Zephyr Essentials Verona Island Use, Care And Installation Manual page 10

12 15/16"
8 1/4"
24"
35 7/16", 41 15/16"
FRONT
C/L
AC In
2 1/16"
TOP of HOOD
www.zephyronline.com
C/L
TOP SUPPORT FRAME
8
12 3/4"
STANDARD
min. ducted - 28 1/2"
min. recirc. - 32"
max. - 50"
Z1C-00VN
min. ducted - 42"
min. recirc. - 46 1/2"
max. - 80 1/2"
16 3/4"
27 7/16"
SIDE
10 1/8"
4 13/16"
10 15/16"
C/L
4 13/16"
(top view)
