Summary of Contents for Trek Farley Carbon 9.6 2023
- Page 1 2023 Farley Carbon 9.6 SERVICE MANUAL...
- Page 2 Notice: Measurements of actual tires may vary. Always verify there is sufficient clearance between the tire and the frame. Improper tire size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tire. Maximum insertion S...
- Page 3 2023 Carbon Farley 9.6 Front and rear dropouts Sliding rear dropout For information about adjusting the sliding dropout, watch the video How to: Adjust Horizontal Sliding Dropouts on Trek’s You- Tube channel. 10 Nm 23 Nm 23 Nm Front dropout Switch lever —...
- Page 4 2023 Carbon Farley 9.6 Routing — 1x 0.7 Nm No housing 0.7 Nm Fasteners, M3 x 12 mm — W318529 Dropper post housing Note: Apply anti-seize or waterproof grease. Rear brake hose Frame plug —...
- Page 5 2023 Carbon Farley 9.6 Routing — Optional 2x 0.7 Nm 0.7 Nm No housing 0.7 Nm 5 Nm Front derailleur housing Cable exit guides — W439610 Dropper post housing Guide tubes — W333080 Fasteners, M3 x 12 mm —...
-
Page 6: Frame Guards
2023 Carbon Farley 9.6 Frame guards 2 Nm Low, direct-mount front derailleur plate cover — W516639 Downtube adhesive guard — W519509 Use isopropyl alcohol to clean the frame surface where the guard is attached. Wait for the alcohol to dry before apply- ing the guard. - Page 7 2023 Carbon Farley 9.6 Fork and frame mounts 5 Nm Mounts for: 3 and 4 . 5 Nm Carbon fork — 5311796 Screws, stainless steel, M5 x 16 mm — W5252789 Water bottle bolts, stainless steel, M5 x 0.8 mm — W598484 Water bottle nutsert plugs —...
- Page 8 2023 Carbon Farley 9.6 Front rack (available separately) 6 Nm Farley front rack — 44354 Search trekbikes.com to find the colour-matched part for your bike. Bolts, M6 x 16 mm, with washers — W582658...
-
Page 9: Specifications
Notice: Measurements of actual tyres may vary. Always verify that there is sufficient clearance between the tyre and the frame. Improper tyre size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tyre. Maximum insertion...
