  • Page 1 GameOver USER’S MANUAL...
  • Page 2: Warranty

    24 months. As INIM Electronics s.r.l. does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;...
  • Page 3: Table Of Contents

    User’s Manual Table of contents Warranty ....... . . 2 Limited Warranty .
  • Page 4 User’s Manual 5-15 Using the SmartLAN/G ......35 Appendix A Technical terminology and Glossary ..36 Appendix B Shortcuts at default .
  • Page 5: General Information

    Web: www.inim.biz Any persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on INIM Electronics brand devices only. Description of the product and various models Description: Intrusion control panel...
  • Page 6: Manuals

    User’s Manual Manuals 1-3-1 Installation Manual The installer should read carefully through the Installation Manual and should be familiar with all the components and the operating procedures of the SmartLiving system. In order to provide adequate protection, you (the installer) must adhere to all the manufacturer's guidelines relating to the active and passive security devices of this system.
  • Page 7: Chapter 2 The Smartliving System

    INIM Electronics recommends that all parts of this manual be read thoroughly before starting up SmartLiving system. Once you have become accustomed to the day-to-day operations, your installer will explain and if required, program the advanced functions provided by the system.
  • Page 8: The Technologies

    User’s Manual The Technologies Expertise in the arena of total security and a commitment to precision and high quality allow INIM's R & D professionals to deliver excellence in design technology and dependability through time. 2-2-1 EASY4U This user-friendly tool provides an interesting array of graphic features and functions.
  • Page 9: Information

    User’s Manual normal circumstances, operations which increase system security can be allowed without valid-code entry whereas, operations which lower system security (Disarm, Delete Alarm/Tamper memory, Deactivate Alarm/Tamper outputs) should be allowed only after valid-code entry. Each keypad is assigned (by the installer) to the partitions it controls. 2-3-1 Display - description The brightness and contrast of the backlit-graphic LCD (96 x 32 pixel) can...
  • Page 10: Using The Keypad

    User’s Manual 2-3-2 Display - standby status If the control panel is in Maintenance status, the first line on the M a i n t e n a n K 0 3 P 0 5 screen will show the string indicated in the figure. The characters D A S I D A S I - - “K03”...
  • Page 11: Timer

    User’s Manual 2-3-4 Emergency keys This control panel provides 3 "key-duos" for Emergency Calls which can be activated by pressing the respective keys on any of the system keypads: 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 D A S I D A S I - - = Fire Emergency = Ambulance Emergency...
  • Page 12: Reader - Nby

    User’s Manual 2-3-7 Emergency status In the event of keypad configuration error or communication error between - J O Y / M A X - the system peripherals, the display will show one of the screens opposite. F W R E L E A S E 1 .
  • Page 13: User Codes

    User’s Manual 2-4-1 Signaling on the Reader LEDs The LEDs have two distinct operating in modes: 1. Reader LEDS with no key at the reader (refer to Table 5: Reader LEDs with no key at reader), the LEDs will show the current operat- ing status of the reader partitions.
  • Page 14 User’s Manual • Partitions - User codes can control only the partitions they are assigned to. If a user code is entered at a keypad, the user can control only the partitions which are common to both the code and keypad concerned.
  • Page 15: Keys

    Keys The SmartLiving system is capable of managing INIM's contact-free digital- keys, which are available in three versions: • nKey - Proximity key • nCard - proximity card •...
  • Page 16: Multi-System Access

    User’s Manual Feedback signals provided by KF100 wireless keyfob Table 7: Push Icon LED 1 LED 2 LED 3 LED 4 Buzzer signal Operation button 1 flash beep Shortcut activation 1 1 flash beep Shortcut activation 2 1 flash beep Shortcut activation 3 1 flash beep...
  • Page 17: Web / E-Mail Functions

    User’s Manual WEB / e-mail functions All SmartLAN/G equipped SmartLiving control panels are capable of sending event associated e-mails (SmartLAN/G is an optional accessory board). The e-mail text, subject, attachments and recipients must be edited by your installer. You must not make any changes whatsoever to the e-mail structure.
  • Page 18: Chapter 3 Shortcuts

    User’s Manual Chapter 3 SHORTCUTS 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 Keypad shortcuts D A S I D A S I - - Each keypad can be programmed with up to 12 shortcuts associated with 4 function keys .
  • Page 19: Shortcut With Code

    User’s Manual Shortcut with code Besides keypad shortcuts provided keys , each user code can have as many as 22 customized (personal) shortcuts. Users can access their code-shortcuts by entering their PINs and pressing (refer to paragraph 2-5-1 Accessing the User Menu). Each code can be programmed to manage: •...
  • Page 20: Shortcut List

    User’s Manual 3-3-2 Shortcuts on JOY/MAX-keypad readers K e y R u p e r t Hold a valid key in the vicinity of the reader area of the JOY/MAX keypad, A r m / d i s a r m indicated by .
  • Page 21: Chapter 4 Voice Functions

    User’s Manual Chapter 4 VOICE FUNCTIONS If the SmartLiving control panel is equipped with a SmartLogos30M voice board, you will be able to take advantage of all the voice functions provided by the JOY/MAX keypad, and the over-the-phone voice guide. Your installer will program the voice messages you require: •...
  • Page 22: Chapter 5 Using The System

    User’s Manual Chapter 5 USING THE SYSTEM This chapter describes all the operations users can carry out with or without authorization (user PIN entry). The tools and methods which allow access the system operations are as follows. The system can be accessed: •...
  • Page 23: Arming And Disarming Partitions

