- Page 1 重要 ご使用前には必ず本取扱説明書をよくお読みになり、正しくお使いくださ い。この取扱説明書は大切に保管してください。 Important Please read this User’s Manual carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference.
- Page 2 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
- Page 4 VESA is a registered trademark or a trademark of the Video Electronics Standards Association in the United States and other countries. EIZO, the EIZO Logo, RadiCS, RadiForce, RadiNET and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries.
-
Page 5: Precautions
PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. •... - Page 6 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
- Page 7 WARNING The equipment must be connected to a grounded main outlet. Not doing so may cause in fire or electric shock. Use the correct voltage. • The unit is designed for use with a specific voltage only. Connection to another voltage than specified in this User’s Manual may cause fire, electric shock, or equipment damage.
- Page 8 CAUTION Firmly fix the half-silvered mirror and attach the fall prevention cap. If the half-silvered mirror falls, it may result in injury. When raising the half-silvered mirror, make sure that it is locked. Never put your head under the upper monitor. To view a two-dimensional image, raise the half-silvered mirror and firmly lock it.
-
Page 9: Notice For This Monitor
Notice for this monitor This product is intended to be used in displaying and viewing digital images including those of digital mammography for review and analysis by trained medical practitioners. Caution: Federal law (USA) restricts this device to sale by or on the order of a physician. This product has been adjusted specifically for use in the region to which it was originally shipped. - Page 10 Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet, panel, half-silvered mirror, or polarized glasses and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet, panel, half-silvered mirror, or polarized glasses.
-
Page 11: Table Of Contents
CONTENTS Cover ............. 1 PRECAUTIONS ..........3 Notice for this monitor ..........7 CONTENTS ............. 9 Chapter 1 Introduction ........10 1-1. Package Contents ..........10 1-2. Utility Disk ............10 ● Disk contents and software overview ....10 ● To use RadiCS LE or ScreenManager Pro for Medical ..............10 1- 3. -
Page 12: Chapter 1 Introduction
• Please keep the packaging box and materials for future movement or transport of the monitor. 1-2. Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the software programs. -
Page 13: Basic Operation And Functions
1- 3. Basic Operation and Functions 13 14 Switches input signals for display. switch Allows you to switch the CAL Switch mode. switch Cancels the adjustment/setting or exit the adjustment menu. switch • Chooses an adjustment item or increases/decreases adjusted values for advanced adjustments using the Adjustment menu. -
Page 14: Chapter 2 Basic Operations
For more information about the compatibility between this product’s DisplayPort and graphics boards, please refer to our website. http://www.eizo.com • Turn off the monitor and PC after using them. -
Page 15: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. Problems Possible cause and remedy No picture • Check whether the power cord is connected correctly. • Power indicator does not light. • Turn off the main power, and then turn it on again a few minutes later. -
Page 16: Chapter 4 Specifications
Chapter 4 Specifications Dimensions 524.0 mm (20.6 inch) × 734.0 mm (28.9 inch) × 566.0 mm (22.3 inch) Mass Approx. 24.5 kg (54 lbs.) Environmental Temperature Operating : 0 °C - 35 °C (32 °F - 95 °F) Conditions Transportation/Storage: -20 °C - 60 °C (-4 °F - 140 °F) Humidity Operating: 20% - 80% R.H. - Page 17 EIZO “RadiCS UX1” Ver.3.5.1 or later Software Kit Network QC Management EIZO “RadiNET Pro” Ver.3.5.1 or later Software Signal Cable PP200 Polarized Glasses (paper) PLP-1 Refer to Web site of EIZO Corporation for the latest information about supported graphics card (http://www.eizo. com). Chapter 4 Specifications...
- Page 18 User's Manual and the Warranty Period for the brightness is limited to five (5) years from the date of purchase of the Product subject to the usage time being less than or equal to 30,000 hours. EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty.
- Page 19 EMC Information Essential performance of RadiForce series is to display images and operate functions normally. CAUTION The RadiForce series requires special precautions regarding EMC and need to be installed, put into service and used according to the following information. Do not use any cables other than the cables that provided or specified by us. Using other cables may cause the increase of emission or decrease of immunity.
- Page 20 Guidance and manufacturer’s declaration - electromagnetic immunity The RadiForce series is intended for use in the electromagnetic environment specified below. The customer or the user of the RadiForce series should assure that it is used in such an environment. Immunity test IEC/EN60601 test Compliance level Electromagnetic environment - guidance...
- Page 21 Recommended separation distances between portable and mobile RF communications equipment and the RadiForce Series The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the RadiForce series can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series as recommended below, according to the maximum output power of the communications equipment.
- Page 22 关于电子信息产品污染控制标识 本标识根据「电子信息产品污染控制管理办法」 ，适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在自制造日起算的年限内，不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr（VI） ） （PBB） （PBDE） 印刷电路板 × ○ ○ ○ ○ ○ 机箱 ○ ○ ○ ○ ○ ○ 液晶显示器 × × ○ ○...
- Page 23 Phone: +86 512 6252 0100 Fax: +86 512 6252 1508 〒924-8566 石川県白山市下柏野町 153 番地 Siemensallee 84, 76187 Karlsruhe, Germany Phone: +49 721 20321 0 Fax: +49 721 20321 471 http://www.eizo.com http://www.eizo.co.jp 4th Edition-September, 2013 Printed in Japan. 00N0L610D1 Copyright © 2010-2013 EIZO Corporation All rights reserved. (U.M-GS521-ST)
