Schwinn 570T Assembly Manual / Owner's Manual
  1. Manuals
  2. Brands
  3. Schwinn Manuals
  4. Treadmill
  5. 570T
  6. Assembly manual / owner's manual

Schwinn 570T Assembly Manual / Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

This product is compliant with the
applicable CE requirements.
ASSEMBLY MANUAL / OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 570T and is the answer not in the manual?

Questions and answers

Related Manuals for Schwinn 570T

Summary of Contents for Schwinn 570T

  • Page 1 This product is compliant with the applicable CE requirements. ASSEMBLY MANUAL / OWNER’S MANUAL...

  • Page 2: Table Of Contents

    China | © 2016 Nautilus, Inc. | ® indicates trademarks registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Schwinn, the Schwinn Quality logo, Schwinn 570T, Schwinn Connect, Bowflex, Nautilus, and Universal are trademarks owned by or licensed to Nautilus, Inc. Polar...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions.
  • Page 4 • This product contains magnets. Magnetic fields can interfere with the normal use of certain medical devices at a close range. Users may come into proximity of the magnets in the assembly, maintenance, and/or use of the product. Given the obvious importance of these devices, such as a pacemaker, it is important that you consult with your medical provider in connection with the use of this equipment. Please consult the “Safety Warning Labels and Serial Number” section to determine the location of the magnets on this product.
  • Page 5 • Connect this machine to a correctly earthed outlet; consult a licensed electrician for assistance. • Do not operate where aerosol products are being used. • Do not let liquids touch the electronic controller. If it does, the controller must be inspected and tested for safety by an approved technician before it can be used again.

  • Page 6: Safety Warning Labels / Serial Number

    SAFETY WARNING LABELS AND SERIAL NUMBER Product Specification Serial Number WARNING! : keep young children away from this machine at all times. Contact with the moving surface may result in severe friction burns.

  • Page 7: Earthing Instructions

    Earthing Instructions This product must be electrically earthed. If a malfunction occurs, correct earthing decreases the risk of electric shock. The power cord is equipped with an equipment-earthing conductor, and must be connected to an outlet that is properly installed and earthed. The electrical wiring must comply with all applicable local and provincial standards and requirements.

  • Page 8: Specifications

    SPECIFICATIONS Maximum User Weight: 136 kg (300 lbs) Maximum Inclined Deck Height: 43.7 cm ( 17.2 inches ) Assembled Weight: 97.5 kgs (approx. 215 lbs) 146.3 cm Total Surface Area (footprint) of equipment: 17522.4 cm ( 57.6” ) Power Requirements: Operational Voltage: 220V - 240V AC, 50Hz Operating Current: 196 cm Heart Rate Chest Strap:...

  • Page 9: Parts

    PARTS Item Description Item Description Console Assembly Heart Rate Chest Strap Console Backing Upright, Left Upright, Right Handlebar Shroud, Lower Left Handlebar Shroud, Upper Right Handlebar Shroud, Upper Left Handlebar Shroud, Lower Right Tray, Left Base Shroud, Right Tray, Right Safety Key Base Assembly ( Base Shroud, Left...

  • Page 10: Hardware

    HARDWARE / TOOLS / BEFORE ASSEMBLY Item Description Item Description Socket Head Hex Screw, M8x50 Lock Washer, M8 Socket Head Hex Screw, M8x16 Flat Washer, M8 Phillips Head Screw, M5x14 Self Tapping Screw, M4.2x16 Self Tapping Screw, M3.9x16 Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remain- ing Hardware after the proper assembly of your machine. Tools Included 6 mm...

