63" x 55" Corner Electric Desk
Instruction Manual
SKU: DESK-E3CT SERIES
Frame:
Table Top:
DESK-E355B
DESK-E3CTB-A
DESK-E355G
DESK-E3CTC-A
DESK-E355W
ASSEMBLY VIDEO AVAILABLE:
Follow along step-by-step with our video walk through by scanning
the QR code with your mobile device or by following the product
link: vivo-us.com/products/desk-e3ctb
help@vivo-us.com
DESK-E3CTD-A
DESK-E3CTN-A
DESK-E3CTG-A
DESK-E3CTW-A
www.vivo-us.com
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo DESK-E355G
Summary of Contents for Vivo DESK-E355G
- Page 1 SKU: DESK-E3CT SERIES Frame: Table Top: DESK-E355B DESK-E3CTB-A DESK-E3CTD-A DESK-E3CTN-A DESK-E355G DESK-E3CTC-A DESK-E3CTG-A DESK-E3CTW-A DESK-E355W ASSEMBLY VIDEO AVAILABLE: Follow along step-by-step with our video walk through by scanning the QR code with your mobile device or by following the product link: vivo-us.com/products/desk-e3ctb...
- Page 2 7AM - 7PM Monday-Friday Give us a Call: Chat Us: Email Us: 309-278-5303 www.vivo-us.com help@vivo-us.com We’re Here for You! Our customer-minded support team is here for YOU, Monday-Friday 7am-7pm CST. We offer immediate assistance with rapid response times from customer service agents and product techncians to...
-
Page 3: Electrical Warning
Returns | Product Didn’t Work Out? We offer a hassle-free 30 day return on all products. Contact customer support at 309-278-5303 or help@vivo-us.com. Please note: For items ordered in error or no longer needed, the return shipping charges will be at the buyer’s expense. -
Page 4: Package Contents
TOOLS NEEDED: DIFFICULTY LEVEL Phillips Screwdriver Level PACKAGE CONTENTS Please consult the parts list below and ensure you have everything you need to assemble your product. If parts are missing or damaged, please contact us. A (x1) B (x1) C (x1) D (x1) E (x1) Left Desktop... -
Page 5: Assembly Steps
ASSEMBLY STEPS STEP 1: Assemble Left Leg Connect Left Crossbar (D) to Left Leg (L) using M6x8mm Screws (S-A) and 5mm Allen Wrench (T-A). Attach Side Bracket (I) to Left Leg (L) using M6x8mm Screwns (S-A) and 5mm Allen Wrench (T-A). D (x1) L (x1) S-A (x4) - Page 6 STEP 2: Assemble Right Leg Attach Angled Right Crossbar (G) to Right Leg (J) using M6x8mm Screws (S-A) and 5mm Allen Wrench (T-A). Attach Side Bracket (I) to Right Leg (J) using M6x8mm Screws (S-A) and 5mm Allen Wrench (T-A). J (x1) G (x1) S-A (x4)
- Page 7 STEP 3: Install Feet & Connect Motorized Leg Attach Foot (P) to Right and Left Leg (J, L) using M6x35mm Screws (S-B) and 5mm Allen Wrench (T-A). Connect Short Left Crossbar (E) and Right Crossbar (F) to Motorized Leg (K) using M6x8mm Screws (S-A) and 5mm Allen Wrench (T-A).
-
Page 8: Assembly Options
- Assembly Options - This desk can be assembled with a left or right side extension. Please select an option and proceed with assembly Option A | Left Side Extension Desk frame will extend out to left side, with a short right side Pg 7-10 Option B | Right Side Extension Desk frame will extend out to right... - Page 9 ASSEMBLY OPTION A | Left Side Extension A-STEP 4: Install Anti-Vibration Pads Affix Anti-Vibration Pads (T) to desk frame, Short Connector Bracket (M), and Long Connector Bracket (N). Connector Brackets will be installed in next step. M (x1) T (x23) N (x1) Short Connector Bracket Anti-Vibration Pads...
- Page 10 A-STEP 5: Assemble Desktop Connect Left, Middle, and Right Desktop (A, B, C) pieces together using Desktop Connectors (O), M5x16mm Screws (S-C) and a Phillips screwdriver. A (x1) B (x1) C (x1) O (x4) S-C (x16) Left Desktop Middle Desktop Right Desktop Desktop M5x16mm...
