- Page 1 BEDIENUNGS- UND MONTAGEANWEISUNG EN User Manual EMWK6550.0...
-
Page 2: Table Of Contents
Contents Safety Information ..........................41 Safety Instructions ........................... 44 The advantages of microwaves ....................... 45 Description of your oven ........................46 Basic controls ........................... 48 Basic Functions ..........................50 Special functions ..........................54 When the oven is working........................ 57 Defrosting ............................ -
Page 3: Safety Information
Safety Information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. CHILDREN AND VULNERABLE PEOPLE SAFETY Warning! Risk of suffocation, injury or permanent disability. - Page 4 Safety Information Warning! The oven cannot be used if: - The door is not closed correctly; - The door hinges are damaged; - The surfaces of the contact between the door and the oven front are damaged; - The door window glass is damaged; - There is frequent electrical arcing inside the oven even though there is no metal object inside.
- Page 5 Safety Information Do not use a steam cleaner to clean the appliance. The door contact surfaces (the front of the cavity and the inside part of the doors) must be kept very clean in order to ensure the oven functions correctly. ...
-
Page 6: Safety Instructions
Safety Instructions Avoid Warning! Do not heat pure alcohol or damaging oven other dangerous situations by following these alcoholic drinks in the microwave. FIRE instructions: RISK! Do not switch on the oven without the Beware! turntable support, the turntable ring and the ... -
Page 7: The Advantages Of Microwaves
The advantages of microwaves In conventional ovens, heat radiated by electrical Why food heats up elements or gas burners slowly penetrates the Most foods contain water and water molecules food from outside to inside. On account of this vibrate when subjected to microwaves. there is a major amount of energy is wasted heating the air, the oven components and the food The friction between molecules produces heat... -
Page 8: Description Of Your Oven
Description of your oven 1. – Door window glass 8. – Lamp bulb 2. – Catches 9. – Control panel 3. – Turntable support 10. –Backing tray (Don’t use with microwaves) 4. – Turntable ring 5. –Turntable plate 11. – Rectangular rack (Don’t use with microwaves) 6.- Drop-down grill 7. - Page 9 Description of your oven Description of Functions Microwave Power Symbol Function Foods Output Slow defrosting for delicate foods; keeping food hot. 200 W Cooking with little heat; boiling rice. 400 W Rapid defrosting, heating baby food. Heating and cooking food. 600 W Microwave Cooking vegetables and food.
-
Page 10: Basic Controls
Basic controls Setting the clock necessary when the oven is first plugged in After connecting the appliance to the network or after a power failure). or after a power failure the clock will flash 3. Press the “+” and “–” keys to set the hours. and thus shows that the time is not correct. - Page 11 Basic controls Stopping the rotating plate If the turntable rotation disturbs you, you can stop The turntable stops. it by proceeding as follows. If you want to allow the turntable to rotate, While the oven is being programmed or during the press again the “<”...
-
Page 12: Basic Functions
Basic Functions Microwave oven Use this function to cook and heat vegetables, potatoes, rice, fish and meat. 1. Press the “On/Off” key to switch the oven on. 5. Press the “+” and “–” keys to set the required Microwave Power Level (see the chapter 2. - Page 13 Basic Functions Microwave + Grill Use this function to cook lasagne, poultry, roast potatoes and toasted foods. 1. Press the “On/Off” key to switch the oven on. 5. Press the “+” and “–” keys to set the required Microwave Power Level (see the chapter 2.
- Page 14 Basic Functions Microwave + Hot air Use this function to bake and roast 1. Press the “On/Off” key to switch the oven 6. Press the “>” key. The display shows: 7. Press the “+” and “–” keys to set the required 2.
- Page 15 Basic Functions Defrosting by weight (automatic) Use this function to defrost meat, poultry, fish, fruit and bread quickly. 1. Press the “On/Off” key to switch the oven on. 7. Press the “+” and “–” keys to set the desired Food Weight. 2.
-
Page 16: Special Functions
Special functions Special Function P1: Heating food Use this function to heat various types of food. 1. Press the “On/Off” key to switch the oven on. 7. Press the “+” and “–” keys to set the desired Food Weight. 2. Press the “Auto-cook programs” key “P“. 8. - Page 17 Special functions Special Function P2: Cooking Use this function to cook fresh food. 1. Press the “On/Off” key to switch the oven on. 6. Press the “>” key to enter the weight parameters 2. Press the “Auto-cook programs” key. The key turns red “P“.
- Page 18 Special functions Special Function P3: Defrosting & Toasting Use this function to cook and toast various types of food. 1. Press the “On/Off” key to switch the oven on. 7. Press the “+” and “–” keys to set the desired Food Weight.
-
Page 19: When The Oven Is Working
When the oven is working... Interrupting a cooking cycle Cancelling a cooking cycle You can stop the cooking process at any time by If you wish to cancel the cooking process, press pressing the Stop key once or by opening the the Stop key for 3 seconds. -
Page 20: Defrosting
Defrosting The table below shows different defrosting and temperature is evenly distributed) for different types standing times (in order to ensure the food and weights of food, plus recommendations. Standing time Food Weight (g) Defrosting time (min) Recommendation (min) 5-10 Turn once 5-10 Turn once... - Page 21 Defrosting General instructions for defrosting 1. When defrosting, use only dishes that are 8. Place poultry on an upturned plate so that the appropriate for microwaves (china, glass, meat juices can run off more easily. suitable plastic). 9. Bread should be wrapped in a napkin so that 2.
