BGT and UT Series TANKTEND
Installation and Operation Instructions
Models: BGT1, BGT1VR, UT1, and UT1VR
Please read the following information before installing. A visual inspection of this product for damage during shipping is recommended
before mounting. It is your responsibility to have a qualified person install this unit and make sure it conforms to NEC and local codes.
WARNING
BEFORE BEGINNING INSTALLATION OF THIS MURPHY PRODUCT
Disconnect all electrical power to the machine.
Make sure the machine cannot operate during installation.
Follow all safety warnings of the machine manufacturer.
Read and follow all installation instructions.
Description
The Murphy TANKTEND
TM
ground tanks, and UT1 for single, remote monitoring below ground
tanks can meet most single tank remote inventory monitoring
requirements.
All of the Murphy BGT1 and UT1 TANKTEND
able with vapor recovery option (BGT1VR and UT1VR), which will
compensate for gas blankets or head pressure caused by vapor recov-
ery storage systems.
Specifications
BGT1 and BGT1VR Models
Dial: White dial with green and black markings,
4-1/2 in. (114 mm) diameter.
Case: Die cast aluminum, painted.
Sensing Element: Brass bellows actuated for greater accuracy;
BGT1VR models feature a second set of bellows for vapor
recovery monitoring.
Lens: Optically clear polycarbonate.
Sensing Connection: 1/4 NPTF;
BGT1VR models include a second connection for vapor
recovery monitoring, 1/8 NPTF.
Shipping Weight: 6 lbs. (2.72 kg).
Shipping Dimensions: 10 x 9 x 6 in. (254 x 229 x 153 mm).
UT1 and UT1VR Models
Enclosure: Cold rolled steel, weatherproofed (painted).
Gaging System: BGT1 or BGT1VR (specifications as above).
Shipping Weight: 26 lbs. (11.79 kg).
Shipping Dimensions: 16 x 16 x 10 in. (406 x 406 x 254 mm).
GENERAL INFORMATION
Series models BGT1, for single, above
TM
systems are avail-
TM
Systems
BGT1 and BGT1VR Dimensions
8-7/16 in.
(214 mm)
4-1/32 in.
(102 mm)
9/32 in.
(7 mm) dia.
3 holes
1/4 NPTF
UT1 and UT1VR Dimensions
12 in. (305 mm)
UTKN Tank Plug Kit
(optional)
Includes: Either 2 NPTM or
4 NPTM tank plug;
304 stainless steel tubing
1/4 in. (6 mm) dia., 12 ft.
(3.6 m) long; and fittings.
FRANK W.
3-3/8 in.
(86 mm)
7-7/8 in.
(200 mm)
3-15/16 in.
1/2 NPT
(100 mm)
conduit
Bleeder
Valve
1/8 NPTF
(BGT1VR only)
1 in. (25 mm)
2-1/2 in.
(61 mm)
6-1/4 in.
(159 mm)
Mounting
Holes
1/8 NPTF
Rubber
(UT1VR only)
bulb
14 in.
(356 mm)
10 in. (254 mm)
Mounting Holes
CKBO Check Valve
can be installed here
Vapor Recovery
connection (plugged)
Tubing
TNK-95049N
Revised 02-97
Section 15
(00-02-0222)
®
MFR.
5 in.
(127 mm)
1