- Page 11 A-STEP 6: Install Connector Brackets Begin connecting frame to desktop by placing assemblies on desktop as shown below. Connect Angled Right Crossbar (G) and Right Crossbar (F) to Short Connector Bracket (M), M6x8mm Screws (S-A), and 5mm Allen Wrench (T-A). Connect Long Connector Bracket (N) to Short Left Crossbar (E) and Left Crossbar (D), using M6x8mm Screws (S-A), and 5mm Allen Wrench (T-A).
- Page 12 A-STEP 7: Secure Frame & Desktop Secure to desktop with M5x16mm Screws (S-C) and a Phillips screwdriver, using the screw locations shown below. Connect Control Panel (Q) to desktop using M5x16mm Screws (S-C) and a Phillips screwdriver. Q (x1) S-C (x25) Control Panel M5x16mm Screw...
- Page 13 A-STEP 8: Install Sync Rod Loosen the coupling nut on Sync Rods (H) and insert hex shaft into Left and Right Leg (L, J), making sure the metal retaining ring makes contact with the leg. Ensure that all three legs are the same height.
- Page 14 A-STEP 9: Connect Power Cables Connect Power Cord (R) and cable from Motorized Leg (K) to Control Panel (Q). If needed, use Extension Cable (S) for cable from Motorized Leg (K) to extend length. Use Cable Clips (U) to secure cables to desktop. R (x1) S (x1) U (x2)
- Page 15 ASSEMBLY OPTION B | Right Side Extension B-STEP 4: Install Anti-Vibration Pads Affix Anti-Vibration Pads (T) to desk frame, Short Connector Bracket (M), and Long Connector Bracket (N). Connector Brackets will be installed in next step. T (x23) M (x1) N (x1) Anti-Vibration Short Connector Bracket...
- Page 16 B-STEP 5: Assemble Desktop Connect Left, Middle, and Right Desktop (A, B, C) pieces together using Desktop Connectors (O), M5x16mm Screws (S-C) and a Phillips screwdriver. S-C (x16) A (x1) B (x1) C (x1) O (x4) M5x16mm Left Desktop Middle Desktop Right Desktop Desktop Screw...
- Page 17 B-STEP 6: Install Connector Brackets Begin connecting frame to desktop by placing assemblies on desktop as shown below. Connect Angled Right Crossbar (G) and Right Crossbar (F) to Long Connector Bracket (N), M6x8mm Screws (S-A), and 5mm Allen Wrench (T-A). Connect Short Left Crossbar (E) and Left Crossbar (D) to Short Connector Bracket (M), M6x8mm Screws (S-A), and 5mm Allen Wrench (T-A).
- Page 18 B-STEP 7: Secure Frame & Desktop Secure to desktop with M5x16mm Screws (S-C) and a drill, using the screw locations shown below. Connect Control Panel (Q) to desktop using M5x16mm Screws (S-C) and a drill. S-C (x25) Q (x1) M5x16mm Screw Control Panel...
- Page 19 B-STEP 8: Install Sync Rod Loosen the coupling nut on Sync Rods (H) and insert hex shaft into Left and Right Leg (L, J), making sure the metal retaining ring makes contact with the leg. Ensure that all three legs are the same height.
- Page 20 B-STEP 9: Connect Power Cables Connect Power Cord (R) and cable from Motorized Leg (K) to Control Panel (Q). If needed, use Extension Cable (S) for cable from Motorized Leg (K) to extend length. Use Cable Clips (U) to secure cables to desktop. R (x1) S (x1) U (x2)
-
Page 21: Troubleshooting
CONTROLLER - USER MANUAL Memory Presets Press any number and the desk will return to the programmed height. See Programing Memory Presets to program presets. Arrow Keys Press and hold the UP arrow for the desk to begin raising. Release when desk reaches desired height. - Page 22 WHO WE ARE VIVO is more than a brand of ergonomic office furniture. We are a team of creative and innovative indivuduals working together to offer high quality, affordable ergonomic solutions. We think and work outside of the box to serve...
-
Page 23: Need Assistance
Call Us: 309-278-5303 Average Resolution Time: 5m 4s Chat Us: www.vivo-us.com Average Resolution Time: < 15m Email Us: help@vivo-us.com Average Resolution Time: 1HR 8M 23% within < 15m 38% within <... - Page 24 LOVE YOUR NEW VIVO SETUP? Ready to share that new amazing setup? Want to brag about that amazing new ergonomic solution? Tag us in your photo! VIVO-us @vivo_us FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM LAST UPDATED: 11/24/2023 REV3.1LF...
