- Page 1 User’s manual EN 50131-1 EN 50131-3 EN 50131-6 EN 50136-1 EN 50136-2 EN 50130-4 EN 50130-5 CEI 79-2 CEB T014 SmartLiving Anti-intrusion control panels and security systems User’s manual...
-
Page 2: Warranty
24 months. As INIM Electronics s.r.l. does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;... -
Page 3: Table Of Contents
User’s manual Table of contents Warranty ........2 Limited warranty . - Page 4 Anti-intrusion control panels Change PIN ......... 41 5-10 Change telephone numbers .
-
Page 5: Chapter 1 General Information
Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on INIM Electronics brand devices only. Description of the product and various models Description: Intrusion control panel... -
Page 6: Environmental Conditions
Sistemi di sicurezza (IMQ S.p.A.) and conform to the above mentioned standards, when duly programmed, as described in . The control panel enclosure in capable of housing the following certified items: • INIM Electronics switching-power supply • Motherboard (IN082 or IN088) • SmartLogos30M voice board (accessory item) •... -
Page 7: Manuals
User’s manual • nCard access-control card for proximity readers • Tag for nKey or nBoss proximity readers • Self-powered sounderflashers for outdoor installation: Ivy, Ivy-F, Ivy-M, Ivy-FM, Ivy- B, Ivy-BF, Ivy-BM, Ivy-BFM • Wireless devices AIR2, AIR2-BS200 (transceiver), Air2-IR100 (PIR detector), Air2- MC100 (magnetic contact) •... -
Page 8: Access Levels
Centrali anti-intrusione • User • Manager • Master The system codes can carry out, in accordance with their assigned level in the system hierarchy (the “User” being the lowest level), the following operations on all other codes that are inferior hierarchically: ••... -
Page 9: Chapter 2 The Smartliving System
Its advanced technology and user-friendly operations provide an extremely high level of protection combined with ease-of use. INIM Electronics recommends that all parts of this manual be read thoroughly before starting up SmartLiving system. Once you have become accustomed to the day-to-day operations, your installer will explain and if required, program the advanced functions provided by the system. -
Page 10: The Technologies
2-2-2 VOIB This is an acronym for Voice Over Inim-Bus. VOIB technology allows the system to manage end-to-end digitized voice transmissions at extremely high-speed over the IBUS. Voice transmissions can be carried to all points of the IBUS. The JOY/MAX and Alien keypads have built-in microphones and speakers for message recording and playback. - Page 11 User’s manual KEYS The various keypad models have different functions, enclosures and key access. The keys on Joy keypads are protected a cover, whereas, the keys of the nCode/G, Aria and Concept/G keypads are on view. The Concept/G is a touch-screen keypad. Alien keypads are not equipped with keys but instead have a colour touch screen that allows access to the system via touch or touch-screen pen (supplied with Alien/G).
- Page 12 Centrali anti-intrusione • Standby - shown when the control panel is functioning normally and there are no alarm, tamper of fault events present on the system. • Zone alarm or tamper - shown when the control panel detects or signals violation on a zone, both in the event of intrusion or detection of a lost device •...
- Page 13 User’s manual The icons which appear on the right side of the second line, provide information regarding the system, therefore, their presence or status (fixed or flashing) depends on the status they must signal: Table 2-3: Information icons Icon Signalling Joy, nCode, Concept Aria Alien...
-
Page 14: Emergency Functions
Centrali anti-intrusione 2-3-2 Using the keys The following section describes how the keys are normally used. Some of the keys may have specific functions which will be indicated when necessary. Table 2-4: The keypad keys Keys Name Typical application Number keys Used to type in User PINs Confirms the selected item (parameter, etc.) These keys allow you to scroll the menu lists and/or adjust graphically displayed parame-... -
Page 15: Keypad Leds
User’s manual 2-3-4 Visual signals on the keypad LEDs The following table describes the signals on the LEDs of the Joy, nCode, Aria and Concept keypads, or the icons which represent them on the display of the Alien keypad. Table 2-6: Keypad LEDs LED/Icon Yellow Blue... - Page 16 Centrali anti-intrusione 2-3-5 Emergency status In the event of a keypad configuration or communication error between the system - JOY/MAX - peripherals, the display will show one of the templates opposite. FW RELEASE X.YZ NO COMMUNICATION If you are using an Alien user interface, the above-mentioned information will be shown on the bottom bar on the home page.
- Page 17 User’s manual Table 2-7: Alien - screen Tapping this section on the display opens (for 3 seconds) a window containing a list of the active scenarios. If required by programming (paragraph 5-8 Keypad settings), it may request entry of a valid code. System information icons, as described in Table 2-3: Information icons.