  • Page 11: Assembly

    ASSEMBLY DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as shown in the appropriate work space. 1. Fold the Walking Deck on the Base Assembly Cut the Shipping Strap on the Base Assembly. Make sure that there is safe clearance around, on and above your tread- mill.
  • Page 12 2. Connect the Input/Output (I/O) Cables and Attach the Uprights to Frame Note: Do not crimp cables. Do not fully tighten Hardware until instructed.
  • Page 13 3. Unfold the Walking Deck Slightly push the walking deck forward toward the front of the machine. With your left foot lightly push the top part of the hydraulic lift forward until the locking tube releases and you can pull the walking deck slightly toward the rear of the machine.
  • Page 14 4. Remove the Console Backing from the Console Assembly Note: Dispose of the pre-installed hardware.
  • Page 15 5. Connect the I/O Cables and Attach the Console to Frame Assembly Note: Do not crimp the Cables.
  • Page 16 6. Fold the Walking Deck and tighten ALL Hardware from previous steps 7. Place the Base Shrouds onto the Frame Assembly, and then unfold the Walking Deck Note: Unfold the Walking Deck after the Base Shrouds have been placed onto the Frame Assembly. The Base Shrouds do not use hardware or snap onto the Frame Assembly.
  • Page 17 8. Attach the Upper Handlebar Shrouds to the Frame Assembly NOTICE: The parts have a right (“ R ”) and left (“ L ”) mark to assist with assembly.
  • Page 18 9. Attach the Console Backing to the Frame Assembly NOTICE: Attach the hardware marked below with the ( * ) first, then the hardware with the ( ** ), followed by the remaining hardware.
  • Page 19 10. Attach the Lower Handlebar Shrouds to the Frame Assembly NOTICE: The parts have a right (“ R ”) and left (“ L ”) mark to assist with assembly.
  • Page 20 11. Snap the Trays into the Console Assembly NOTICE: Tray edges should be flush with the face of Console.
  • Page 21 12. Connect the Power Cord and Safety Key to the Frame Assembly Connect this machine to a properly earthed outlet only (see Earthing Instructions). 13. Final Inspection Inspect your machine to ensure that all hardware is tight and components are properly assembled. Be sure to record the serial number in the field provided at the front of this manual.

  • Page 22: Storage And Moving The Machine

    BEFORE YOU START Storage and Moving the Machine The machine can be moved by one or more persons. Use caution when you move the machine. The treadmill is heavy and can be awkward. Make sure that your own physical strength is capable of moving the machine.

  • Page 23: Unfolding The Machine

    Carefully tilt the base frame of the folded treadmill a small distance back on the transport wheels while grasping the support bar. Do not use the Console, handlebars, or lifted walking deck to lift or move the treadmill. Damage to the treadmill can occur.

  • Page 24: Leveling The Machine

    Leveling the Machine The machine needs to be leveled if your workout area is uneven. To adjust: Place the machine in your workout area. 2. A djust the levelers until they all contact the floor. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur.

  • Page 25: Features

    FEATURES USB Port Walking Belt and Deck MP3 Input Dampener Media Tray Hydraulic Lift Speaker Transport Wheel Console Leveler Base Storage Tray Motor Cover Emergency Safety Key Port Uprights Contact Heart Rate (CHR) Sensors Power Switch Ergo Bar AC Inlet Handlebar Telemetry Heart Rate (HR) Receiver (not shown) Heart Rate Chest Strap...

  • Page 26: Console Features

    Console Features The Console provides important information about your workout and lets you control the resistance levels while you exercise. The Console features touch control buttons to navigate you through the exercise programs. Fitness Score Display Goal Display Pacer Icon User Indicator User Placement Lights Display INCLINE SPEED COMPARE 0-15 km/h Button 19.3 USER Button Pre-Set F i t n e s s S c o r e...
  • Page 27 Decrease () button- Decreases the current value, or moves through the options available Right () button- Shifts the currently active segment, and moves through options PROGRAMS button- Selects a category of workout programs Pre-Set Incline buttons- Selects an incline value for the Walking Deck. After pushing a Pre-Set Incline button, push the Incline Enter button within 12 seconds for the Walking Deck to be adjusted to the desired incline.
  • Page 28 Option Guides The Option Guides inform the User where they are in a list of options with the MORE and PREVIOUS Options. If the MORE Options (decrease arrow) is active, then there are additional options that can be viewed by pushing the Decrease () button.

  • Page 29: Bluetooth ® Connectivity With Fitness App

    1. Select the Options tab in the upper left corner of the Software App, and click on “Settings”. 2. Select the “Schwinn Connect” option. Sign in to your account or create a new account. To create a new account, click on the “Create New Account”...
  • Page 30 1. Insert the USB Drive with your workout data into a device connected to the internet. 2. Sign in to the Schwinn Connect™ website at www.schwinnconnect.com, or create a new account. To create a new account, click on the “Create New Account” button.

