1.6

Disclaimer

Please not that we cannot accept any liability for damages arising from failure to observe the instructions.
Gardner Denver Schopfheim GmbH does not assume liability for the following cases:
• Not intended use
• Not complying with these instructions
• Nonobservance of all documents and specifications belonging to the overall documentation
• Erection, operation, maintenance and repair by insufficiently qualified staff
• Modification or removing of the part or serial number
• Using spare parts that have not been approved by Gardner Denver Schopfheim GmbH
• Unauthorised modifications to the machine or the accessories supplied by Gardner Denver Schopfheim
GmbH
Please, also consider that repairs are only allowed to be done by authorised workshops using original spare
parts; otherwise our guarantee will expire.
1.7

Specialist terms and meaning

Term
Machine
Motor
Vacuum pump
Claw
Suction capacity
Final pressure (abs.)
Permanent vacuum
Noise emission
Abbreviation
Fig.
Tab.
C-VLR
CD
XD
Explanation
Pump and motor combination ready for connection
Pump drive motor
Machine for creating underpressure (vacuum)
Design or operating principle of the machine
Vacuum pump, volumetric flow related to the condition in the inlet con-
nection, specified in m
The maximum vacuum that a pump reaches while the inlet opening is
closed, displayed as absolute pressure in mbar (abs.)
Vacuum or the inlet pressure range, at which the pump operates in con-
tinuous operation.
The permanent vacuum or inlet pressure is ≥ than the final vacuum and <
than the atmospheric pressure.
Noise emitted at a specific loading state indicated as a numeric value,
sound pressure level dB(A) as per EN ISO 3744.
Meaning
Figure
Table
Model description of the vacuum pump
Pump in standard design
Pump with corrosion-protective coating
/h
3
