Sinoboom TB18E Plus Operation Manual

Hide thumbs Also See for TB18E Plus:
Table of Contents

Advertisement

Quick Links

Download this manual
Part No.514002100002
Rev: A
Oct 2021
Operation
Manual
产品说明书
PRODU
C T MAN U AL
TB18E Plus/TB590E Plus
TB20EJ Plus/TB660EJ Plus
0608E (2132E)
G T JZ
TB20E Plus/TB680E Plus
0808E (2732E)
G T JZ
TB22EJ Plus/TB740EJ Plus
0808E (2732E)
G T JZ
G T JZ
0808E (2732E)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TB18E Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sinoboom TB18E Plus

Summary of Contents for Sinoboom TB18E Plus

  • Page 1 Operation Part No.514002100002 Rev: A Manual Oct 2021 产品说明书 PRODU C T MAN U AL TB18E Plus/TB590E Plus TB20EJ Plus/TB660EJ Plus 0608E (2132E) G T JZ TB20E Plus/TB680E Plus 0808E (2732E) G T JZ TB22EJ Plus/TB740EJ Plus 0808E (2732E) G T JZ...
  • Page 3 Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your...
  • Page 4 : No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China Zip Code : 410600 Copyright © Hunan Sinoboom Intelligent Equipment Co., Ltd. All Rights Reserved The final interpretation right of this manual belongs to Hunan Sinoboom Intelligent Equipment Co., Ltd.
  • Page 5 Decals/Nameplate Inspection of the Operation Manual for details.) Trade Identification Model Serial No. Imperial Metric From 1400100100 to present TB18E Plus TB18E Plus TB590E Plus From 1400200100 to present TB20EJ Plus TB20EJ Plus TB660EJ Plus From 1401000100 to present...
  • Page 6 This Page Intentionally Left Blank...
  • Page 7 This manual covers the basic parts information of one or more products. Therefore, please use this manual according to your needs. If you find problems in the manual or have suggestions for improve- ment, feel free to share your feedback with Sinoboom, and we will address these issues as soon as possible.
  • Page 8 This Page Intentionally Left Blank...

  • Page 9: Table Of Contents

    Function Test ......6-1 Decals/Nameplates(ANSI)..10-14 Testing the Ground Controller ..6-1 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 10 Appendix 1: Symbols and Description....... A-1 Appendix 2: Prepare the Work Record Before Delivery ..A-3 Appendix 3: Repair & Inspection Report ......A-5 © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 11: Introduction

    The owner or administrator of the machine shall also provide the manufacturer’s maintenance information to the person responsible for maintaining the machine. If you have any questions, contact Hunan Sinoboom In- telligent Equipment Co., Ltd.. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 12 This Page Intentionally Left Blank © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 13: Machine Specifications

    Drive mode (drive×steer) 4WD×2WS Gradeability 35%/19° Turntable tailswing 4ft 9in 1.45 m Max allowable inclination 5° Turning radius (inside) 2.4 m 7ft 10.5in Turning radius (outside) 5.55 m 18ft 2.5in TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 14 WEIGHT Gross weight (unladen) 11328 kg 24974 lb Table 1-2 TB20EJ Plus specifications TB20EJ Plus (METRIC) TB660EJ Plus (IMPERIAL) MEASURE DIMENSION Max platform height 20 m 65ft 7in © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 15 5.55 m 18ft 2.5in Max allowable side force(restricted/ 600 N/400 N 134 lbf/90 lbf unrestricted) Max operating noise level 80 dB IP grade IP65 POWER 29 V DC,15 kW Motor（Volts/kW） TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 16 Max horizontal reach (restricted/ 13.0 m/14.7 m 42ft 8in / 48ft 2in unrestricted) Overall length(stowed) 9.63 m 31ft 7in Overall width(stowed) 2.49 m 8ft 2in Overall height (stowed) 2.81 m 9ft 3in © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 17 16 ml/r + 4 ml/r Hydraulic tank capacity 37.4gal（UK）/44.9gal（US） 170 L Hydraulic system pressure 28MPa 4061 Psi 2×24V, 480Ah（lead-acid battery） Battery (number×voltage, capacity) 2×24V, 528Ah（lithium battery） Power system voltage 48 VDC TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 18 2.49 m 8ft 2in Ground clearance 0.39 m 1ft 3in Options 36×14-20（non-marking） Tire size (spec / type) 36×14-20（solid） 355/65D625（foam-filled） Options Options Platform dimension (L×W×H) 1.45×0.85×1.1 m 4ft 9in×2ft 9in×3ft 7in © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 19 48 VDC Control system voltage 12 VDC Charger（input voltage/output 100～240 V AC,60 A current） GROUND BEARING DATA 6820 kg Max tire load 15036 lb Pressure against ground 700 KPa 102 Psi TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 20 In cold weather, auxiliary devices are needed to start the machines. e) Rated platform capcity represents the rated load of the platform, including the loads of persons, materials, tools, platform accessories and other objects borne by the platform. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 21 MACHINE SPECIFICATIONS TB18E Plus range of motion 454 kg（1000 lb) 300 kg（661 lb） TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 22 MACHINE SPECIFICATIONS TB20EJ Plus range of motion 454 kg（1000 lb) 300 kg（661 lb） © Oct 2021 1-10 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 23 MACHINE SPECIFICATIONS TB20E Plus range of motion 454 kg（1000 lb) 300 kg（661 lb） TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 1-11 © Oct 2021...
  • Page 24 MACHINE SPECIFICATIONS TB22EJ Plus range of motion 454 kg（1000 lb) 300 kg（661 lb） © Oct 2021 1-12 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 25: Machine Components

