- Page 1 CASPR MEDIK CONTINUOUS HV AC DISINFECTANT TECHNOLOGY OWNER’S MANUAL Specifications ● Installation ● Maintenance Caution: Read manual carefully for proper procedures and operation.
-
Page 2: Table Of Contents
About CASPR MEDIK ........ -
Page 3: Product Contents
NCC cell Adhesive Gasket Installation Hardware (4) Self-tapping Screws (2) Cell Mounting Screws Replacement Parts Bulbs: 9” Bulb Part Number: BULB-HV-9-002-CASPR 14” Bulb Part Number: BULB-HV-14-002-CASPR Cells(which includes bulbs): 9” NCC Cell Part Number: CELL-HV-9-002-CASPR 14” NCC Cell Part Number: CELL-HV-14-002-CASPR... -
Page 4: About Caspr Medik
About CASPR MEDIK CASPR MEDIK is an enhanced “no touch” continuous disinfection device designed to supplement normal cleaning and disinfection protocols. CASPR MEDIK uses Natural Catalytic Conversion (NCC) to generate safe, low levels of hydrogen peroxide. NCC technology replicates natural purifying processes by using a high intensity light to activate a proprietary metal catalytic coating, converting water vapor into hydrogen peroxide. -
Page 5: Recommended Installation Tools
Recommended Installation Tools A - 4.5” Hole Saw Bit D - Utility Knife B - 3/8” Drill Bit E - STET C - Drill/Power Driver F - Phillips Head Screwdriver Installation Requirement Unit may be installed up or down stream of the air handler in the HVAC system as long as it is behind the filter. -
Page 6: Installation
Installation 1. Find a suitable location to mount your CASPR MEDIK Unit. 2. If necessary, cut away insulation for your plate to adhere to the duct. 3. Using the Adhesive Gasket Plate, trace the hole location onto the duct. 4. Use the Hole Saw and Drill to cut out the... - Page 7 Alternative Cutting Method 1. Using the Adhesive Gasket Plate, trace the hole location onto the duct. 2. Drill holes around the outside edges of the prviously marked hole but inside the outer holes of the Adhesive Gasket Plate. 3. Use the Tin Snips to cut out the space around the marked hole.
- Page 8 Installation 5. Remove the plastic backing on your Adhesive Gasket Plate. 6. Press the Adhesive Gasket Plate onto the duct. Secure with the (8) Self-Tapping Screws. 7. Connect the Cell to the Ballast using the two (2) cell mounting screws. 8.
-
Page 9: Maintenance/Uv Lamp Indicator
Disposal Of The NCC Cell Please do not throw the used NCC Cells in the garbage. The special germicidal UV bulb used in the CASPR MEDIK contains some insignificant amount of mercury. Contact your local Waste Management Center for a proper disposal procedure. -
Page 10: Changing The Ncc Cell
Changing The NCC Cell 1. Remove the Unit Power Cable from the receptacle or ensure the unit isn’t powered. 2. Twist the Ballast Housing counter-clockwise to unlock the unit from the mounting plate. Pull the unit from the duct. 3. Remove the (2) Screws holding the NCC Cell in plae and remove the NCC Cell from the Unit Cover. - Page 11 Changing The NCC Cell 4. Exchange the Old NCC Cell with the new NCC Cell and replace the (2) Screws that hold it in place. 5. Replace the Unit in the duct and turn clockwise to lock in place. 6. Place the Unit Power Cable back into the receptacle or repower your unit.
-
Page 12: Warranty Information
LIMITED 3 YEAR WARRANTY ON CASPR Technologies UNITS AND 1 YEAR WARRANTY ON CASPR Technologies REPLACEMENT PARTS Customer should not repackage and ship the CASPR MEDIK unit due to possibility of irreparable damage. For warranty service, please contact your CASPR Technologies Distributor for the address of the nearest service center, email warranty@casprgroup.com call Customer Service at 844-717-8819. - Page 13 This entire warranty shall continue to be valid, legal and enforceable in any jurisdiction where a similar determination has not been made. This warranty is provided by: CASPR Technologies, Inc. 4505 Excel Parkway, #600 Addison, TX 75001...
- Page 14 www.casprTech.com Corporate Offices 4505 Excel Parkway Suite 600 Addison, TX US 75001 1-844-171-8819 info@casprtech.com V.IN-M-MED-03-03052021b...
