AWNING WALLS INSTRUCTIONS
1
DETERMINE THE POSITION OF THE WALL
USING THE DIAGRAM BELOW.
LOCATE THE LABEL ON THE WALL AND
LINE THIS UP WITH THE LABEL ON THE
AWNING. THIS WILL HELP IDENTIFY THE ZIP
STARTING POSITION.
2
3
WALL
EC27-W1
1
2
CONNECT ZIPS AND COMPLETELY ZIP THE
WALL TO THE AWNING.
NOTE: ENSURE THE INSERT PIN ON THE
AWNING'S ZIP IS SEATED FULLY INTO
THE WALL'S RETAINING BOX BEFORE
COMMENCING TO SLIDE THE ZIP.
WHILST ZIPPING, IT IS ESSENTIAL TO HOLD
UP THE WALL WITH YOUR OPPOSITE HAND
OR WITH THE AID OF A HELPER TO RELIEVE
PRESSURE OFF THE ZIP. FAILURE TO DO
THIS MAY DAMAGE THE ZIP TEETH WHICH
WILL VOID ANY WARRANTY.
2
3
3
ANCHOR THE WALLS TO THE GROUND
USING THE PEGS SUPPLIED.
3
WALL
EC27-W3
2
1
WALL
EC27-W2