    MACHINE COMPONENTS 17 18 21 22 23 24 Figure 2-1 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 26 Boom rises at an angle exceeding 15°, or extends beyond 1.2m. Transport position： Boom lowers and retracts in place, outriggers retract in place, jib boom rotate leftwards in place until under the main boom, platform rotates leftwards in place. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 27: Safety

    Ensure the machine's lifting height does not exceed 3 m(9.8 ft) until all damage has been repaired and all controllers operate properly. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 28: Electrocution Hazards

    Voltage Minimum Safe Distance (Phase to Phase, kV) (m/ft) 0-50 3.05 (10) 50-200 4.60 (15) 200-350 6.10 (20) 350 -500 7.62 (25) 500 -750 10.67 (35) 750 -1000 13.725 (45) © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 29 • Do not use the platform or boom minimum distance of 0.6m (2ft) assembly to push other machines and reduce the speed. or objects. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 30: Jobsite Hazards

    Do not lift the platform when the wind speed exceeds 12.5 m/s (28 mph). If the wind speed exceeds 12.5 m/s (28 mph) after the platform is lifted, © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 31 If the machine is used in any other applications, or by any other means, than specified by fold the platform and do not Sinoboom, it must be approved or guided by the continue to operate the machine. manufacturer.

  • Page 32: Unsafe Operation Hazards

    The battery is vital to maintaining the stability of the machine. • Do not place or attach any suspended load onto any part of the machine. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 33: Fall Hazards

    Maintenance Manual in addition to following more maintenance manual in addition to following more stringent industry regulations and workplace rules. stringent industry regulations and workplace rules. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 34: Crush Hazards

    • Limit the speed of travel according to ground conditions, crowding, gradients, the presence and location of personnel and any © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 35: Explosion And Fire Hazards

    During operation, keep the left and right doors of the chassis closed and locked. Only trained service personnel can open the left and right doors to repair the machine. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 36: Battery Hazards

    ELECTROCUTION HAZARD • Contact with hot circuit may cause serious injury or death. Be sure to wear goggles, gloves and protective clothing. • Remove all rings, watches and other accessories. © Oct 2021 3-10 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 37: Welding And Polishing Requirements

    Do not tamper with battery system to avoid serious accident. • Cut off the battery main switch if the battery is not to be used for an extended period. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 3-11 © Oct 2021...

  • Page 38: After Using The Machine

    7. Turn the key switch at the ground controls to OFF position and remove the key to avoid unauthorized operation of the machine. 8. Turn off the main power switch. © Oct 2021 3-12 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 39: Jobsite Inspection

    Operators must identify and avoid workplace hazards when mov- ing, installing and operating the machine. Unless approved by Sinoboom, never operate the ma- chine in a hazardous site. The following items present danger on the jobsite: •...
  • Page 40 JOBSITE INSPECTION This Page Intentionally Left Blank © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 41: Pre-Operation Inspection

    Never use a machine that has damaged or modified be certified as a qualified operator in operation of parts. Mark the machine and stop using the this machine. machine if you discover damage or modifications. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 42: Conducting A Pre-Operation

    • Tires and rims range of oil level indicator. • Alarms and lighting (if equipped) • Platform（including rails, floor plate, safety lock, brackets and entry door） © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 43: Inspecting The Battery

    Check the battery box for accumulation of water, if any, clear the water. • Check the paint of battery for damage, if any, repair immediately to prevent corrosion and keep the box insulated. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 44 PRE-OPERATION INSPECTION Note:Adding terminal protectors or applying anti- corrosion agent will help the terminals and cables from corrosion. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 45: Pre-Operation Function Test