    User’s Manual Arming and disarming partitions Via Keypad 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 Method 1 D D D D D D D D - - Activate the shortcuts associated with keys (shown on the display) with or without code entry.
  • Page 24: Managing Alarms

    User’s Manual via Web Icon Arm selected partition in Away mode Access the SmartLAN/G web-server and press button. Use the mouse to select a partition then press the buttons shown opposite to: Arm selected partition in Stay mode Arm selected partition in Instant mode Disarm selected partition Managing alarms...
  • Page 25: Voice Functions And Intercom (Joy/Max Only)

    User’s Manual via Wireless keyfob Push the respective button on the keyfob and verify the outcome of the requested operation, as described in paragraph 2-6-1 Air2-KF100 Wireless keyfobs. via Web Access the SmartLAN/G web-server and press button. Use the mouse to select a partition then press button to delete the alarm memory and, if allowed, tamper memory.
  • Page 26: Activations

    User’s Manual Activations The activation/deactivation of the SmartLiving system peripherals and elements (described in the following section) enables them to operate in accordance with their settings (activation) or disables their functions completely (deactivation). The user has full control over activation/ deactivation of the SmartLiving system peripherals and elements.
  • Page 27: View

    User’s Manual 2. Use keys followed by , to select the single element. 3. Use to activate the selected element or to deactivate it. • Other shortcuts which provide direct access to sub-sections of the “Activations” section are: •• Shortcut n.19 ( ) accesses “Activations/Zones”...
  • Page 28: Information

    User’s Manual Via Keypad Method 1 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 Activate the shortcuts associated with keys (shown on the D D D D D D D D - - display) with or without code entry.
  • Page 29 User’s Manual Press the button. Use the mouse to select a partition and view (in the top section) all the partition zones the user controls: Zone Zone status Bypassed status Test Alarm memory Tamper memory No alarm No tamper Zone in Zone in test Zone bypassed empty...
  • Page 30: Activating/Deactivating Outputs

    User’s Manual Activating/Deactivating outputs This section allows you to activate/deactivate manually the outputs the 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 code controls. D D D D D D D D - - Via Keypad Method 1 Activate the shortcuts associated with keys...
  • Page 31: Change Date And Time

    User’s Manual Change date and time 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 D D D D D D D D - - This option allows you to set the date and time in accordance with the selected format.
  • Page 32: Change Pin

    User’s Manual Method 2 Access the “Keypad settings” section of the User Menu by means of a valid PIN. Follow the instructions described in Method 1. Change PIN 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 This section allows you to change your User Code PIN.
  • Page 33: Overtime Request

    User’s Manual 5-11 Overtime request This operation can be carried out under the following conditions only. 1 8 : 2 3 2 0 / 0 8 / 2 0 0 8 • The partition concerned must be timer-controlled. D D D D D D D D - - •...
  • Page 34: Partition Status Enquiry

    User’s Manual 5-13 Partition status enquiry This function can be activated over-the-phone only. The Partition status enquiry function allows you to listen to voice announcements regarding of the armed/disarmed status of the partitions during telephone communications with the control panel, or by activating the corresponding shortcut from a JOYMAX keypad.
  • Page 35: Using The Smartlan/G

    Option Example SmartLiving control Text, edited by the installer, associated with Subject panel [Valid code ] the respective event (in square brackets). Sender SmartLAN@inim.biz Parameters set by the installer User1@inim.biz, Recipient User2@inim.biz --------------------- 01/01/09 18:23:00 Valid code The first part of the e-mail shows the date...
  • Page 36: Appendix A Technical Terminology And Glossary

    User’s Manual Appendix A TECHNICAL TERMINOLOGY AND GLOSSARY ACCESS CODES These are 4, 5 or 6 digit PINs which allow the building occupants (users) to access the system. Each code can be programmed to control specific functions only, and to operate the system to suit the requirements of the Main User.
  • Page 37: Information

    This device allows the system to send calls over the GSM network. The SmartLink is a custom GSM interface for INIM control panels. This device is capable of providing the control panel with a telephone line even in the event of telephone line tamper (line cutting).
  • Page 38: General

    User’s Manual A zone that monitors the inside of the protected building. INTERIOR ZONE For example, the interior zones of an office building are the zones that monitor offices and entrance points. If a partition that a zone belongs to is armed in Stay mode, it will be unable to generate alarms.
  • Page 39 User’s Manual This device allows users to access and control the system. The system readers are READER connected to the control panel via the I-BUS. (NBY) The key (TAG) allows the user to activate shortcuts (refer to Shortcuts) and arm/disarm the partitions which are common to both the key (TAG) and reader in use.
  • Page 40: Appendix B Shortcuts At Default

    User’s Manual Appendix B SHORTCUTS AT DEFAULT ICON description function parameter ICON DESCRIPTION function ZoneBypass Accesses the User Menu Arm/disarm Applies a pre-set scenario Scenario menu section: Activations/Zones Immediately deactivates the outputs relative to Accesses the User Menu Stop alarms zone/partition alarm and Voice memo section: Voice functions...
  • Page 41: Appendix C Fault Signals

    User’s Manual Appendix C FAULT SIGNALS The following table shows how system faults, indicated by the yellow LED, are signaled clearly on the keypad User menu string: “View/ FAULT Probable cause Solution Faults” Excessive current draw on the Zone fuse fault Zone fuse blown “+AUX”...
  • Page 42 User’s Manual Fault signals...
  • Page 43: Notes

    User’s Manual Notes...
