- Page 1 User’s Manual Monochrome LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
- Page 2 This is a monitor intended for use in a medical setting. Copyright© 2005 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
-
Page 3: Table Of Contents
English TABLE OF CONTENTS PRECAUTIONS ................... 4 1. INTRODUCTION ..................9 1-1. Features ......................9 1-2. Package Contents..................9 1-3. Controls & Connectors ................10 2. CABLE CONNECTION ................. 12 3. ScreenManager ..................15 3-1. How to use the ScreenManager ..............15 3-2. ScreenManager Adjustments and Settings...........16 3-3. -
Page 4: Precautions
English PRECAUTIONS IMPORTANT! This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below). - Page 5 English WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
- Page 6 English WARNING To avoid danger of suffocation, keep the plastic packing bags away from babies and children. Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
- Page 7 English WARNING When attaching an arm stand, please refer to the user’s manual of the arm stand and install the unit securely with the enclosed screws. Not doing so may cause the unit to become unattached, which may result in injury or equipment damage.
- Page 8 English CAUTION Do not touch the plug with wet hands. Doing so may result in electric shock. Use an easily accessible power outlet. This will ensure that you can disconnect the power quickly in case of a problem. Periodically clean the area around the plug. Dust, water, or oil on the plug may result in fire.
-
Page 9: Introduction
English 1. INTRODUCTION Thank you very much for choosing an EIZO Monochrome Monitor. 1-1. Features DVI (p.31) Digital input (TMDS (p.31)) compliant G31-G: Resolution: 3M pixels (1536 dots × 2048 lines) Horizontal scanning frequency: 92.86 - 96.72 kHz Vertical scanning frequency: 60 Hz G51-BLG/G51-CLG: Resolution: 5M pixels (2048 dots ×... -
Page 10: Controls & Connectors
English 1-3. Controls & Connectors Front (G51-BLG/G51-CLG is given as an example.) Control Panel ® (1) ScreenManager Main Power Switch Power Indicator Green Operation Orange Power saving Flashing orange (2 times for each) Power save mode Flashing orange slowly Power is off (Main power is on) Power off Power Button Control Buttons (Up, Left, Right, Down) - Page 11 English Rear (G51-BLG/G51-CLG is given as an example.) (10) (11) (12) (13) (14) (15) Side (7) Height Adjustable Stand (Detachable) Security Lock Slot USB Port (1 Upstream) (10) USB Port (2 Downstream) (11) Serial Port (Mini DIN 6 pin) (for factory use) (12) Serial Port (D-Sub 9 pin) (for factory use) (13)
-
Page 12: Cable Connection
English 2. CABLE CONNECTION NOTE Be sure that the power switches of both the PC and the monitor are OFF. Please refer to the manual of the PC also to connect the monitor. Pivot the panel in the counter-clockwise to fix in portrait position. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC. - Page 13 English NOTE When housing the cables into the cable holder, lead them to the cable entrance side and pinch the projection to open the cable entrance. The cables are recommended to lead with slight sag for the smooth motion of the stand.
- Page 14 English Turn on the monitor’s Power Button and then switch on the PC’s power. The monitor’s power indicator will light up (green). If an image does not appear, refer to the “6. TROUBLESHOOTING” (p.24) for advice. Whenever finished, turn off the PC and the monitor. NOTE Adjust brightness of the screen depending on the brightness of your environment.
-
Page 15: Screenmanager
English 3. ScreenManager 3-1. How to use the ScreenManager Control Buttons Up, Left, Right, Down ScreenManager Main Menu Enter Button Entering the ScreenManager Press the Enter Button once to display the main menu of the ScreenManager. Making Adjustments and Settings (1) Select the desired sub menu icon using the Control Buttons and press the Enter Button. -
Page 16: Screenmanager Adjustments And Settings
English 3-2. ScreenManager Adjustments and Settings The following table shows all the ScreenManager’s adjustment and setting menus. Main menu Sub menu Reference Screen Brightness Control the brightness for the entire screen. Unlock Unlock the lock. (p.18) LUT Setting Default / Normal / Custom Set the LUT (Look-up table) (p.31) setting. -
Page 17: Useful Functions
English 3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Settings in the ScreenManager. Unlocked function Adjustment of brightness by the Control Buttons. [To lock] (1) Switch off the monitor’s power by the power button on the control panel. (2) Press on the Enter Button while switching on the monitor’s power. - Page 18 English Unlock Function after Calibration The calibration is available when using the specified optional calibration kit (p.30). After the calibration, the functions below are automatically locked. Locked function Brightness adjustment (including the adjustment by Left and Right Buttons on the front panel) LUT Setting Unlock function is available by using ScreenManager.
