- Page 1 Installation and programming manual NRB100 Self-powered hornstrobe for outdoor use Installation and programming manual...
-
Page 2: Table Of Contents
NRB100 Self-powered hornstrobe Table of contents Table of contents........2 Chapter 1 Overview . -
Page 3: Chapter 1 Overview
Any persons authorized by the manufacturer to repair or replace any part of this device hold authorization to work on INIM Electronics devices only. Product description The heavy duty NRB100 hornstrobe unit is especially designed to allow maximum installation flexibility and durability. A microprocessor continuously monitors all the device parameters and assures high- reliability and first-rate performance. -
Page 4: Chapter 2 Hornstrobe Description
Self-powered hornstrobe Chapter 2 HORNSTROBE DESCRIPTION Box contents Inside the box you will find: • NRB100 hornstrobe • 2 frontplate screws (4x22) • 3 wall plugs (screw 4x35) for mounting the backplate • 1 wall plug (screw 3.5x50) for tamper microswitch •... - Page 5 Installation and programming manual Table 2: Description of parts Terminal board Programming button Battery wires Jumpers for tamper balance configuration STATUS LED - Red PRG LED - Green Red programming LEDs Strobe Open casing and Dislodgement tamper microswitch Frontplate Grill Frontplate screw locations Cable entry Backbox screw locations...
- Page 6 NRB100 Self-powered hornstrobe WARNING! Do not touch the hornstrobe board while the Mains is connected. Electric shock risk! Hornstrobe description...
-
Page 7: Lights Signalling
Installation and programming manual Table 4: Tamper device Tamper screw Spacer Microswitch Screw location Microswitch-block location Rawplug Frontplate screw Frontplate screw location Lights signalling STROBE FLASHER The strobe (Table 2, H) will flash at 2 second intervals in the event of tamper (wire cutting) or when activated via the +-F terminal. -
Page 8: Chapter 3 Installation
NRB100 Self-powered hornstrobe Chapter 3 INSTALLATION The hornstrobe should be mounted high up on an even surface, in such way that it is out of reach but clearly on view and therefore may serve as a visible deterrent against break-in. -
Page 9: Wire Connection
Installation and programming manual 3 wire connection This wiring method triggers alarm signalling on the both the horn and strobe through the +-B and +-F inputs. The +-B and +-F inputs must be configured as "Negative Removed" (refer to Table 6 "Programming phases"). -
Page 10: Chapter 4 Programming
NRB100 Self-powered hornstrobe Chapter 4 PROGRAMMING The Hornstrobe can be programmed only during the installation, therefore, it is necessary to ensure that: • the device is not powered; battery and mains must be disconnected • the tamper microswitch is open •... -
Page 11: Warranty
24 months. As INIM Electronics s.r.l. does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;... - Page 12 ISO 9001 Quality Management certified by BSI with certificate number FM530352 via Fosso Antico snc - fraz. Centobuchi 63076 Monteprandone (AP) ITALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz...
