the mobile network
Ethernet SMS gateway for easy alerting
Two switching inputs and one switching output
Stateful inspection firewall for dynamic filtering
NAT table and port forwarding for direct remote access to an end device
Configuration via web-based management or microSD card
Two local Ethernet connections
Switchable energy-saving mode
Integrated logbook
Connection monitoring
Extended temperature range, -40 °C ... +70 °C
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Industrial LTE 4G router, European version, fallback to 3G UMTS/HSPA and 2G GPRS/EDGE, 2 Ethernet
interfaces, firewall, NAT, 2x SMA-F antenna socket, SMS and e-mail transmission, 2 digital inputs, 1 digital output
1
4055626212814
85176200
04/13/2017 Page 1 / 7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Phoenix Contact TC ROUTER 2002T-4G
Summary of Contents for Phoenix Contact TC ROUTER 2002T-4G
- Page 1 Router - TC ROUTER 2002T-4G - 2702530 Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's documentation. Our General Terms of Use for Downloads are valid (http://phoenixcontact.com/download) Industrial LTE 4G router, European version, fallback to 3G UMTS/HSPA and 2G GPRS/EDGE, 2 Ethernet...
-
Page 2: Technical Data
Router - TC ROUTER 2002T-4G - 2702530 Technical data Dimensions Width 45 mm Height 130 mm Depth 126 mm Ambient conditions Ambient temperature (operation) -40 °C ... 70 °C (Maximum transmission power 5 dBm) -40 °C ... 60 °C (Maximum transmission power 23 dBm) Ambient temperature (storage/transport) -40 °C ... - Page 3 Router - TC ROUTER 2002T-4G - 2702530 Technical data Radio interface Frequency 850 MHz (2 W (EGSM)) 900 MHz (2 W (EGSM)) 1800 MHz (1 W (EGSM)) 1900 MHz (1 W (EGSM)) 850 MHz (0.25 W (UMTS/HSPA)) 900 MHz (0.25 W (UMTS/HSPA)) 1900 MHz (0.25 W (UMTS/HSPA)) 2100 MHz (0.25 W (UMTS/HSPA))
-
Page 4: Standards And Regulations
Router - TC ROUTER 2002T-4G - 2702530 Technical data Standards and Regulations Electromagnetic compatibility Conformance with R&TTE directive 1999/5/EC Type of test Vibration resistance in acc. with EN 60068-2-6/IEC 60068-2-6 Test result 5g, 10...150 Hz, 2.5 h, in XYZ direction Type of test Shock in acc. with EN 60068-2-27/IEC 60068-2-27... - Page 5 Router - TC ROUTER 2002T-4G - 2702530 Schematic diagram Schematic diagram RESET Micro M ic LAN 1 LAN 2 ANT 2 ANT 1 ANT 2 Connect the antenna 24V 0V I1 I2 O1 Front view Schematic diagram Schematic diagram Remove SIM card holder Insert the SIM card 04/13/2017 Page 5 / 7...
-
Page 6: Power Supply
Router - TC ROUTER 2002T-4G - 2702530 Schematic diagram Schematic diagram M ic 24V 0V I1 I2 O1 Assembly Device connections Classifications eCl@ss eCl@ss 5.1 27230207 ETIM ETIM 6.0 EC000310 Accessories Accessories Antenna Antenna - TC ANT MOBILE WALL 5M - 2702273 Multiband mobile phone antenna with mounting bracket for outdoor installation. 5 m antenna cable with SMA round plug ... - Page 7 Router - TC ROUTER 2002T-4G - 2702530 Accessories Power supply unit - TRIO-PS-2G/1AC/24DC/3/C2LPS - 2903147 Primary-switched TRIO POWER power supply with push-in connection for DIN rail mounting, input: 1-phase, output: 24 V DC/3 A C2LPS Phoenix Contact 2017 © - all rights reserved http://www.phoenixcontact.com 04/13/2017 Page 7 / 7...
