- Page 1 USER’S GUIDE...
-
Page 3: Table Of Contents
Contents Section 1: Welcome To The Family ..............Before You Begin - Important Information ..............Section 2: Precautions Watch For These Symbols ..................AC Power Requirements ..................... CAUTION ........................Power Amplifiers - Operating Temperature ® ............. Care and Maintenance ....................Mounting / Suspending EON Speakers .............. -
Page 4: Section 1: Welcome To The Family
Section 1: Welcome To The Family Series loudspeakers. Since the launch of the very first EON Thank you for choosing JBL Professional EON ® systems in 1995 they have proven to be the loudspeaker system that is all things to everyone and as such remain the best selling powered speaker in professional audio history;... -
Page 5: Before You Begin - Important Information
Before You Begin - Important Information Before using your EON ® speaker system please review the following for important information on safety and protection of your investment in quality loudspeakers. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. -
Page 6: Section 2: Precautions
Section 2: Precautions Watch For These Symbols The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated. “Dangerous Voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 7: Mounting / Suspending Eon Speakers
THIS APPARATUS CONTAINS POTENTIALLY LETHAL VOLTAGES. TO PREVENT ELECTRIC SHOCK OR HAZARD, DO NOT REMOVE CHASSIS, INPUT MODULE OR AC INPUT COVERS. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Mounting / Suspending EON Speakers EON speakers are designed for portable applications in which the speakers will be stacked directly on the floor, stage, speaker stands, or a solid, stable platform. -
Page 8: Eon Series Speakers Declaration Of Conformity
Declaration Of Conformity Safety And EMC Compliance Specifications EN 55103-1:1997 Electromagnetic Compatibility - Product Family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control Apparatus for Professional Use, Part 1: Emissions EN 55103-1:1997 Magnetic Field Emissions-Annex A@ 10 cm and 20 cm EN 55022:2003 Limits and Methods of Measurement of Radio Disturbance Characteristics of ITE: Radiated, Class B Limits;... -
Page 9: Section 3: Quick Start
Section 3: Quick Start Congratulations on your purchase of JBL Professional EON ® Series loudspeakers! We know you are anxious to get up and running as fast as possible, which is why you are reading this section. The following will help you get set up as soon as possible. Packaging Contents Your EON515XT system should include the following: 1 x EON515XT speaker... -
Page 10: Section 4: About The Eon515Xt
Section 4: About the EON515XT EON515XT represents the natural evolution of a product whose creators have advanced the state of the art in professional audio for more than 60 years. With almost 1 million EON speakers in the world, more than any other powered loudspeaker, EON embodies “the survival of the fittest”. -
Page 11: Eon515Xt Specifications
EON515XT Specifications System Specification Self powered 15", two-way, bass-reflex System Type: Maximum SPL Output: 132 dB Frequency Range (-10 dB): 39 Hz -20 kHz Frequency Response (±3 dB): 42 Hz - 18 kHz Input Connectors: 2 x 1/4" TRS phone jacks balanced/unbalanced 1 x XLR / 1/4" TRS combo jack with XLR loop through Input Impedance: 14k ohms Signal Indicators:... -
Page 12: Back Panel
Back Panel... - Page 13 Back Panel See Section 6: Application Example – Using the Mix/Loop Function For details on how this mode may be used.
- Page 14 Back Panel...
-
Page 15: Section 5: Loudspeaker Placement And Suspension
Section 5: Loudspeaker Placement and Suspension ® The following guidelines will help you achieve optimum sound wherever you use your EON loudspeakers: Raise the speakers as high as possible. For best results try to get the high frequency horn at least 2 to 4 feet above the heads of the audience. If the speakers are too low, the people in the back of the audience will not receive the best quality sound. -
Page 16: Using The Suspension Points
Using the suspension points speakers should be done by qualified persons following safe rigging standards CAUTION: Suspension of EON ® and practices. Unsafe mounting or overhead suspension of any heavy load can result in serious injury and equipment damage. CAUTION: When suspending this product carefully follow JBL instructions and local ordinances. Do not attempt to use unless you have read and understood all instructions including the JBL User’s Guide. -
Page 17: Section 6: Application Examples
Section 6: Application Examples EON515XT Simple PA Using Built-In Mixer Using the Mix/Loop function 1/8” Mini Plug... -
Page 18: Small Pa Using External Mixer Eon510
Section 6: Application Examples EON515XT Small PA Using External Mixer... -
Page 19: Simple Pa Using External Mixer And Subwoofer Eon515Xt - Eon518S
Section 6: Application Examples EON515XT - EON518S Simple PA Using External Mixer and Subwoofer... -
Page 20: Daisy-Chaining A Pa System Eon510 - Eon515Xt - Eon315
Section 6: Application Examples EON510 - EON515XT - EON315 Daisy-Chaining a PA System Using the Mix/Loop function 1/8” Mini Plug... -
Page 21: Pa System With Powered Mains And Floor Monitors Eon515Xt - Eon510
Section 6: Application Examples EON515XT - EON510 PA System With Powered Mains and Floor Monitors Gigging with the built-in mixers only Using the Mix/Loop function... -
Page 22: Section 7: Connection Types
Section 7: Connection Types There are two basic types of audio system interconnections for audio signals: Balanced and Unbalanced. Your EON ® can accept either type of input. Balanced Lines In audio, a balanced line is a three-conductor system in which the two signal wires carry an equal, but opposite voltage with respect to the ground wire. - Page 23 Cables and Connectors (continued)
-
Page 24: Section 8: Trouble Shooting
Section 8: Trouble Shooting Symptom Likely Cause What to do Speaker not connected Verify that speaker is connected and that the circuit is on No sound to active AC power Power not switched on Switch on power and verify that power LED is on •... -
Page 26: Section 10: Warranty Information
Section 10: Warranty Information tern. The JBL Limited Warranty on professional loudspeaker products (except for enclosures) remains in effect for five years from the date of the first consumer purchase. JBL amplifiers are warranted for three years from thedate of original purchase. - Page 28 Part Number: 445387-001 10-26-10...
