Warren rupp SANDPIPER MSB2 Service And Operating Manual

Ball valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of Contents

Principle of Operation ............................................................................................ 1
Installation and Start-Up ........................................................................................ 1
Air Supply .............................................................................................................. 1
Air Inlet & Priming .................................................................................................. 2
Air Valve Lubrication .............................................................................................. 2
: Externally Serviceable Air Distribution System ................................ 2
®
Air Exhaust ............................................................................................................ 3
Between Uses ....................................................................................................... 3
Check Valve Servicing ........................................................................................... 3
Diaphragm Servicing ............................................................................................. 3
Reassembly ........................................................................................................... 4
Pilot Valve .............................................................................................................. 4
Pilot Valve Actuator ................................................................................................ 4
Service Instructions: Troubleshooting ................................................................4-5
Warranty ................................................................................................................ 5
Installation ............................................................................................................. 6
Material Codes ...................................................................................................... 7
Composite Repair Parts List ...............................................................................8-9
Composite Repair Drawing.................................................................................. 10
CE Declaration of Conformity - Machinery .......................................................... 11
CE Declaration of Conformity - ATEX .................................................................. 12
Warren Rupp, Inc A Unit of IDEX Corporation • P.O. Box 1568, Mansfield, Ohio 44902 USA
Telephone (419) 524-8388 • Fax (419) 522-7867 • warrenrupp.com
Model MSB2
SERVICE AND OPERATING MANUAL
II 2G c T5
II 2Dc T100°C
Models MSB2 and MSB2-B
Mine/Construction Duty
©Copyright 2017 IDEX AODD, Inc. All rights reserved.
Ball Valve
Type 3
