Pulsar APSDC2410A Manual

Buffer switch mode power supply unit with technical outputs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APSDC2410A
APS UPS DC 27,6V/10A/OC
Buffer switch mode power supply unit
with technical outputs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APSDC2410A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pulsar APSDC2410A

Summary of Contents for Pulsar APSDC2410A

  • Page 1 APSDC2410A APS UPS DC 27,6V/10A/OC Buffer switch mode power supply unit with technical outputs.

  • Page 2: Table Of Contents

    INSTRUCTIONS APSDC1202A Features: • • DC 27,6V/10A uninterruptible power supply* EPS technical output indicating AC power loss • – OC and relay type fitting battery: 2x17Ah/12V • • PSU technical output indicating PSU failure wide range of mains supply: 176÷264V •...

  • Page 3: Block Diagram

    INSTRUCTIONS APSDC1202A 1.2 Block diagram (fig.1) Fig.1. The block diagram of the PSU. 1.3 Description of the module’s components and connectors. Table 1. Elements of the module’s (see fig. 2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage EPS- AC absence technical output –...

  • Page 4: Description Of Psu Components And Connectors

    INSTRUCTIONS APSDC1202A Fig. 2. The view of the PSU. Description of PSU components and connectors (tab.2, fig.3). Element no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. Output terminals of the PSU. Fig.3. The view of the PSU.

  • Page 5: Specifications

    INSTRUCTIONS APSDC1202A 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) Electrical parameters (tab. 3) Mains supply 176÷264V AC Current up to 1,5A@230V AC Supply power 276W max. Efficiency 22V÷27,6V DC – buffer operation Output voltage 19V÷27,6V DC –...

  • Page 6: Installation

    INSTRUCTIONS APSDC1202A Mechanical parameters (tab. 4) Dimensions W=400, H=350, D+D =92+8 [+/- 2mm] =405, H =355 [+/- 2mm] The dimensions of the 370x170x80mm (WxHxD) max battery compartment Fixation See figure 2 Net/gross weight 4,2kg / 4,5kg Enclosure Steel plate, DC01 0,7mm colour: RAL 9003 Closing Cheese head screw x 2 (at the front), (lock assembly possible) Power supply: Φ0,63-2,50 (AWG 22-10)

  • Page 7: Installation Procedure

    INSTRUCTIONS APSDC1202A Before installation, prepare a PSU load balance. 1. Output current 9A + 1A battery charge 2. Output current 8A + 2A battery charge 3. Output current 6A + 4A battery charge Total device current + battery: 10A max As the PSU is designed for a continuous operation and is not equipped with a power-switch, therefore an appropriate overload protection shall be guaranteed in the power supply circuit.
  • Page 8 INSTRUCTIONS APSDC1202A 3.2 Technical outputs The PSU has indication outputs: • EPS - absence of AC supply output: - OC type output that indicates AC power loss. Under normal status, with 230V AC supply, the output is connected to ground (L level – 0V). In case of power loss, the PSU will switch the output into high impedance state hi-Z.
  • Page 9 GREEN POWER plus www.pulsar.pl HPSBOC10A24C 4. Operation and use. 4.1 Overload or short circuit of the PSU output (SCP on). In case of overload, the output voltage is automatically shut off, and so is the LED indicator. The restoration of the voltage takes place immediately after the failure (overload) is over.