-
Page 22: Cooking With A Microwave Oven
Cooking with a microwave oven When heating liquids, use containers Warning! Read the section “Microwave Safety” with a wide opening, so that the steam before cooking with your microwave. can evaporate easily. Follow these recommendations when cooking with Prepare the foods as per the instructions and your microwave: keep in mind the cooking times and power levels ... - Page 23 Cooking with a microwave oven Tables and suggestions – Cooking vegetables Addition of Power Time Standing Food Quantity (g) Instructions liquids (Watt) (min.) Time (min.) Cauliflower 100ml 9-11 Cut into slices. Keep covered Broccoli 50ml Turn once Mushrooms 25ml Cut into chunks or Peas &...
-
Page 24: Cooking With The Grill
Cooking with the grill For good results with the grill, use the grid iron 4. If the grill is used for extended period of time supplied with the oven. it is normal to find that the elements will switch themselves off temporarily due to the Fit the grid iron in such a way that it doesn’t safety thermostat. - Page 25 Cooking with the Grill Tables and suggestions – Microwave + Grill The microwave + grill function is ideal for cooking The microwave and the grill work simultaneously. quickly and, at the same time, browning foods. The microwave cooks and the grill toasts. Furthermore, you can also grill and cook cheese covered food.
-
Page 26: Roasting And Baking
Roasting and baking Table and advices – Preparing meat and cake Microwave / Hot air Quantity Power Temperature Time Standing Food Instructions ºC (Min.) time (min.) Do not put lid on Roast beef 1000-1500 30-40 container Turn once Pork loin / Cutlet Do not put lid on or bones 800-1000... - Page 27 Roasting and baking Advice to roast - bake Advice on ovenware Turn the pieces of meat halfway through the Check that the ovenware fits inside the oven. cooking time. When the roasted meat is ready you Hot glass containers should be put on a dry should let it stand for 20 minutes in the oven with kitchen cloth.
- Page 28 Baking Table and advices – baking/hot air Type Container Level Temperature Time (min.) Walnut cake Spring-form type tin Turntable 170/180 30/35 Spring-form type tin Ø 28 Turntable, small Fruit tart 150/160 35/45 round grille Ring cake Spring-form type tin Turntable 170/190 30/45 Piquant cakes e.g.
-
Page 29: What Kind Of Ovenware Can Be Used
What kind of ovenware can be used? Microwave function Aluminium containers and foil For the microwave function, keep in mind that Pre-cooked food in aluminium containers or in microwaves are reflected by metal surfaces. aluminium foil can be put in the microwave if the Glass, china, clay,... - Page 30 What kind of ovenware can be used? Table of Ovenware The table below gives you a general idea of what type of ovenware is suitable for each situation. Operating mode Microwave Combined Grill / Hot- Air Defrosting / functions Type of Cooking heating ovenware...
-
Page 31: Oven Cleaning And Maintenance
Oven Cleaning and Maintenance Cleaning is the only maintenance normally Oven interior required. After each time the oven is used, clean the inside Warning! Your microwave oven should be walls with a damp cloth since this is the easiest cleaned regularly, with all food remains being way to remove splashes or spots of food that may removed. - Page 32 Oven Cleaning and Maintenance The mica cover (3) located in the ceiling must Oven ceiling always be kept clean. Any food remains that If the oven ceiling is dirty, the grill can be lowered collect on the mica cover can cause damage or to make cleaning easier.
-
Page 33: What Should I Do If The Oven Doesn't Work
What should I do if the oven doesn’t work? The food is too hot, dried out or burnt! WARNING! Any type of repair must only be Check if you selected the correct operating done by a specialised technician. Any repair time and power level. -
Page 34: Technical Characteristics
Technical characteristics Specifications AC Voltage ................... (see characteristics plate) Power required ................3400 W Grill power..................1500 W Hot air power ................1500 W Microwave output power.............. 1000 W Microwave frequency… ..............2450 MHz ... -
Page 35: Installation Instructions
Installation instructions Before installation After installation Check that the input voltage indicated on the The oven is equipped with a power cable and a characteristics plate is the same as the voltage of plug for single phase current. the power outlet you are going to use. If the oven is to be installed on a permanent Open the oven door and take out all the basis it should be installed by a qualified... -
Page 36: Installation
Einbau / Installation Die Mikrowelle in die Nische einschieben entsprechend anpassen. Die Tür der Mikrowelle öffnen und Gerät vier mitgelieferten Schrauben Küchenmöbel Bild dargestellt befestigen. Push oven completely into the cabinet and centre it. Open microwave door and fasten the appliance to the cabinet using the four screws provided. - Page 37 Küppersbusch Hausgeräte GmbH Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Teka Austria GmbH Eitnergasse 13, A-1230 Wien Telefon: (01) 8 66 80-15, Telefax: (01) 8 66 80-50 www.kueppersbusch.at...
