Summary of Contents for Totevision LCD-566T
-
Page 2: The Remote Control
The Remote control The following figure shows a clear layout of the remote control. Calling up a Menu display Press the MENU button on the remote control to call up the various menu displays. Then, use the Channel Up/Down buttons to select which item you want to access or adjust. Display color will be changed for the selected item. - Page 3 CH AUTO SCAN CH DELETE CH MANUAL SELECT TV MODE Select INPUT select TV/AV Mirror Left/Right Display Up/Down Select Adding and Skipping unwanted TV Channel If you want to exclude any channel from the memory, press “DEL” button on the remote control.
-
Page 4: Automatic Power Off
Dot Pitch: 0.120mm(H) x 0.360mm(V) Brightness rating: 200 cd/m Number of Pixels: 224,640 Dots Pixel Configuration: Stripe Audio output: 2W(RMS) Power requirements : 11VDC- 27VDC Power consumption : 10 Watts 1319 Dexter Ave. N. Suite 020 Seattle, WA. 98109 Tel : (206)623-6000 www.totevision.com...