    All the function tests of ground controller must be completed within a cycle. Do not use a machine with problems or malfunctions. Mark the machine and do not use it if you discover any TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 46 6. Enable switch 14. Platform rotate switch 7. Emergency power switch (not 15. Platform level switch used) 8. FE/DC mode select switch (not 16. Exhaust disposal switch (not used) used) © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 47 21. Heavy load indicator 9. Platform info 33. Overload limit 10. Alarm message 34. Drive limit (operating position) 22. Overload alarm 35. Drive and boom functions 11. Fault alarm 23. Not used allowed TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 48 4. Ensure the relevant indicator light on the display should be on and no error should be present. Enable switch Horn button © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 49 Jib up/down switch-TB20EJ Plus&22EJ Plus 2. Move the enable switch and meanwhile move only leftwards the main boom telescope switch, the main boom should extract smoothly. Turntable rotate switch TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 50: Testing The Platform Controller

    Move both the emergency power switch and each function switch/handle, the corresponding function should operate normally. TESTING THE PLATFORM CONTROLLER NOTICE All the tests of platform controllers should be completed within a cycle. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 51 8. Platform rotate switch 18. Steer direction 9. Not used 19. Drive/steer control handle 29. Horn button 10. Jib up/down switch-TB20EJ 20. Drive direction 30. Buzzer button Plus&TB22EJ Plus only TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 52 ON position, and then move the engine start Power indicator light switch, the engine should fail to start and all functions should be inoperative. Drive function Light on inidcates the platform controller is normally powered. Horn button © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 53 Note：The main boom up/down speed is in positive proportion to the stroke of control handle. TIPPING HAZARD Main boom telescope The machine must drive at low speed when not on a level surface. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 54 Move the reverse drive platform rotate switch, the platform should rotate switch, the light shall lit and the drive fucntion should counterclockwise. resume. Jib up/down switch-TB20EJ Plus & TB22EJ Plus only © Oct 2021 6-10 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 55 Should the chassis tillt indicator light come on when indicator light should be on. the boom is raised or extended, retract and lower the boom to stowed position. Heavy load indicator light Platform tilt indicator light CAUTIO TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 6-11 © Oct 2021...

  • Page 56: Testing The Drive Speed

    POSITION MAX DRIVE SPEED the platform controller. Operating 1.1km/h (0.68mph) 5. Move the corresponding boom function switch on the platform controller to lower the platform. Non-operating 4.8km/h (3 mph) © Oct 2021 6-12 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 57: Testing The Tilt Protection System

    3. The tilt alarm sounds and the chassis tilt indicator light flashes, no function is restricted. 6. TB18E Plus：when the boom extends to the farthest(the ground display reads 15.45m/50ft 8in of 4. With the machine in operating position, flip the level boom length), the buzzers at the ground and switch to exceed 5°in X (left-to-right)/Y (front-to-...

  • Page 58: Testing The Weighing System

    PRE-OPERATION FUNCTION TEST 6. TB18E Plus：when the boom extends to the 2. Pull out the emergency stop button at the ground farthest(the ground display reads 14.1m/46ft 3in of controls to ON position. boom length), the buzzers at the ground and 3.
  • Page 59 All motion functions will not resume until the excessive load is removed. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 6-15 © Oct 2021...
  • Page 60 PRE-OPERATION FUNCTION TEST This Page Intentionally Left Blank © Oct 2021 6-16 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 61: Operating The Machine

    Check the work site. tipping. • Check the safety decals/ nameplate on the machine. • Only use the machine according to the instructions in this manual and for its intended purpose. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 62 Boom kept horizontal; Turntable rotated 90°; The machine will tip over in the direction as indicated by the arrow if overloaded or operated beyond the limits of the maximum operating slope. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 63: Emergency Stop

    • Push the power disconnect switch on the left side of chassis to OFF, the system power will be disconnected and all functions will get inoperative. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 64: Emergency Lowering

    When the platform or boom is caught overhead： If the platform or boom becomes jammed or snagged in overhead structures or equipment, rescue all people in the platform before freeing the machine. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 65: Operation From Ground

    4. Move the enable switch and meanwhile move upwards/downwards the platform level switch to level up or down the platform. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 66: Operation From Platform

    1. Turn the Ground/Platform select switch on the side of the thumb rocker switch on top of the handle to ground controller to Ground. steer left/right. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 67: Driving On A Slope

    3. Slope grade= H/L x 100%. Maximum gradeability： NOTICE Uphill：35%/19° The machine must not drive for over 2min on the maximum permissible slope grade to prevent the tires running suspended. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 68: Charging The Battery

