30" AND 36" WALL-MOUNT RANGE HOOD
Universal Installation Instructions, Use, & Care Guide
Model:
668 Series
688 Series
63175S
63190S
63175D
63190D
GVBI-30/36S
627-50/90S
649A
680A
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
Revised September 2014
Disclaimer: Item purchased may be slightly different from the manual.
For questions about features, operation/performance parts, accessories or service, call:
1-626-453-0550
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cosmo 668 Series
Summary of Contents for Cosmo 668 Series
- Page 1 30" AND 36" WALL-MOUNT RANGE HOOD Universal Installation Instructions, Use, & Care Guide For questions about features, operation/performance parts, accessories or service, call: 1-626-453-0550 Model: 668 Series 688 Series 63175S 63190S 63175D 63190D GVBI-30/36S 627-50/90S 649A 680A IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE HOOD SAFETY ..............2 INSTALLATION REQUIREMENTS ...........4 Tools and Parts Requirements ...........4 Location Requirements .............4 Installation Dimensions ............5 Ventilation Requirements ............6 Electrical Requirements ............7 INSTALLATION INSTRUCTIONS ..........8 Prepare Location ..............8 Install Range Hood ..............10 Connect Vent System ..............11 Complete Installation ..............12 RANGE HOOD USE .................14 Range Hood Controls ..............15... - Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF A RANGE TOP WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC GREASE FIRE, READ THE FOLLOWING: SHOCK, OR INJURY TO PERSONS, READ THE FOLLOWING: Never leave surface units unattended at high settings. ■...
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENT TOOLS AND PARTS REQUIREMENTS Electrical drill or ratchet driver 1/2” drill bit for drilling pilot holes 1 ¼” drill bit for drilling electrical wiring access hole. Screwdrivers: Philips & Straight blade Pliers Tape measure or ruler and pencil Electrical supplies for wiring Aluminum foils tape and/or duct tape Hammer... -
Page 5: Installation Dimensions
INSTALLATION DIMENSIONS A. Countertop height B. Hood height from ceiling to bottom of the range hood filter surface: D-A-C=B C. 29” (73.66 cm) min. from cooking surface, suggested 31” (78.74 cm) max. D. Ceiling height... -
Page 6: Ventilation Requirements
VENTILATION REQUIREMENTS Venting Method ■ Range hoods must be ventilated to the This canopy hood is factory set for through outdoors, except for non-vented the roof or wall. (recirculating) installations. ■ Do not ventilate the range hood into an attic or other enclosed areas. A 6"... -
Page 7: Electrical Requirements
Calculating Vent System ELECTRICAL Length REQIUREMENTS Observe all governing codes and ordinances. To calculate the length of the system you need, Ensure that the electrical installation is adequate add the equivalent feet (meters) for all vent and in conformance with the National Electrical pieces used in the system. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS PREPARING THE LOCATION It is recommended for the vent system to be installed before hood is installed. ■ Before making cutouts, make sure there is proper clearance within the ceiling or walls for the exhaust ■ vent. Check your ceiling’s height and the maximum hood height available for your ceiling before selecting ■... - Page 9 Vent Cover Bracket Installation Mark the hole’s location. Attach chimney mounting bracket to the wall by using two M5 x 8 screws. A. Central point B. M5 x 8 screw C. Chimney mounting bracket Complete Preparation Determine and make all necessary cuts in the wall for the vent system. Install the vent system before installing the hood.
-
Page 10: Install Range Hood
STEP 1: MOUNTING THE RANGE HOOD After preparing the location, use two or more people, hang the range hood on the two mounting screws (Part A), installed during preparations (Look at page 8), through the mounting slots on the back of hood (Part B1). Excessive Weight Hazard Use two or more people to move and install range hood. -
Page 11: Connect Vent System
STEP 2: CONNECTING VENT SYSTEM COMPLETE INSTALLATION FOR VENTED MODE Install the non-return air flap on top of hood (if removed for shipping) with M5 X 12 screws (Part B). Remove the tape from the air flow flappers. (Part C) A. -
Page 12: Complete Installation
COMPLETE INSTALLATION FOR VENTLESS (RECIRCULATING) MODE IMPORTANT: Do not install the exhaust pipe and disconnect the power Remove the filter panel(s) located at the bottom of the range hood. Locate the motorized fan inside the hood. Attach the carbon filters to both sides of the motorized fan. Twist the carbon filter until it is in the locking position. - Page 13 STEP 3: INSTALL VENT COVERS When using both inner and outer vent covers, push lower cover down onto hood and lift upper cover to ceiling and install with two M5 x 8 screws NOTE: For vented installations, the upper vent cover maybe reversed to hide slots. A.
-
Page 14: Range Hood Use
RANGE HOOD USE The range hood is designed to remove smoke, vapors, and odors. For best results, start the hood before cooking. After, the cooking process is complete, allow the range hood to run for several minutes to completely clear all the smoke and odors from the kitchen. A. -
Page 15: Range Hood Controls
RANGE HOOD CONTROLS Operating the lights The On/Off light button controls both lights. Press once for “ON” and again for “OFF”. Operating the blower The “Speed” button turns the fan on and controls the fan speed and sound level for quiet operation. The speed can be changed anytime during the fan operation by pressing the desired blower speed button. -
Page 16: Range Hood Care
RANGE HOOD CARE Cleaning IMPORTANT: Clean the hood and panel filters frequently according to the following instructions. Replace the panel filters before operating hood. Exterior Surfaces To avoid damage to the exterior surface, do not use steel wool or soap-filled scouring pads. Always wipe dry to avoid water marks. -
Page 17: Replacement
Non-Vented (recirculating) Installation Filters: The carbon filter is not washable. It should last up to 6 months with normal use. For replacement, please visit our website www.shoprangehoods.com Replacing the LED/Halogen light Turn off the range hood and allow the LED/Halogen to cool. To avoid damage or decreasing the life of the new bulb, do not touch bulb with bare fingers. -
Page 18: Trouble Shooting
TROUBLE SHOOTING Potential Effect of Potential Cause(s) Recommended Action(s) Failure Lamp does not turn Electronic Control a) Pressing any key the LCD lights up and does not work. Due to icons are in place? Over Voltage Yes, Proceed with the following diagnostic sequence No, Replace the control and user interface. - Page 19 - Hold and press main connectors attached in the white plastic. - Push inwards the motor/lamp connectors until the locking system on connectors is well attached. 5) Connect hood to power supply and verify. The blower is Filters are dirty 1) Verify that the grease and/or charcoal too noisy filters are clean.
-
Page 20: Warrenty & Services
SHOPRANGEHOODS.COM MAJOR APPLIANCE WARRANTY LIMITED WARRANTY For three year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or furnished with the product, Www.shoprangehoods.com will pay for Factory Specified Parts. This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in the country in which it was purchased.
