- Page 1 ASSEMBLY INSTRUCTIONS : 30 IN JAVA STOOL W/WOOD SEAT Description : S-193 Item No. ITEM NO.: S-193 Printed in Vietnam REVISED MAY 18, 2018 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-193 Printed in Vietnam REVISED MAY 18, 2018 - 2 -...
- Page 3 Long Screw (M6 x 80mm) (M4 x 50mm) Short Screw Lock Washer (M4 x 35mm) (6.5 x11mm) Flat Washer Allen Key (6.5 x19mm) (M4 x 30mm x 110mm) ITEM NO.: S-193 Printed in Vietnam REVISED MAY 18, 2018 - 3 -...
- Page 4 Attach front stretcher (G) between front legs, and then attach side stretchers (E) and (F) to front and back legs with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: S-193 Printed in Vietnam REVISED MAY 18, 2018...
- Page 5 STEP 3 Attach seat (C) to top of seat frame (B) with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-193 Printed in Vietnam REVISED MAY 18, 2018 - 5 -...