    -20℃~45℃. Charging the lead acid battery requiring maintenance 1. Disconnect the cables wiring the battery to the machine. 2. Remove the vent cap of the lead acid battery. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 69 3. Disconnect the charger from the AC circuit. 4. ire the battery to the machine, and the machine is ready for use. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 70 OPERATING THE MACHINE This Page Intentionally Left Blank © Oct 2021 7-10 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 71: Transporting And Lifting The Machine

    • Lock the wheels of the machine after it has been installed to prevent the machine from rolling. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 72: Lifting The Machine With A Crane

    （12.4 in） （7.72in） 1124 mm 1143 mm 1166 mm 1110 mm （44.3 in） （45.0 in） （45.9 in） （43.7 in） 6. Lift the machine as shown in the figure below. Figure 8-2 © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 73: Transporting The Machine

    Follow these requirements when transporting the the air. machine by truck or trailer: Figure 8-3 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 74 TRANSPORTING AND LIFTING THE MACHINE This Page Intentionally Left Blank © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 75: Maintenance

    Conduct a quarterly inspection on machines that repair the machine and must follow the procedures have been out of service for a period lasting longer as stated in operation manual and maintenance than three months. manual. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...

  • Page 76: Following Amaintenance Schedule

    A+B+C hours in the box marked "inspection". Select the appropriate inspection procedure based on the Every year or every 1000 hours A+B+C+D inspection type. © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 77 B-5 Inspect Emergency Lowering B-6 Inspect Air filter of Hydraulic Tank B-7 Replace High-Pressure Filter Element B-8 Test Drive Speed B-9 Inspect Length and Angle Sensors B-10 Inspect Tilt Protection TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 78 D-1 Replace Drive Reducer Gear Oil D-2 Replace Slewing Reducer Gear Oil D-3 Replace Hydraulic Oil D-4 Replace Hydraulic Tank Suction Filter D-5 Inpsect Boom Wear Pads User Inspector Signature © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 79 MAINTENANCE REPAIR & INSPECTION REPORT Inspector Date Inspector Title Inspector Company TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 80 MAINTENANCE This Page Intentionally Left Blank © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 81: Decals/Nameplates Inspection

    Do not operate the engine if there are missing or badly worn safety labels. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-1 © Oct 2021...

  • Page 82: Decals/Nameplates(Gb)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES(GB) (36) © Oct 2021 10-2 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 83 101048100014 Decal-Rated load 340kg 105021100002 104011100017 Decal-Footswitch 104011100019 Decal-Crush hazard Decal-Tipping hazard 105021100003 Decal-Tipping hazard 103007103002 Yellow-black caution stripe 216060000002 104011100021 Decal-Crush hazard 104011100012 Decal-Fall hazard Decal-Charge voltage 101023100012 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-3 © Oct 2021...
  • Page 84 Decal-No smoking or fires 101012100001 Nameplate-GB 105001100057 215050000001 Blind rivet 3×8-ZnD Decal-Range of motion TB18E Plus 114001103008 Decal-Range of motion TB20EJ Plus 114002103007 Decal-Range of motion TB22EJ Plus 114006103000 © Oct 2021 10-4 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 85: Decals/Nameplates(Ce-Metric)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES(CE-METRIC) Tel:0086-731-87116222 www.sinoboom.com (36) TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-5 © Oct 2021...
  • Page 86 101016100030 Decal-Rated load 340kg 105021100002 104011100017 Decal-Footswitch 104011100019 Decal-Crush hazard Decal-Tipping hazard 105021100003 Decal-Tipping hazard 103007103002 Yellow-black caution stripe 216060000002 104011100021 Decal-Crush hazard 104011100012 Decal-Fall hazard Decal-Charge voltage 101012100014 © Oct 2021 10-6 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 87 Decal-No smoking or fires 101012100001 Nameplate-CE(TB) 105001100056 215050000001 Blind rivet 3×8-ZnD Decal-Range of motion TB18E Plus 114001103008 Decal-Range of motion TB20EJ Plus 114002103007 Decal-Range of motion TB22EJ Plus 114006103000 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-7 © Oct 2021...

