- Page 1 ASSEMBLY INSTRUCTIONS : 24 IN VINEYARD STOOL Description : S-142 Item No. ITEM NO.: S-142 Printed in Vietnam REVISED APR 27, 2018 - 1 -...
- Page 2 Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-142 Printed in Vietnam REVISED APR 27, 2018 - 2 -...
- Page 3 Long Screw (M6 x 80mm) (M4 x 50mm) Short Screw Lock Washer (M4 x 35mm) (6.5 x11mm) Flat Washer Allen Key (6.5 x19mm) (M4 x 30mm x 110mm) ITEM NO.: S-142 Printed in Vietnam REVISED APR 27, 2018 - 3 -...
- Page 4 Allen key (8). Attach front stretcher (C) between front legs, and then attach side stretchers (D) to front and back legs with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: S-142 Printed in Vietnam REVISED APR 27, 2018...
- Page 5 STEP 3 Attach the seat (F) to top of the seat frame (B) with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-142 Printed in Vietnam REVISED APR 27, 2018 - 5 -...
