- Page 1 Dryer Model: MDV160-V042/F01-SA Service Manual Note： Before service the unit, please read this manual first. Contact with your service center if meet problem...
-
Page 2: Table Of Contents
Contents 1 PRECAUTION………………….………………..……………………………………………………….3 1.1 Safety Precautions 1.2 Servicing Precaution 1.3 Cautions For Safety 2 UNPACKING WAYS OF MAIN PARTS…………………………………………………………..5 3 MALFUNCTIONS CODES AND EXPLANATIONS …………………………………...…..13 4 TROUBLESHOOTING………………………………………………………………………..………14 Will not start or run Motor runs/ tumbler will not turn Runs a few minutes and then stops Blows fuses or trips circuit breaker Will not heat (motor runs) Improper drying clothes wrinkled Rough texture long dry time... -
Page 3: Precaution
1 Precaution When performing troubleshooting and part replacement during servicing, note the following safety precaution. 1-1.Safety Precautions 1-1-1.Use Genuine Parts The components of the Tumble Dryer machine have safety features such as non-combustibility and voltage withstanding. Therefore, always use the same part as suggested by the maker. In particular, be sure to use only designated parts in case of major safety parts identified by the marker. -
Page 4: Cautions For Safety
1 Precaution 1.3 Cautions For Safety • Please observe the following notes for safety. • The symbols indicate as follows. Symbol Meaning Indicates possibility of death or serious injury of a repair technician and a person nearby through the misconducted work, or of a user by a defect of product after the work performed by the technician. -
Page 5: Unpacking Ways Of Main Parts
2 Unpacking Ways Of Main Parts Ordinary Information 1.Please unplug the power cord when you disassemble or maintain the product； 2.Please use the regulation connector lug between the wires as much as possible. Then crimp them firmly by the proper tools and bundle them by the insulating tape; 3.When you plug the wires, please insert the plug to the bottom so it is not easily to be unplugged;... - Page 6 2 Unpacking Ways Of Main Parts Steps of disassembling machine Pictures 1.Remove the control panel 1.1 Remove the screws that is used to fix the control panel; 1.2 Remove the screws on the electrical box; 1.3 Flip the electrical box; 1.4 Pull out the terminals;...
- Page 7 2 Unpacking Ways Of Main Parts Steps of disassembling machine Pictures 5. Take down the tumble assy; 5.1 Remove the screws; 5.2 Take down the belt from the Motor; 5.4 Hold the belt and take down the tumble assy; 6. Remove the heater assy 6.1 Pull out all the terminals;...
- Page 8 2 Unpacking Ways Of Main Parts Steps of disassembling machine Pictures 10. Deleave the Door assy 10.1 Remove all 12 screws around the door. 10.2 Depart the door front and back. 11. Remove the door lock. Take care the slots. 12.
- Page 9 2 Unpacking Ways Of Main Parts Steps of disassembling machine Pictures 14. Take down the Lint Filter 15. Pull out the terminals as shown on the fig. 16. Remove the screws as shown on the fig. 17. Remove the air flow channel assy 18.
- Page 10 2 Unpacking Ways Of Main Parts Pictures Steps of disassembling machine 20. Remove the belt switch. 21. Remove the idle wheel. 22. Remove the motor and fan assy.
- Page 11 2 Unpacking Ways Of Main Parts Pictures Steps of disassembling machine 23. Remove the fan 23.1 the screws that is used to fix the Fixed Sheet Assembly; 23.2 Remove the Fixed Sheet Assembly. 24. Remove the motor. 25. Remove the wheels supporting the drum.
- Page 12 2 Unpacking Ways Of Main Parts display communication TEMP Lamp Heater Door switch Motor Heater...
-
Page 13: Malfunctions Codes And Explanations
3 Malfunctions Codes And Explanations... -
Page 14: Troubleshooting
4 Troubleshooting Problem What To Do ● All wires are hooked up to their corresponding terminals. ● Dryer is plugged in. ● Blown fuse or circuit breaker. ● Door switch functional…door closed. ● Star/Pause button rotary selector dial functional. Will not start or run ●... -
Page 15: Improper Drying Clothes Wrinkled Rough Texture Long Dry Time
4 Troubleshooting Problem What To Do ● Lint filter is not clean. ● Restriction in exhaust. ● Outside exhaust hood damper door stuck closed. ● Exhaust too long, too many elbows, flex ductwork installed. ● Poor intake air available for the dryer. ●... - Page 16 5 Check Point Of Circuit Before repairing, use multimeter to judge circuit stand of fail. Parts picture parameter ● Thermostat 1 resistance < 1Ω - If resistance is infinity, replace Thermostat 1. ● Thermistor resistance 40KΩ @30 ℃ Thermostat 50KΩ @25 ℃ 99KΩ...
-
Page 17: Check Point Of Circuit
5 Check Point Of Circuit Before repairing, use multimeter to judge circuit stand of fail. Parts parameter ● Centrifugal Switch (Motor) Motor... -
Page 18: Service Tools
5 Service Tools... -
Page 19: Appendix
7 Appendix Machine function description, program description, the whole detailed parameter table, fault codes, etc. Please refer to the instructions. Note: The schedule for the reference value. - Page 20 The end!
