- Page 1 User’s Manual Monochrome LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
- Page 2 Copyright© 2006 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
-
Page 3: Table Of Contents
English TABLE OF CONTENTS PRECAUTIONS ................4 1. INTRODUCTION ..................9 1-1. Features ......................9 1-2. Package Contents..................9 1-3. Controls & Connectors ................10 2. CABLE CONNECTIONS............... 12 2-1. Before Connecting ..................12 2-2. Cable Connection ..................12 3. MENUS & FUNCTIONS ................ 15 3-1. -
Page 4: Precautions
English PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. •... - Page 5 English WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
- Page 6 English WARNING To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock. The equipment must be connected to a grounded main outlet. Not doing so may result in fire or electric shock. Use the correct voltage.
- Page 7 English WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal which leaks from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly.
- Page 8 English LCD Panel The screen may have defective pixels. These pixels may appear as slightly light or dark area on the screen. This is due to the characteristics of the panel itself, and not the product. The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker, please contact your dealer.
-
Page 9: Introduction
• USB (Universal Serial Bus) hub support (see p. 23) • Utility software “ScreenManager Pro for Medical”, which enables control of the monitor from a Windows PC with a mouse or keyboard (refer to the EIZO LCD Utility Disk). • Monitor stand adjustable for different heights •... -
Page 10: Controls & Connectors
English 1-3. Controls & Connectors Front ScreenManager main menu CAL Switch menu Control Panel Main Power Switch (2) MODE Mode Switch (3) ENTER Enter Switch Directing Switches (Left, Down, Up, Right) Power Switch Power Indicator Green Operational Orange Power saving Flashing orange slowly Power off (Main power is on) Main Power off... - Page 11 English Side / Rear Side (7) Monitor stand with adjustable height (detachable) Security lock slot DVI-D input connector (10) USB upstream port (x 1) (11) USB downstream ports (x 2) (12) Power connector The LCD monitor can be oriented in the landscape position. (It can rotate clockwise ninety degrees.) By removing the monitor stand, the LCD monitor can be used with the optional arm stand (see p.
-
Page 12: Cable Connections
English 2. CABLE CONNECTIONS 2-1. Before Connecting Before connecting your monitor to the PC, change the display screen settings resolution (see p.33) and frequency in accordance with the charts below. NOTE • When your computer and display support VESA DDC, the appropriate resolution and the refresh rate are set just by plugging your display into the computer without any manual settings. - Page 13 English Connect the signal cable to the DVI-D input connector on the rear of the monitor and to the video output connector on the PC. After connecting, secure the cable connectors with the attached screw-in fasteners. Signal cable FD-C39 Power cord Signal Cable Connector Signal cable (FD-C39)
- Page 14 English Connect the other end of the power cord to a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
-
Page 15: Menus & Functions
English 3. MENUS & FUNCTIONS 3-1. ScreenManager Screen adjustments and settings can be performed with the monitor controls. ScreenManager main menu Directing Switches CAL Switch menu Left, Down, Up, Right Enter Switch NOTE • The ScreenManager menu and CAL Switch menu cannot be displayed at the same time. - Page 16 English ScreenManager Menus and Settings. The following table briefly explains each of the menus and settings in the ScreenManager. Main menu Sub menu Explanation Setup Signal Selection See 3-3. Other Useful Functions (p. 18) Mode Preset Mode Brightness See 4-1. Brightness Adjustment (p. 21) Reset PowerManager DVI DMPM...
-
Page 17: Cal Switch Function
English 3-2. CAL Switch Function This function allows you to select the optimal display mode for your display images and adjust the brightness in each mode. CAL Switch Modes Mode Description 1-DICOM Select this option to display images in the DICOM mode (see p. 33). -
Page 18: Other Useful Functions
English 3-3. Other Useful Functions Hardware Rotation This function allows you to rotate the monitor image 90 degrees without using special software or graphics board utilities. [How to set] (1) Shut down the computer if it is running. Also, turn off the monitor by touching the power switch on the control panel. - Page 19 English Mode Preset When CAL Switch mode is selected, the computer can be forced to display only specified modes. Use this function when the display modes are restricted or when the display should not be changed needlessly. [How to set] (1) Select <Mode Preset>...