  • Page 31: Remote Heart Rate Monitor

    Remote Heart Rate Monitor Monitoring your Heart Rate is one of the best procedures to control the intensity of your exercise. Contact Heart Rate (CHR) sensors are installed to send your heart rate signals to the Console. The Console can also read telemetry HR sig- nals from a Heart Rate Chest Strap Transmitter that operates in the 4.5kHz - 5.5kHz range. Note: The heart rate chest strap must be an uncoded heart rate strap from Polar Electro or an uncoded POLAR com- ®...
  • Page 32 The graph is a brief guideline, describing the generally suggested target heart rates based on age. As noted above, your optimal target rate may be higher or lower. Consult your physician for your individual target heart rate zone. Note: A s with all exercises and fitness regimens, always use your best judgment when you increase your exercise time or intensity.

  • Page 33: Operations

    OPERATIONS What to Wear Wear rubber-soled athletic shoes. You will need the appropriate clothes for exercise that allow you to move freely. How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.

  • Page 34: Power Up / Idle Mode

    Note: if the Safety Key is not installed, the machine will allow the User to perform all activities except to activate the Walking Belt. The Console will display the reminder to insert the Safety Key ( “ + SAFETY KEY” ). • Always attach the Safety Key Clip to your clothing during workouts. • If there is an emergency, pull out the Safety Key to shut off the power to the Belt and Incline Motors. This will quickly stop the belt (brace yourself- this is an abrupt stop) and clear the workout.

  • Page 35: Quick Start Program

    Push OK to set. Units of Measurement: Push the Increase/Decrease buttons to adjust between “MILES” (Imperial English) or “KM” (metric). Push OK to set. The Console goes to the Power-Up Mode screen. Note: To adjust these selections, consult the “Console Set-Up Mode” section. Quick Start ( Manual ) Program The Quick Start ( Manual ) program lets you start a workout without entering any information.
  • Page 36 Edit User Profile 1. From the Power-Up Mode screen, push the User buttons to select one of the User Profiles. 2. Push the OK button to select the User Profile. 3. The Console display shows the GOAL TRACK prompt. Push the Increase() button. 4. The Console display shows the EDIT prompt and the current User Profile name. Push OK to start the Edit User Profile option.
  • Page 37 The default is “VALUE - ON” for all workout values. When done with modifying which workout values are displayed, push the OK button to set the Console. 10. The Console display shows the WIRELESS HR prompt. If you are using the Console speakers at their higher settings and / or using a larger sized personal electronic device, the Console may show Heart Rate interference.

  • Page 38: Profile Programs

    QUICKSTART (press and hold to customize PERFORMANCE 1: program) QUICK GOAL and PACER brickyard (s): QUICK GOAL Profi le Programs Distance These programs feature different incline angles of the deck and belt speeds based on the maximum and minimum speed Time Default MAX SPEED : 3 mph supplied by the user. The user can also manually adjust the incline and speed values at any time during a workout. The Calories TRAIN/PACER: Profi le Programs are organized into Categories (Quick Goal, Heart Health, Weight Control, Interval, Train, and Custom).
  • Page 39 SPEED CALORIE BURN (low incline / low s CALORIE BURN (SCH): Time Default MAX SPEED : 3 mph SPEED Default MAX SPEED Incline. Speed is preset. INCLINE (SCH) (NLS) Default MAX SPEED : 2 mph Calories CALORIE BURN (SCH): INCLINE Default MAX SPEED : 1 mph BOTH SPEED...
  • Page 40 4. Push the Increase() or Decrease() buttons to select a Profile Workout, and push OK. If the selected Workout is Heart Rate Target, the Console will request the desired Beats Per Minute (BPM) for the Workout. Use the Increase() or Decrease() buttons to adjust, and push OK. If the selected Workout Program has Incline and/or Speed Profile customization, the Console will prompt, “EDIT INCLINE”...

  • Page 41: Compare Pacer Display

    A User can also set a Heart Rate Target value by selecting the HR TARGET program in the CUSTOM Category. The Con- sole will adjust the incline during a workout to keep the User in the desired Heart Rate zone. 1.