-
Page 19: Power-Save Setup
English 3-4. Power-save Setup The <PowerManager> menu in the ScreenManager enables to set the power-save setup. NOTE Do your part to conserve energy, turn off the monitor when you are finished using it. Disconnecting the monitor from the power supply is recommended to save energy completely. -
Page 20: Making Use Of Usb (Universal Serial Bus)
Required system environment PC with build-in USB ports or another USB hub connected to the USB compliant PC EIZO USB Cable (MD-C93) NOTE The USB hub function may not work properly depending on the PC, OS or peripherals. - Page 21 English After setting up, the monitor’s USB hub is available for connecting USB compliant peripherals to the downstream ports of the monitor. Connecting Examples Monitor Mouse Keyboard Printer Downstream Ports: Printer Keyboard Downstream Ports Connect the cables from USB compliant peripherals such as a mouse, keyboard, etc.
-
Page 22: Attaching An Arm
English 5. ATTACHING AN ARM The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm or stand to the LCD monitor. NOTE If you will use the arm or stand of other companies, confirm the followings to the arm or stand maker before selecting. - Page 23 English Attach an arm stand to the LCD monitor securely. Arm-stand 4 Mounting Screws: M4 × 10 (mm) Ni/Fe 5. ATTACHING AN ARM...
-
Page 24: Troubleshooting
English 6. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. No picture problems See No.1 - No.2 Imaging problems See No.3 - No.6 Other problems See No. 7 - No.8 USB problems See No.9 - No.10... - Page 25 If the problem is solved by doing this, contact an EIZO dealer. The Power Button of the Apple keyboard does not operate if it is connected to the EIZO USB Hub. Please connect the keyboard directly with the PC. Refer to the instruction of the PC for details.
-
Page 26: Cleaning
English 7. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. -
Page 27: Specifications
English 8. SPECIFICATIONS G31-G LCD Panel 53 cm (20.8 inch), TFT Monochrome LCD panel Glare Panel Hard Coating 3H, Response Time: approx. 50 ms Viewing Angle Horizontal: 170 , Vertical: 170 (CR 10) Dot Pitch 0.207 mm Horizontal Scan Frequency 92.86 ~ 96.72 kHz (only exclusive timing supported) Vertical Scan Frequency 60 Hz (only exclusive timing supported) - Page 28 English G51-BLG/G51-CLG LCD Panel 54 cm (21.3 inch), TFT Monochrome LCD panel Glare Panel, Hard Coating 3H, Response Time: approx. 100 ms Viewing Angle Horizontal: 170 , Vertical: 170 (CR 10) Dot Pitch 0.165 mm Horizontal Scan Frequency 99.9 ~ 107.9 kHz (only exclusive timing supported) Vertical Scan Frequency 47.06 ~ 53.06Hz (only exclusive timing supported) Resolution...
- Page 29 English Dimensions G31-G mm (inches) 325.5(12.8) FRONT SIDE G51-BLG/G51-CLG FRONT SIDE 8. SPECIFICATIONS...
- Page 30 45 seconds Orientation Portrait LUT Level 3061 Language English Optional Calibration Kit EIZO RadiCS GX2 Pin Assignment DVI-D Connector Signal Signal Signal 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21...
-
Page 31: Glossary
Resolution The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. The EIZO G31-G display panel consists of 1536 horizontal pixels and 2048 vertical pixels, and the G51-BLG/G51-CLG consists of 2048 horizontal pixels and 2560 vertical pixels. - Page 32 English MEMO MEMO...
- Page 33 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord...
