Murphy PowerView Analog Gages PVA20 Installation Instructions

& PVA35 Installation Instructions
Please read the following information before installing. A visual inspection of this product for damage during ship-
ping is recommended before mounting. It is your responsibility to have a qualified person install this unit.
WARNING
BEFORE BEGINNING INSTALLATION OF THIS MURPHY PRODUCT
✔
Disconnect all electrical power to the machine.
✔
Make sure the machine cannot operate during installation.
✔
Follow all safety warnings of the machine manufacturer.
✔
Read and follow all installation instructions.
Description
CAUTION: These instruments are designed to be used ONLY
with the MurphyLink
TM
†
MurphyLink TM PowerView products.
The PowerView Analog Gages (PVA) are a series of intelligent gages
designed to display easy-to-read information transmitted by the PowerView.
The PVA gages communicate with the PowerView via a single RS485 twist-
®†
ed pair MODBUS RTU serial link. The gages can be daisy-chained using
quick-connect harnesses with watertight connectors.
The PVA gages also include features such as a smooth stepper motor opera-
tion for the 270° sweep pointer, an environmentally sealed case with two
Deutsch DT style connectors molded into the casing, and green LED back
lighting. They are available for standard 2-1/16 in. (52 mm) and 3-3/8 in. (86
mm) diameter hole sizes. In addition their plastic cases incorporate a "D"
shape allowing panel cutouts that eliminate gage rotation during installation.
The PowerView Audible Alarm (PVAA) alerts operators to fault conditions
via piezoelectric alarm and relay contacts. It also has a temporary silencer
button that silences the audible tone for 2 minutes on alarms and 30 seconds
on shutdown conditions.
All PowerView Gages can be powered by 12 or 24 VDC systems.
PVA20 Series Models:
PVA20 –A = Engine Oil Pressure
PVA20 –B = Coolant Temperature
PVA20 –C = Voltmeter
PVA20 –D = Percent Load at Current RPM
PVA20 –E = Transmission Oil Pressure
PVA20 –F = Transmission Oil Temperature
PVA20 –G = Engine Oil Temperature
PVA20 –T = Tachometer
PVAA20 = 2 inch dial audible alarm gage
PVA35 Series Models:
PVA35 –T = Tachometer
PVA35 –S = Speedometer
Analog Gages PVA20
GENERAL INFORMATION
†
PowerView module or other approved
2 inch size gages:
3-1/2 in. size gages:
PVA-02126N page 1 of 4
PVA35 Series

Specifications

Power Supply Input Voltage: 12/24V (8-32VDC min. & max. voltage).
Power Supply Operating Current: (@ 14 VDC) =
PVA20, PVA35: 28 mA minimum; 52 mA maximum.
PVAA20: 19 mA minimum; 46 mA maximum.
Backlight Maximum Current (not applicable to PVAA20): 24 mA.
Input: RS485 MODBUS ® RTU data.
Output: Analog Readout.
Relay Rated Load (PVAA20): 0.5 A, 125 VAC; 1 A, 24 VDC.
Relay Maximum Switching Capacity (PVAA20): 62.5 VA, 30W.
External Audible Alarm Output (PVAA20): 28 VDC, 30 mA max. (cur-
rent sink).
Temporary Silence Button (PVAA20): Charge transfer technology.
Operating Temperature: -40° to 185°F (-40° to 85°C).
Storage Temperature: -76° to 185°F (-60° to 85°C).
Dial: White numerals over black background.
Indicating Pointer: Stepper motor operation with 270° sweep.
Gage Accuracy: PVA20: Better than ±1.0% of scale.
PVA35: Better than ±2% of scale.
Environmentally Sealed Enclosure:
Sealing: IP68, ±5 psi (±34.4 kPA).
Case and Clamp Material: Polyester (PBT).
Lens Material: Polycarbonate.
Bezel Material: Polyester (PBT).
Maximum Panel Thickness: 3/8 in. (9.6 mm).
Connectors: 6-Pin Deutsch DT06 Series.
†
MurphyLink is a registered trademark of FWMurphy. All other trademarks and
service marks used in this document are the property of their respective owners.
PVA-02126N
Revised 01-04
Section 78
00-02-0532
PVA20 Series
