- Page 1 DARCHE ROOF TOP TENT Hi View 1400 Hi View 1600 Hi View 1800 Hi View 2200 Panorama 2 Intrepidor 2 www.darche.com.au...
-
Page 2: Table Of Contents
Warranty ....................11 Thank you for purchasing a Darche Roof Top Tent Congratulations on your purchase of a Darche Roof Top Tent. We strive to provide the ultimate camping experience for every tourer. Your Roof Top Tent mounts directly to your roof rack or aftermarket roof bars. -
Page 3: Warning
For your safety and protection, ensure correct placement and angle of ladder. DO NOT CLIMB ON LADDER UNTIL CORRECT ANGLE IS ACHIEVED (approx. 75 degrees). Darche Outdoor Gear - The wholesaler / manufacturer shall not be liable for special, indirect incidental or consequential damages. -
Page 4: Roof Top Tent Hardware Identification Chart
ROOF TOP TENT HARDWARE INDENTIFICATION CHART Quantity Model# Ladder Mounting Bracket Panorama 1400 Hi View 1400 Hi View 1600 2pcs Hi View 1800 Intrepidor 1400 Hi View 2200 4pcs 55 mm Steel M8 Bolt T050801879 40 mm Steel M6 Bolt... - Page 5 ROOF TOP TENT HARDWARE INDENTIFICATION CHART Quantity Model# M6 Nyloc Nut Panorama 1400 Hi View 1400 Hi View 1600 12 pcs Hi View 1800 Intrepidor 1400 Hi View 2200 14pcs M8 Nyloc Nut All models 8 pcs T050801889 A Stainless Steel Washer...
-
Page 6: Tent Orientation On Your Vehicle
These orientations depend on the size of the roof top tent. The Panorama 1400, Hi View 1400 and Intrepidor 1400 can be mounted in either orientation. Darche recommends the Hi View 1600, Hi View 1800 and Hi View 2200 to be side mounted. -
Page 7: Attaching Mounting Channels
ATTACHING MOUNTING CHANNELS 1. Remove the Roof Top Tent from the carton and place on a clean surface. Observe the top surface. If it has four holes in the center area of the base, then this is the side which will receive the mounting channels. - Page 8 40mm Steel M6 Bolt Washer M6 Nyloc Nut Aluminium Mounting Channel 55mm Steel M8 Bolt Slide Plate Steel Mount Saddle M8 Nyloc Nut DIAGRAM A...
-
Page 9: Attaching The Ladder
ATTACHING THE LADDER 1. Flip the tent base over. 2. Locate the pre-drilled holes at the edge of the base and attach the ladder bracket to the base using 40mm Steel M6 bolt, washers, and Nyloc nuts. DIAGRAM B For your safety and protection see Diagram C below for correct placement and angle of ladder. -
Page 10: Fitting The Roof Top Tent To Your Roof Rack
FITTING THE ROOF TOP TENT TO YOUR ROOF RACK 1. Place the Roof Top Tent on top of your vehicle’s roof rack system (minimum 2 persons required). 2. Place 55mm Steel M8 bolt into the slide plates. Slide the plates and bolts into the mounting channel. -
Page 11: Closing And Storage
CLOSING AND STORAGE Note: The bunji cords shown in the image below assist in holding the canvas in during RTT pack up. Attach these to the 3 round plastic loops located around the windows inside the RTT. Bring them across to the opposite side of the RTT and attach to the plastic loop. - Page 12 36 MONTH WARRANTY Darche will repair or any Darche product at its discretion that is subject to faulty manufacturing or workmanship including materials. EXCLUSIONS: The above warranty is limited to manufacturing and materials defects. Not including damage caused by misuse or abuse, wear and tear, condensation, extreme weather, accidents, incorrect set up, damage caused by mould, insects, animals or children.
