Harman JBL EON 718S Quick Start Manual

EON7 18S
QUICKST ART GUIDE
1 . POWER ON THE UNIT
1. Connect the power cord to the
AC Power Connector
2. Press the Power Button [D]
second to engage power.
LCD Display
C
CH1 XLR- 1/4"
B
Combo Input
CH1 XLR Male
A
Loop Thru
(I).
for .5
2. PLUG IN THE INPUTS
1. Turn the Main Volume (E)
the LCD screen displays -100db before
connecting inputs.
2. Connect your devices to the
Input Jacks (B) (G).
3. Turn Main Volume (E)
volume is reached.
D
E
F
G
H
I
to the left until
until desired
Power
Main /
Menu Navigation
Back Button
CH2 XLR- 1/4"
Combo Input
CH2 XLR Male
Loop Thru
AC Power Connector