  • Page 88: Decals/Nameplates(Ce-Imperial)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES(CE-IMPERIAL) Tel:0086-731-87116222 www.sinoboom.com (36) © Oct 2021 10-8 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 89 101016100030 Decal-Rated load 340kg 105021100002 104011100017 Decal-Footswitch 104011100019 Decal-Crush hazard Decal-Tipping hazard 105021100003 Decal-Tipping hazard 103007103002 Yellow-black caution stripe 216060000002 104011100021 Decal-Crush hazard 104011100012 Decal-Fall hazard Decal-Charge voltage 101012100014 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-9 © Oct 2021...
  • Page 90 Decal-No smoking or fires 101012100001 Nameplate-CE(TB) 105001100056 215050000001 Blind rivet 3×8-ZnD Decal-Range of motion TB18E Plus 114001103008 Decal-Range of motion TB20EJ Plus 114002103007 Decal-Range of motion TB22EJ Plus 114006103000 © Oct 2021 10-10 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...

  • Page 91: Decals/Nameplates(Csa)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES(CSA) (37) TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-11 © Oct 2021...
  • Page 92 101016100030 Decal-Rated load 340kg 105046103003 104011100017 Decal-Footswitch 104011100019 Decal-Crush hazard Decal-Tipping hazard 105021100003 Decal-Tipping hazard 103007103002 Yellow-black caution stripe 216060000002 104011100021 Decal-Crush hazard Decal-Annual inspection 101040103015 104011100012 Decal-Fall hazard © Oct 2021 10-12 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 93 Decal-No smoking or fires 101012100001 Nameplate-CSA(TB) 105045103003 215050000001 Blind rivet 3×8-ZnD Decal-Range of motion TB18E Plus 114001103008 Decal-Range of motion TB20EJ Plus 114002103007 Decal-Range of motion TB22EJ Plus 114006103000 Decal-Operating instructions 105029103023 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-13 © Oct 2021...

  • Page 94: Decals/Nameplates(Ansi)

    DECALS/NAMEPLATES INSPECTION DECALS/NAMEPLATES(ANSI) (37) © Oct 2021 10-14 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 95 101016100030 Decal-Rated load 340kg 105046103003 104011100017 Decal-Footswitch 104011100019 Decal-Crush hazard Decal-Tipping hazard 105021100003 Decal-Tipping hazard 103007103002 Yellow-black caution stripe 216060000002 104011100021 Decal-Crush hazard Decal-Annual inspection 101040103015 104011100012 Decal-Fall hazard TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual 10-15 © Oct 2021...
  • Page 96 Decal-No smoking or fires 101012100001 Nameplate-ANSI(TB) 103007103000 215050000001 Blind rivet 3×8-ZnD Decal-Range of motion TB18E Plus 114001103008 Decal-Range of motion TB20EJ Plus 114002103007 Decal-Range of motion TB22EJ Plus 114006103000 Decal-Operating instructions 105029103023 © Oct 2021 10-16 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 97 Electrocution hazards Electrocution hazards Tip-over hazards-Avoid Tip-over hazards-Avoid Tip-over hazards- on platform on the ground and uneven ground uneven ground Never use machine platform during strong, gusty wind TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 98 The side force Electrocution hazards Fast/high speed Slow/low speed Horn Improve point Lashing points Tire to ground load Hydraulic oil filler Platform carrying capacity Do not use damaged Tool or weight cords © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 99 3. Record the inspection results. If any inspection results are "NO", the machine must be stopped and re- inspected after repair is completed and marked in the box marked "inspection". TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 100 DECALS/NAMEPLATES INSPECTION This Page Intentionally Left Blank © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 101 B-2 Inspect Rim ,Tire and Fasteners B-3 Inspect Hydraulic Oil B-4 Inspect Electrical Wiring B-5 Inspect Emergency Lowering B-6 Inspect Air filter of Hydraulic Tank B-7 Replace High-Pressure Filter Element TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 102 Good Damage or Description Been Repaired Condition Malfunction D-1 Replace Drive Reducer Gear Oil D-2 Replace Slewing Reducer Gear Oil D-3 Replace Hydraulic Oil D-4 Replace Hydraulic Tank Suction Filter © Oct 2021 TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual...
  • Page 103 "inspection". Select the appropriate inspection procedure based on the inspection type. Select the appropriate inspection procedure based on the inspection type. TB18E Plus&20EJ Plus&20E Plus&22EJ Plus Operation Manual © Oct 2021...
  • Page 104 Solution s Alw ays For B et t er A ccess Solution s Always for Better Access Solutions AS/N ZS Hunan Sinoboom Intelligent Equipment Co., Ltd. 长沙市宁乡高新技术产业园区金洲大道东 128 号 No.128, East Jinzhou Avenue, Ningxiang High-tech Industrial Park, Changsha, Hunan, China 市宁乡高新技术产业园区金洲大道东...

This manual is also suitable for:

Tb590e plusTb20ej plusTb660ej plusTb20e plusTb680e plusTb22ej plus ... Show all