-
Page 18: Reader - Nby
Centrali anti-intrusione Table 2-8: Signalling and types of signal Signalling Type of signal Button pressed Single pulse (beep) Entry time running 8 pulses + 5 second pause 3 pulses + 5 second pause; Exit time running 4 short pulses + 5 second pause during the final 20 seconds of the exit Time Pre-arm time running 1 pulse + 5 second pause Activation of the output con-... -
Page 19: User Codes
User’s manual 2. When a key is present at the reader (refer to Table 2-10: Reader LEDs with key at reader), the LEDs will indicate (in rapid succession) the available shortcuts. Table 2-9: Reader LEDs with no key at reader Blue Green Yellow... -
Page 20: User Menu
Centrali anti-intrusione Note The PINs of user codes can be changed by the installer or by other hierarchically superior code. The installer provides the system users with default user PINs which they must change immediately to PIN codes of their choice. Each user code has the following parameters, to be programmed by the installer or by other user codes of hierarchically superior level. -
Page 21: Keys
(3.) Keys User Code Stop alarms The SmartLiving system is capable of managing INIM's contact-free digital-keys, which Delete memory are available in three versions: Nexus status • nKey, nBoss - tag fro proximity readers •... -
Page 22: Multi-System Access
Centrali anti-intrusione control imparts audible and visual feedback signals (beep and LED signals) which notify the user of the outcome of requested operations. Table 2-11: Feedback signals provided by KF100 wireless remote-control Icon LED 1 LED 2 LED 3 LED 4 Buzzer signal Operation 1 flash... -
Page 23: Web / E-Mail Functions
The control panels can be reached and configured even when the computer in use is not equipped with INIM software. An Internet connection is necessary either through a PC or the AlienMobile app for smartphones and tablets. -
Page 24: Videosurveillance
Centrali anti-intrusione “SHOW SCENARIO” If the “Show scenario” control panel parameter is active, the left side of the second line on the screen will display the current scenario. “VIEW PARTITION If you are using an Alien keypad, the "View partition status" option (refer to paragraph 3-3-3 Remote-control shortcuts) will allow you to select the visualization mode of the STATUS”... -
Page 25: Chapter 3 Shortcuts
User’s manual Chapter 3 SHORTCUTS Keypad shortcuts The installer can program each Joy, nCode and Concept keypad with up to 12 shortcuts associated with 4 function keys . The shortcuts are identified by 18:23 01/02/2016 icons which appear on the lower part of the display. Arrows to the right and left of the DASIDASI-- icons indicate that keys will allow you to view and use other shortcuts (if... -
Page 26: Shortcut With Code
Centrali anti-intrusione Shortcut with code Besides the shortcuts provided by keys , each user code can have as many as 22 customized (personal) shortcuts. Users will be able to access their code-shortcuts only after validating their PINs (refer to paragraph 2-5-1 Ways of accessing the user menu). Each code can be programmed to manage: •... -
Page 27: Shortcut List
User’s manual “50131READERLEDOFF” If the installer has enabled option “50131ReadLedOFF”, the reader LEDs will be off, therefore, if you wish to activate a shortcut, you must: 1. Wave the key across the sensitive area of the reader: the LEDs will signal the respective status for 30 seconds. -
Page 28: Chapter 4 Voice Functions
Centrali anti-intrusione Chapter 4 VOICE FUNCTIONS If the SmartLiving control panel is equipped with a SmartLogos30M voice board, you will be able to take advantage of all the voice functions provided by the JOY/MAX and Alien keypads, including the over-the-phone voice guide. Your installer will program the voice messages you require: •... -
Page 29: Chapter 5 Using The System
User’s manual Chapter 5 USING THE SYSTEM This chapter describes all the operations users can carry out with or without authorization (user PIN entry). The tools and methods which allow access the system operations are as follows. The system can be accessed: •... -
Page 30: Arming And Disarming Partitions
Centrali anti-intrusione Via Keypad Method 1 Activate the shortcuts associated with keys , ..., shown on the display, with or without code entry: • The shortcut which is assigned to “Alarm menu” menu operations (shortcut n.13: 18:23 01/02/2016 Method 2 DDDDDDD ) allows you to view the respective section. - Page 31 User’s manual If you request an arm-partition command at a keypad (for one or more partitions) and conditions (programmed by the installer) which lower the security of the system are Faults present present, the keypad will provide a list of the conditions concerned, as shown in the Low battery figure opposite.
-
Page 32: Voice Box And Intercom Functions
Centrali anti-intrusione Via Command Zone Under normal circumstances, a command zone comprises a mechanical key-lock or call point which activates an electrical contact wired to the command zone. In accordance with how the command zone is configured, it is possible to: •... -
Page 33: Activations
User’s manual Via Keypad Method 1 Activate the shortcuts associated with keys , ..., (shown on the display) with or without code entry: • The shortcut assigned to the “Voice functions menu” (shortcut n.14: ) allows 18:23 01/02/2016 you to view the “Voice functions” section. Select the required function by means of DDDDDDD keys then press... - Page 34 • Sync IP2RX - if activated, the control panel will send a specific string to the IP2RX 18:23 01/02/2016 software in order to allow its identification. DDDDDDD • Cloud enrollment - this option allows the SmartLiving panel to access INIM Electronics cloud service (future use). Via Keypad Method 1...