- Page 20 English Off Timer The off timer function causes the monitor to turn off automatically after a predetermined amount of time has lapsed. This function was created to reduce the afterimages particular to LCD monitors, which appear when the screen is left on for long periods without use.
-
Page 21: Adjustments & Settings
English 4. ADJUSTMENTS & SETTINGS 4-1. Brightness Adjustment The brightness of the entire screen can be set to a desired level. [Procedure] (1) Select <Brightness> in the ScreenManager <Mode> menu. (2) Make adjustments with the Left and Right directing switches. The Left directing switch makes the screen darker, and the Right directing switch makes it brighter. - Page 22 English [Procedure] (1) Set the PC's power saving settings. (2) Select “DVI DMPM” in the <PowerManager> menu. [Power saving system] Monitor Power Indicator Operation Green Power saving / Off mode Power saving Orange [Power Resumption Procedure] • Click the mouse or press a key on the keyboard to return to a normal screen. 4.
-
Page 23: Making Use Of Usb (Universal Serial Bus)
English 5. MAKING USE OF USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected. Required system environment •... - Page 24 Downstream Port ScreenManager Pro for Medical (for Windows) For further details about the “ScreenManager Pro for Medical (for Windows)”, refer to the EIZO LCD Utility Disk. 5. MAKING USE OF USB (Universal Serial Bus)
-
Page 25: Attaching An Arm
English 6. ATTACHING AN ARM The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm or stand to the LCD monitor. NOTE • If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting. -
Page 26: Troubleshooting
English 7. TROUBLESHOOTING If a problem persists even after applying the remedies suggested below, contact an EIZO dealer. • No picture problems → See No.1 ~ No.2 • Imaging problems → See No.3 ~ No.6 • Other problems → See No.7 ~ No.10 •... - Page 27 English Problem Points to check and possible solutions Do you use the screen saver or timer (p.20) Afterimages appear. when displaying the same image for extended periods of time? Afterimages are particular to LCD monitors. Avoid displaying the same image for extended periods of time.
- Page 28 Try connecting the peripheral to another USB operate. downstream port. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) Try executing the following method. - Restarting the PC...
-
Page 29: Cleaning
English 8. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. -
Page 30: Specifications
English 9. SPECIFICATIONS LCD Panel GS310-BL 52.9 cm (20.8 inch), TFT Monochrome LCD panel Anti-Glare Hard Coating 3H, Response Time : 50ms GS310-CL GS310-CLG 52.9 cm (20.8 inch), TFT Monochrome LCD panel Hard Coating 3H, Response Time : 50ms Viewing Angle Horizontal: 170°, Vertical: 170°... - Page 31 Matrox “MED5mp-PPP” 8bit monochrome signal supported • RealVision “VREngine/MD3W” • RealVision “VREngine/CMD3W” Calibration Kit EIZO “RadiCS GX2” Ver.2.3.0 or later EIZO “Clip-On Swing Sensor G1” Network QC EIZO “RadiNET Pro” Ver.2.3.0 or later Management Software Cleaning kit EIZO “ScreenCleaner” 9. SPECIFICATIONS...
- Page 32 English Pin Assignment DVI-D Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 19 20 21 22 23 24 17 18 Pin No. Signal Pin No. Signal Pin No. Signal TMDS Data2- TMDS Data1- TMDS Data0- TMDS Data2+ TMDS Data1+...
-
Page 33: Glossary
Resolution The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. The EIZO GS310-BL/GS310-CL/GS310-CLG display panel consists of 1536 horizontal pixels and 2048 vertical pixels. At a resolution of 1536 x 2048, all pixels are displayed as a full screen. - Page 34 Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
