- Page 1 CASPR MEDIK CONTINUOUS HV AC DISINFECTANT TECHNOLOGY OWNER’S MANUAL Specifications ● Installation ● Maintenance Caution: Read manual carefully for proper procedures and operation.
-
Page 2: Table Of Contents
About CASPR MEDIK ........ -
Page 3: Product Contents
NCC cell Adhesive Gasket Installation Hardware (4) Self-tapping Screws (2) Cell Mounting Screws Replacement Parts Bulbs: 9” Bulb Part Number: BULB-HV-9-002-CASPR 14” Bulb Part Number: BULB-HV-14-002-CASPR Cells(which includes bulbs): 9” NCC Cell Part Number: CELL-HV-9-002-CASPR 14” NCC Cell Part Number: CELL-HV-14-002-CASPR... -
Page 4: About Caspr Medik
About CASPR MEDIK CASPR MEDIK is an enhanced “no touch” continuous disinfection device designed to supplement normal cleaning and disinfection protocols. CASPR MEDIK uses Natural Catalytic Conversion (NCC) to generate safe, low levels of hydrogen peroxide. NCC technology replicates natural purifying processes by using a high intensity light to activate a proprietary metal catalytic coating, converting water vapor into hydrogen peroxide. -
Page 5: Recommended Installation Tools
Recommended Installation Tools A - 4.5” Hole Saw Bit D - Utility Knife B - 3/8” Drill Bit E - STET C - Drill/Power Driver F - Phillips Head Screwdriver Installation Requirement Unit may be installed up or down stream of the air handler in the HVAC system as long as it is behind the filter. -
Page 6: Installation
Installation 1. Find a suitable location to mount your CASPR MEDIK Unit. 2. If necessary, cut away insulation for your plate to adhere to the duct. 3. Using the Adhesive Gasket Plate, trace the hole location onto the duct. 4. Use the Hole Saw and Drill to cut out the... - Page 7 Alternative Cutting Method 1. Using the Adhesive Gasket Plate, trace the hole location onto the duct. 2. Drill holes around the outside edges of the prviously marked hole but inside the outer holes of the Adhesive Gasket Plate. 3. Use the Tin Snips to cut out the space around the marked hole.
- Page 8 Installation 5. Remove the plastic backing on your Adhesive Gasket Plate. 6. Press the Adhesive Gasket Plate onto the duct. Secure with the (8) Self-Tapping Screws. 7. Connect the Cell to the Ballast using the two (2) cell mounting screws. 8.
-
Page 9: Maintenance/Uv Lamp Indicator
Disposal Of The NCC Cell Please do not throw the used NCC Cells in the garbage. The special germicidal UV bulb used in the CASPR MEDIK contains some insignificant amount of mercury. Contact your local Waste Management Center for a proper disposal procedure. -
Page 10: Changing The Ncc Cell
Changing The NCC Cell 1. Remove the Unit Power Cable from the receptacle or ensure the unit isn’t powered. 2. Twist the Ballast Housing counter-clockwise to unlock the unit from the mounting plate. Pull the unit from the duct. 3. Remove the (2) Screws holding the NCC Cell in place and remove the NCC Cell from the Unit Cover. - Page 11 Changing The NCC Cell 4. Exchange the Old NCC Cell with the new NCC Cell and replace the (2) Screws that hold it in place. 5. Replace the Unit in the duct and turn clockwise to lock in place. 6. Place the Unit Power Cable back into the receptacle or repower your unit.
-
Page 12: Warranty Information
SALES THROUGH DISTRIBUTOR OR RESELLER To the extent the Product is purchased by Buyer from an authorized CASPR distributor or reseller, this Express Limited Warranty passes through to Buyer. - Page 13 FOR U.S. APPLICATION ONLY Product warranties are governed by state and federal laws and may vary from state to state. This Express Limited Warranty provides Buyer with specific assurances regarding repair or replacement of the Product. Other warranties are expressly negated. FOR CANADIAN APPLICATION ONLY Canadian, provincial, and territorial sales laws may govern implied warranties.
- Page 14 www.casprTech.com Corporate Office 1343 W. Causeway Approach Mandeville, LA US 70471 1-844-717-8819 info@casprtech.com V.IN-M-MED-03-08012023...