-
Page 35: View
User’s manual Following is a list of the sections relating to the elements you can activate by tapping the ACTIVATE button. Each section presents its own elements arranged in list form. Each element is associated with two buttons - ON for activation and OFF for inhibition, and an icon which changes in accordance with the status: •... - Page 36 Centrali anti-intrusione • Shortcut n.16 ( ) accesses “View/NexusStatus”: 1° line: GSM network provider (Wind, Tim, Vodafone, etc.), on the left side and BUS connections on the right side of the string: - if nothing appears, it means that the Nexus/G is connected to the BUS - if the letter “G”...
- Page 37 User’s manual Via Web and AlienMobile Access to the system via web browser and mobile phone allows users to view other parts of the system through their respective sections: • Partitions • Zones • Commands Following is a table showing the meaning of the various icons positioned at the side of the description of the element displayed: Table 5-1: Viewing via web browser and mobile phone Section...
-
Page 38: Activation Of Outputs
Centrali anti-intrusione Activation of outputs This section allows you to activate/deactivate manually the outputs the code is enabled to work on. You can activate/deactivate low-power open-collector or relay outputs and view their status by means of the respective icons. You can activate/deactivate high-power relay outputs and view their supplied voltage and relative power factor (cos ). -
Page 39: Change Date And Time
User’s manual Via Web and AlienMobile Access the “Commands” section. This section provides a list of the control panel outputs and two buttons: • ON to activate the output, when activated the corresponding icon becomes • OFF to deactivate the output, when deactivated the corresponding icon becomes •... - Page 40 Centrali anti-intrusione •• Beep on output - if enabled, the buzzer will emit audible signals during partition 18:23 01/02/2016 Exit time. DDDDDDD •• Disable chime - if enabled, the buzzer will not emit audible signals when a bell zone is violated. These settings apply only to the keypad you are working on, and will be saved even in the event of panel shutdown.
-
Page 41: Change Pin
User’s manual You can select the parameter by means of “+” and “-”. To confirm changes and exit the section tap SAVE. Note English is the default language of the Alien keypad. Change PIN This section allows you to change the User Code PIN you used for access and also the 18:23 01/02/2016 PINs of other users with a lower rank in the system hierarchy (refer to paragraph 2-5 User Codes). -
Page 42: Teleservice Request
Centrali anti-intrusione 5-11 Teleservice request 18:23 01/02/2016 This command sends a call to the installer company. DDDDDDD Your installer must enable control panel option “Num15ForTeleserv”, otherwise this function will not be available. Via Keypad Method 2 Method 1 Type in code Activate theshortcut assigned to the “Teleservice req.”... -
Page 43: Thermostat
User’s manual 5-13 Thermostat The “Thermostat” function, provided by JOY/MAX and Alien keypads, manages the heating or air-conditioning system in accordance with its setting. • - Summer/Cooling: when the sensor detects that the temperature has risen above the value set by the user, the output connected to the air-conditioning system will activate (indicated on the display by •... -
Page 44: Teleservice Via Nexus
Centrali anti-intrusione Via AlienMobile On accessing the “Climate” section you will find a list of all the keypads configured with the thermostat function. If there is only one keypad, you will immediately access the thermostat configuration page. Each listed keypad will show: •... - Page 45 User’s manual User Code Table 5-2: Combinations “text menu” and “user menu” Manage alarms Case Text menu User menu Description Arm/Disarm ops. Voice functions Accesses the user-menu (shown as a list of operations the user is enabled to per- form); at this point the user can scroll Disabled Enabled the list using...
-
Page 46: Timer Programming
Centrali anti-intrusione 3. Press to confirm and exit. 4. If the shortcut is associated with “Arm/Disarm” operations, the application will ask you to select a scenario. If the associated shortcut is “Activate output” or “Deactiv. output”, the application will ask you to select the output. •... -
Page 47: Listen-In
User’s manual 5-17 Listen-in This function can be activated over-the-phone only. Users communicating with the control panel over-the-phone can activate the Listen-in function and eavesdrop on the protected premises. This is made possible by the microphones on voice-capable keypads which have at least one partition in common with the entered telephone code. -
Page 48: The Control Panel
Centrali anti-intrusione 5-19-2 User to panel calls If the “Answerphone” function (refer to paragraph 5-4 Activations) is enabled, users can call the control panel from any remote telephone and send commands to the system (refer to paragraph 3-2 Shortcut with code) and/or activate Listen-in sessions (refer to paragraph 5-17 Listen-in) in the following way. -
Page 49: Alien Function Keys
User’s manual <xxxxxx> EXC <zone description> where: •• <xxxxxx> is the PIN of a control-panel user coded, followed by a blank space •• “EXC” (or “ESC” or “INC”) is the command to be implemented on the zone, followed by a space ••... - Page 50 Centrali anti-intrusione Table 5-3: Alien menu Function Icon/key Alien keypad Web interface AlienMobile Accesses two sections: You access a section containing the list • “Real-time” - where the configured of cameras configured in the AlienMo- cameras are listed bile “Settings” section. •...
