Summary of Contents for Harman JBL EON 315

  • Page 3: Table Of Contents

    Contents Section 1: Welcome To The Family ..............Before You Begin - Important Information ..............Section 2: Precautions Watch For These Symbols ..................AC Power Requirements ..................... CAUTION ........................Power Amplifiers - Operating Temperature ............® Care and Maintenance ....................Mounting / Suspending EON Speakers ..............
  • Page 4: Section 1: Welcome To The Family

    Section 1: Welcome To The Family Thank you for choosing JBL Professional EON Series loudspeakers. Since the launch of the very first EON ® systems in 1995 they have proven to be the loudspeaker system that is all things to everyone and as such remain the best selling powered speaker in professional audio history;...
  • Page 5: Before You Begin - Important Information

    Before You Begin - Important Information Before using your EON speaker system please review the following for important ® information on safety and protection of your investment in quality loudspeakers. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4.
  • Page 6: Section 2: Precautions Watch For These Symbols

    Section 2: Precautions Watch For These Symbols The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated. “Dangerous Voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 7: Mounting / Suspending Eon ® Speakers

    THIS APPARATUS CONTAINS POTENTIALLY LETHAL VOLTAGES. TO PREVENT ELECTRIC SHOCK OR HAZARD, DO NOT REMOVE CHASSIS, INPUT MODULE OR AC INPUT COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Mounting / Suspending EON Speakers ® EON speakers are designed for portable applications in which the speakers will be stacked directly on the floor, stage, speaker stands, or a solid, stable platform.
  • Page 8: Eon ® Series Speakers Declaration Of Conformity

    Series Speakers Declaration Of Conformity ® Safety And EMC Compliance Specifications EN 55103-1:1997 Electromagnetic Compatibility - Product Family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control Apparatus for Professional Use, Part 1: Emissions EN 55103-1:1997 Magnetic Field Emissions-Annex A@ 10 cm and 20 cm EN 55022:2003 Limits and Methods of Measurement of Radio Disturbance Characteristics of ITE: Radiated, Class B Limits;...
  • Page 9: Section 3: Quick Start

    Section 3: Quick Start Congratulations on your purchase of JBL Professional EON Series loudspeakers! We know you ® are anxious to get up and running as fast as possible, which is why you are reading this section. The following will help you get set up as soon as possible. Packaging Contents Your EON315 system should include the following: 1 x EON315 speaker...
  • Page 10: Section 4: About The Eon315 Applications

    Section 4: About the EON315 Applications • Live sound reinforcement, speech and vocals, music playback in entertainment, A/V, and institutional venues - especially when ease of use and portability are important factors. • Amplification, mixing, and monitoring for electronic musical instruments. •...
  • Page 11: Eon315 Specifications

    EON315 Specifications System Type: Self powered 15", two-way, bass-reflex design Frequency Range (-10 dB): 38 Hz - 20 kHz (EQ in ‘Flat’ position) Frequency Response (±3 dB): 50 Hz - 18 kHz (EQ in ‘Flat’ position) Coverage Pattern: 100º x 60º nominal Directivity Index (DI): 9 dB Directivity Factor (Q):...
  • Page 12: Back Panel

    Back Panel...
  • Page 13 Back Panel...
  • Page 14 Back Panel...
  • Page 15: Section 5: Loudspeaker Placement And Suspension

    Section 5: Loudspeaker Placement and Suspension The following guidelines will help you achieve optimum sound wherever you use your EON loudspeakers: ® Raise the speakers as high as possible. For best results try to get the high frequency horn at least 2 to 4 feet above the heads of the audience. If the speakers are too low, the people in the back of the audience will not receive the best quality sound.
  • Page 16: Using The Suspension Points

    Using the suspension points CAUTION: Suspension of EON speakers should be done by qualified persons following safe rigging standards ® and practices. Unsafe mounting or overhead suspension of any heavy load can result in serious injury and equipment damage. CAUTION: When suspending this product carefully follow JBL instructions and local ordinances. Do not attempt to use unless you have read and understood all instructions including the JBL User’s Guide.
  • Page 17: Section 6: Application Examples

    Section 6: Application Examples EON515 Simple PA Using Built-In Mixer Using the Mix/Loop function...
  • Page 18: Small Pa Using External Mixer Eon510

    Section 6: Application Examples EON510 Small PA Using External Mixer...
  • Page 19: Simple Pa Using External Mixer And Subwoofer Eon510 - Eon518S

    Section 6: Application Examples EON510 - EON518S Simple PA Using External Mixer and Subwoofer...
  • Page 20 Section 6: Application Examples EON315 - EON510 - EON518S Simple PA Using Built-In Mixer And Adding More Power Using the Mix/Loop function...
  • Page 21: Pa Using Powered Mixer And Powered Subwoofers Eon305 - Eon518S

    Section 6: Application Examples EON305 - EON518S PA Using Powered Mixer And Powered Subwoofers...
  • Page 22: Pa Using Powered Mixer And Powered Monitors Eon305 - Eon515

    Section 6: Application Examples EON305 - EON515 PA Using Powered Mixer And Powered Monitors...
  • Page 23: Daisy-Chaining A Pa System Eon315 - Eon510 - Eon515

    Section 6: Application Examples EON315 - EON510 - EON515 Daisy-Chaining a PA System Using the Mix/Loop function...
  • Page 24: Pa System With Powered Mains And Floor Monitors Eon510 - Eon515

    Section 6: Application Examples EON510 - EON515 PA System With Powered Mains and Floor Monitors Gigging with the built-in mixers only Using the Mix/Loop function...
  • Page 25: Section 7: Connection Types

    Section 7: Connection Types There are two basic types of audio system interconnections for audio signals: Balanced and Unbalanced. Your EON can accept either type of input. ® Balanced Lines In audio, a balanced line is a three-conductor system in which the two signal wires carry an equal, but opposite voltage with respect to the ground wire.
  • Page 26 Cables and Connectors (continued)
  • Page 27: Section 8: Trouble Shooting

    Section 8: Trouble Shooting Symptom Likely Cause What to do Speaker not connected Verify that speaker is connected and that the circuit is on No sound to active AC power Power not switched on Switch on power and verify that power LED is on Speaker power cable is faulty •...
  • Page 28: Section 9: Contact Information

    Section 9: Contact Information...
  • Page 29: Section 10: Warranty Information

    Section 10: Warranty Information The JBL Limited Warranty on professional loudspeaker products (except for enclosures) remains in effect for five years from the date of the first consumer purchase. JBL amplifiers are warranted for three years from the date of original purchase. Enclosures and all other JBL products are warranted for two years from the date of original purchase.