  • Page 42: Fitness Score Display

    User Fitness Level Based on Fitness Score excellent good high average average low average poor excellent good high average average low average poor 18-25 26-35 36-45 46-55 56-65 INCLINE 0-15 Fitness Score Display The Fitness Score is based on an estimate of the User’s VO2 Max and calorie burn over their last five workouts. F i t n e s s S c o r e www.schwinnconnect.com VO2 Max estimates are calculated using performance data (time, distance and average heart rate or an estimate of average heart rate if that data is unavailable). VO2 Max is the maximal oxygen consumption...

  • Page 43: Pausing Or Stopping

    For every workout completed that is longer than 10 minutes or a mile (1.6 km) in distance, the Console will apply those workout values toward your Fitness Score. This value is displayed on the Fitness Score Display area of the Console. Note: Using a Heart Rate Chest Strap provides the most accurate information to calculate the Fitness Score.
  • Page 44 6. Push the Decrease() button to move to “LAST 30 DAYS”. The Console will display the total values for the previous thirty days. The Console will cycle between the workout results every 4 seconds. Use the Left() or Right() buttons to force the cycle between the workout results.

  • Page 45: Console Setup Mode

    CONSOLE SETUP MODE The Console Setup Mode lets you control the sound settings ( on/off ), adjust the date and time, or see maintenance statistics (Total Run Hours and Software Version– for service technician use only). Hold down the PAUSE/STOP button and Right button together for 3 seconds while in the Power-Up Mode to go into the Console Setup Mode.

  • Page 46: Maintenance

    MAINTENANCE Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done.

  • Page 47: Adjusting The Walking Belt

    Adjusting the Belt Tension If the walking belt starts to slip during use, it is necessary to adjust the tension. Your treadmill has tension bolts at the rear of the treadmill. Make sure that the walking belt is stopped and the power switch is turned Off. Be sure not to touch a moving walking belt or step on the power cord.

  • Page 48: Lubricating The Walking Belt

    turn counterclockwise. If the belt moves to the right, turn the left adjustment bolt 1/4 turn counterclockwise and the right adjustment bolt 1/4 turn clockwise. 4. M onitor the path of the belt for approximately 2 minutes. Continue to adjust the bolts until the walking belt is centered. Push PAUSE/STOP twice to stop the walking belt and end the Quick Start workout. Lubricating the Walking Belt Your treadmill is equipped with a low maintenance deck and belt system.

  • Page 49: Heart Rate Chest Strap Battery Replacement

    performance. We can recommend that you use the following: • 8300 Silicone Spray, available at most Hardware and Auto Parts stores. • Lube-N-Walk Treadmill Lubrication Kit, available from your local specialty fitness dealer or Nautilus, Inc. ® Store silicone lubricant in a safe place. Keep out of reach of children. Silicone lubricant is not intended for human consumption. Manually rotate the belt 1/2 of the length of the belt and apply lubricant again. Unfold the machine.

  • Page 50: Maintenance Parts

    Maintenance Parts Console Assembly Grip, Upper Right Heart Rate Chest Strap Safety Key Port Grip, Lower Right Upright, Left Base Shroud, Right Grip, Lower Left Contact Heart Rate Sensor Base Cable Grip, Upper Left Console Cable Base Assembly Tray, Left Right Upright Cable Base Shroud, Left Tray, Right...
  • Page 51 Maintenance Parts ( Frame ) Front Back Power Switch Base Support Incline Adjuster Fuse Deck Cushioners Pivot Assembly Power Input Transport Wheel GG Belt Tensioner Motor Cover Leveler Rear Roller Cover Side Foot Support Rails Lifting Cylinder Motor Control Board (MCB) Cover...

  • Page 52: Troubleshooting

    TROUBLESHOOTING Condition/Problem Things to Check Solution No display/partial display/ Check electrical (wall) Make sure unit is plugged into a functioning wall outlet. Test the unit will not turn on outlet outlet with a known functioning device such as a lamp. Check connection at front Connection should be secure and undamaged.
  • Page 53 Condition/Problem Things to Check Solution Check data cable Be sure cable is connected securely and oriented properly. connections/orientation Small latch on connector should line up and snap into place. Reset machine Unplug unit from electrical outlet for 3 minutes. Reconnect to outlet.
  • Page 54 Nautilus Bowflex Schwinn Universal ® ® ® ® 8012897.111516.A...