-
Page 51: Using The Smartlan/G
Option Example SmartLiving control Text, edited by the installer, associated with Subject panel [Valid code ] the respective event (in square brackets). Sender SmartLAN@inim.biz Parameters set by the installer User1@inim.biz, Recipient User2@inim.biz --------------------- 01/04/2016 18:23:00 Valid code The first part of the e-mail shows the date and... -
Page 52: Using Alienmobile Application
Centrali anti-intrusione 2. At this point the control panel will display the access page template which requires the following data (provided by the installer): Username Password Code (user code valid for the control panel) If the installer code is entered, it will be accepted only if the Teleservice function is enabled (paragraph 5-4 Activations). -
Page 53: Photo Frame
User’s manual Table 5-5: AlienMobile - home page Firmware version, type and description of the SmartLiving control panel. Mobile connection-type icon: • Mobile data • WiFi Section for the active functions, with access buttons to the application and the SmartLiving system. The home page of the Alien/G (shown in the figure) shows the function buttons indicated in Table 5-3: Alien menu. -
Page 54: Graphic Maps
Centrali anti-intrusione • From the Alien keypad - access the “Apps” section by tapping the button , then tap the “Photo frame” button. • Automatically, if the value set for the “Delay photo” parameter is different from “Disabled”. In order to change this parameter and others of the Alien keypad and the application, access the “Settings”... -
Page 55: Alarm Clock And Memo
User’s manual Table 5-6: Graphic map icons at default Subject Icon BUTTON Subject Icon BUTTON After a valid code entry you can deactivate instantly the outputs Stop Output activated activated by zone/partition alarm alarms and tamper events and system Output switches sta- tamper events. -
Page 56: Camera Access
Centrali anti-intrusione 5-26 Camera access The user can view the video recording made by the IP cameras through the Alien interface, the web browser, the AlienMobile application (“AlienMobile+”version) or keypad. Via Graphic maps Access to the graphic maps allows direct viewing on the display or screen associated with the “Camera”... -
Page 57: Appendix A Technical Terminology And Glossary
User’s manual Appendix A TECHNICAL TERMINOLOGY AND GLOSSARY ACCESS CODES These are 4, 5 or 6 digit PINs which allow the building occupants (users) to access the system. Each code can be programmed to control specific functions only, and to operate the system to suit the requirements of the Main user. - Page 58 Centrali anti-intrusione This device allows the control panel to send report calls to Alarm Receiving centres (ARC). DIGITAL DIALLER SmartLiving control panels provide a built-in digital dialler which supports all the most widely used protocols. ENTRY TIME (OR The time (expressed in minutes or seconds) that the system allows the user to disarm the partition after zone violation.
- Page 59 User’s manual A zone that monitors the inside of the protected building. INTERIOR ZONE For example, the interior zones of an office building are the zones that monitor offices and entrance points. If a partition that a zone belongs to is armed in Stay mode, it will be unable to generate alarms. IP CAMERA A camera is an electronic instrument that records bidirectional images in sequence.
- Page 60 Centrali anti-intrusione This device allows users to access and control the system. The system readers are connected to the READER control panel via the I-BUS. The readers allows users to arm/disarm the partitions which are common to both the reader and key in use (refer to Shortcuts).
-
Page 61: Appendix B Shortcuts At Default
User’s manual Appendix B SHORTCUTS AT DEFAULT Icon description function parameter Icon description function which sce- Accesses the user menu Arm/Disarm Applies a pre-set scenario Voice memo nario section: Voice functions Immediately deactivates the outputs relative to Accesses the user menu Stop alarms zone/partition alarm and Output control... -
Page 62: Appendix C Fault Signals
Centrali anti-intrusione Appendix C FAULT SIGNALS The following table shows the system faults which are signaled on the yellow LED on the keypad Message on the User menu, FAULT Probable cause Note “View/Faults” Excessive current draw on the “+AUX” terminals of Zone fuse fault Zone fuse blown the control panel... -
Page 63: Notes
Installation and programming manual Notes... - Page 64 Anti-intrusion control panels ISO 9001 Quality Management certified by BSI with certificate number FM530352 via Fosso Antico Loc. Centobuchi 63076 Monteprandone (AP) ITALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz...
