EN 54-2 EN 54-4 User’s Manual EN 54-21 EN 12094-1 0051 0051-CPR-3155 0051-CPR-3156 CONVENTIONAL FIRE-DETECTION CONTROL PANEL, FIRE EXTINCTION CONTROL PANEL, ALARM TRANSMISSION AND REMOTE FAULT SIGNALLING AND WARNING EQUIPMENT USER’S MANUAL...
In no case can INIM Electronics s.r.l. be held responsible or liable by the buyer or any other person for any loss or damage, direct or indirect, consequential or incidental.
Status Bar............................12 Chapter 4 Inim Cloud Fire ......................14 User interface, home page ......................14 Registration of a control panel to the Inim Cloud user account ........15 Chapter 5 Viewing the system....................16 Viewing active events........................16 Visualization of the events log ....................17 Visualization of the system status ....................18...
Page 4
Fire alarm and extinguishing system Table of contents...
INIM Electronics brand. About this manual Manual code: DCMUINI0PREVIDIAM Revision: 1.00 This manual describes the procedures for the configuration, commissioning and maintenance of the Previdia Micro fire- detection system. Operator classification - Access Levels The control panel has 4 distinct access levels: Level 1: Public level - this is the normal access level of the control panel and is the access level for building inhabitants who are neither authorized to use the system nor instructed in its use.
Power supply performance PASS Response delay (response time in the event of fire) PASS 0051 Transmission performance PASS INIM Electronics s.r.l. Operating reliability PASS Via Dei Lavoratori 10 - Fraz. Centobuchi Thermal resistance 63076, Monteprandone (AP) - Italy PASS Vibration resistance...
Page 7
User’s Manual 1.4.2 Directive 2014/53/EU Hereby, INIM Electronics s.r.l., declares that this type of Previdia Micro control panel are in compliance with the essential requirements and other relevant provisions of Directive 2014/53/UE. Following paragraph explains how to download the complete Declaration of Conformity.
Fire alarm and extinguishing system Chapter 2 Operative statuses of the Previdia Micro system Standby: Operating status of the control panel when there is no ongoing alarm or fault signalling. This status is altered by the occurrence of an event, that is, an operative status which is characterized by an activation (when the event occurs) and a reset (when the event ends).
User interface Front plate models The user interface of the Previdia Micro control panel consists of a touch-screen display, buttons and LED indicators mounted on the front plate. Depending on the control panel model, there are three different types of user interfaces:...
Fire alarm and extinguishing system Function buttons and LEDs The LEDs on the sides and below the screen provide visual signals which indicate the general status of the system, whereas the function buttons allow fast execution of all the main operations. The key permits level 1 (public level) to pass to level 2 (supervisor level).
User’s Manual Function LEDs Colour On solid Function button Signalling The test on the visual If this button is pressed and held all the LEDs Yellow test signalling devices is running. on the control panel will light. Button for manual activation of the signalling The evacuation phase has Evacuate devices (audible and visual) for evacuation of...
Fire alarm and extinguishing system Status Bar Icon Function Selection of this area allows you to enter a code and change the current user-access level. Access level:1 - 1 = Public level (no code entry) - 2 = Supervision level (turn key or user code entry) - 3 = Programming level (installer code entry) If required by the configuration, this button will appear on the status bar.
Page 13
User’s Manual Icon Function Selection of this icon accesses the management window of the remote communicator for alarm signalling (refer to paragraph 6.3 Management of the remote communicator). If installed, remote alarm-signalling devices (voice or digital telephone communicators associated with alarm receiving centres) are in standby status and operating efficiently.
After login, the user will have access to a customized web interface which provides all the tools required for supervision of all the control panels registered by the user. In order to access Inim Cloud services as a user, registration must be carried out also by the user (paragraph 4.2). User interface, home page Following is the description of the home page;...
Registration of a control panel to the Inim Cloud user account After logging in to the relevant Inim Cloud service user account, a user can request the registration of a new control panel in addition to those the user can access via the web interface.
The events are listed in a chronological order [C] and can be scrolled with the arrow keys. PREVIDIA MICRO By selecting with a touch an event generated by a loop device, you will access the management page of the device itself (refer to paragraph 6.2 Device management).
Keys for scrolling the events in the log 149/150 Number of the selected 1/01/2023 6:21:00 PM Open input Zone 1 PREVIDIA MICRO event out of the total events 1/01/2023 6:22:00 PM RECOGNIZED CODE User Code PREVIDIA MICRO Scrolling keys (100 events)
Revisions Button for displaying the firmware Alarm counter 23 revision of the control panel in use Panel: Previdia Micro Buttons for visualization and management of the communicator (paragraph 6.3), The Control panel access button allows you to select one of the Previdia control panels configured in the network to which the control panel you are accessing belongs.
Page 19
User’s Manual Button Display Section If an analogue control panel equipped with a loop is Loop Status selected, this section will activate as well as the two Point Loop 1 Standby following sections. Loop 2 Alarm This section allows the selection of the loops of the selected control panel.
Page 20
Fire alarm and extinguishing system Button Display Section Section for the management of the timers Timers Status programmed for the selected control panel. Timers Timer 1 Standby The activation status of each timer is shown and Timer 2 Standby made distinctive by colour: Timer 3 Active •...
Page 21
Cloud button becomes available Cloud No problem visualization and management of the Inim Cloud Network diagnostic Fire service. The section that opens shows the following buttons: • Enroll, for the process of registration of the control panel to the account of the user (refer to paragraph 4.2 - Registration of a control panel to...
Fire alarm and extinguishing system Chapter 6 Using the system Access to programming The Programming button (paragraph 3.3 - [A]) accesses the system configuration functions. These functions are reserved for specialized technical personnel only and require entry of the installer code. Refer to the Configuration and Programming manuals.
System management > select one of the available control panels > Zones Management of the remote communicator Previdia Micro allows you to view and manage a remote communicator. “Remote communicator” defines the remote notification functions performed by the PREVIDIA-C-DIAL communicator module, via the telephone line or 3G line, by the TCP-IP digital communicator on-board the control panel, or by any external communication device connected to the control panel or to the optional PREVIDIA-C-COM board.
Fire alarm and extinguishing system Managing the extinction channel The front plates of control panels from the Previdia Micro range equipped with fire extinction channels, provide signals via the LED indicators: LEDs Colour On solid Flashing Pre-extinguishing time in Extinction channel...
User’s Manual Appendix Rapid emergency management Sequence in the event of ALARM Mute the buzzer Pass to access level 2 by turning the key clockwise (one pulse sufficient) Silence the sounders Verify signalling on the display In the event of false alarm press the reset button In the event of danger activate manual evacuation...
Page 26
Fire alarm and extinguishing system Rapid emergency management...
Page 28
Fire alarm and extinguishing system ISO 9001 Quality Management certified by BSI with number FM530352 Inim Electronics S.r.l. Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel. +39 0735 705007 _ Fax +39 0735 704912 DCMUINE0PREVIDIAC-110-20231005 info@inim.it _ www.inim.it...
