These instructions apply only to the destination countries listed on the appliance's data
plate.
This is a class 3 built-in hob.
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Table of contents
4
4
6
6
6
6
7
8
8
8
9
10
10
10
10
13
13
13
15
15
15
16
17
18
20
21
3
Advertisement
Table of Contents
Related Manuals for Smeg PGF95HK
Summary of Contents for Smeg PGF95HK
-
Page 1: Table Of Contents
These instructions apply only to the destination countries listed on the appliance's data plate. This is a class 3 built-in hob. We advise you to read this manual carefully, as it contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Cooking process should always be kept under control. A short 1.1 General safety instructions cooking process must be continuously surveyed. Risk of personal injury • While cooking do not place • Never try to put out a fire or metal objects, such as cutlery or flames with water: turn off the dishes on the hob surface as they... - Page 3 Instructions chromium-plating). • The hoses should not come into contact with moving parts and • Do not use abrasive or corrosive should not be crushed in any way. detergents (e.g. scouring powders, stain removers and • After carrying out any operation, metallic sponges) on glass parts.
-
Page 4: Manufacturer Liability
Instructions Manufacturer liability 1.4 Identification plate The manufacturer declines all liability The identification plate bears the for damage to persons or property technical data, serial number and caused by: brand name of the appliance. Do not remove the identification plate for •... -
Page 5: How To Read The User Manual
Instructions 1.6 How to read the user manual This user manual uses the following reading conventions: Instructions General information on this user manual, on safety and final disposal. Description Description of the appliance and its accessories. Information on the use of the appliance and its accessories. -
Page 6: Description
Description 2 Description 2.1 General Description 1. Control panel 2.2 Symbols 2. Auxiliary Burner (AUX) Cooking zones 3. Semi-rapid burner (SR) 4. Ultra-rapid burner (UR) Front left 5. Right grid 6. Central grid Rear left 7. Left grid Front right Rear right Central... -
Page 7: Available Accessories
Description Burner knobs The ring must be placed above the hob grid as shown in the picture above. In any case, pans with a diameter greater than 26 cm must be used solely on the Used for lighting and adjusting the hob Ultra-rapid burner (UR). -
Page 8: Use
3 Use 3.2 First use 1. Remove any protective film from the 3.1 Instructions outside or inside of the appliance, including accessories. Improper use 2. Remove any labels (apart from the Danger of burns technical data plate) from accessories. 3. Remove and wash all the appliance's •... - Page 9 Positioning the pan stands Practical tips for using the hob The pan stands are provided unassembled For better burner efficiency and to minimise on the hob. To install the grids correctly, gas consumption, use pans with lids and of follow the instructions as shown in the figure. suitable size for the burner, so that the flames do not reach up the sides of the pan.
- Page 10 Limitations on griddle use A few precautions are necessary if you wish to use a griddle: • The griddles should not exceed the perimeter of the hob. • Aluminium griddles with Teflon anti-stick coating should be pre-heated for a maximum of 5 minutes in order to avoid damage to the appliance and the Teflon coating.
-
Page 11: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance Food stains or residues Do not use steel sponges and sharp 4.1 Instructions scrapers, as they will damage the surfaces. Use normal, non-abrasive products and a Improper use wooden or plastic tool, if necessary. Rinse Risk of damage to surfaces thoroughly and dry with a soft cloth or a microfibre cloth. - Page 12 Cleaning and maintenance Flame-spreader crowns and burner caps Igniters and thermocouples For easier cleaning, the flame-spreader For correct operation the igniters and crowns and the burner caps can be thermocouples must always be perfectly clean. Check them frequently and clean removed.
-
Page 13: Installation
Installation 5 Installation 5.2 Safety instructions Heat production during appliance 5.1 Important notes operation Read these instructions carefully and keep Risk of fire them in a safe place. Safety during use can only be ensured if the appliance is fitted •... -
Page 14: Positioning In The Counter Top
Installation 5.3 Positioning in the counter top To prevent leakage of liquid between the frame of the hob and the work surface, The following operation requires carefully put the insulating seal provided in building and/or carpentry work position before assembly. and must therefore be carried out 1. -
Page 15: Mounting
Installation 3. Place the hob on the insulating seal and 5.4 Mounting fix it to the supporting structure using the Over built-in oven unit supplied screws and fastening brackets The clearance between the hob and the (A) so that the hob is perfectly level. kitchen furniture or other installed 4. -
Page 16: Gas Connection
Installation 5.5 Gas connection Gas leak Danger of explosion • After carrying out any operation, check that the tightening torque of gas connections is between 10 Nm and opens on bottom 15 Nm. • If required, use a pressure regulator that complies with current regulations. - Page 17 Installation According to the Gas Safety Ordinance of Room ventilation Hong Kong, any gas installation works The room where the appliance is installed including installation of appliances and must have enough air flow for the regular connection tubing, must be undertaken by combustion of gas and the necessary air registered gas installers who are registered change in the room itself.
-
Page 18: Electrical Connection
Installation Technical data table Product description 5-burner town gas hob Model PGF95HK Top plate material Stainless steel Net weight 19kg Product dimensions H x W x D: 79 x 867 x 512mm Gas type Hong Kong Town Gas External gas governor MAXITROL RV47LM-Rp-1/2”... -
Page 19: Instructions For The Installer
Installation • 220-240 V 1N~ 5.7 Instructions for the installer • The plug must be accessible after installation. Do not bend or trap the power cable. • The appliance must be installed according to the installation diagrams. • Do not try to unscrew or force the Use a 3 x 0.75 mm²...
