Linear Technology DC1516A Manual page 6

DEMO MANUAL DC1516A
PARTS LIST
ITEM QTY REFERENCE
16 1 R1
17 1 R10
18 2 R11, R23
19 1 R13
20 1 R15
21 1 R16
22 1 R18
23 3 R2, R12, R24
24 2 R4, R5
25 2 R6, R8
26 1 RS1
27 1 U1
Additional Circuit Components
1 0 C3
2 0 C4, C11
3 0 CIN3
4 0 COUT5, COUT6
5 0 D2
6 0 Q4, Q3
7 1 Q5
8 2 R20
9 1 R22
10 0 R14, R19, R21, R25
Hardware
1 10 E1 - E10
2 4 J1, J2, J3, J4
3 2 J6, J5
4 2 JP1 & JP2 (1 & 2)
5 2 JP1, JP2
6 4 MH1 - MH4
6
PART DESCRIPTION
RES 100k 1/16W 5% 0603
RES 15k 1/16W 1% 0603
RES 10k 1/16W 1% 0603
RES 2.2Ω 1/16W 5% 0603
RES 33.2k 1/16W 5% 0603
RES 0Ω 1/16W 0603
RES 137k 1/16W 1% 0603
RES 0Ω 1/16W 0603
RES 10Ω 1/16W 5% 0603
RES 10Ω 1/16W 5% 0603
RES SENSE 0.0025Ω 2512
IC TC3833EFE TSSOP20FE-CB
CAP 0805
CAP 0603
CAP 1210
CAP 1206
DIODE SMA
MOSFET POWER N-CH LFPAK
MOSFET N-CH DPAK-TO252AA
RES 10k 1/16W 1% 0603
RES 0.0Ω 2% 2010
RES 0603
TESTPOINT TURRET 094"
JACK BANANA
CONN BNC 5 PINS
SHUNT .079" CENTER
JMP 3-PIN 1 ROW 0.079CC
STAND-OFF NYLON 0.50"
MANUFACTURER/PART NUMBER
VISHAY CRCW0603100KJKEA
VISHAY CRCW060315K0FKEA
VISHAY CRCW060310K0FKEA
VISHAY CRCW06032R20JNEA
VISHAY CRCW060333K2JNEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW0603137KFKEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW060310R0JNEA
VISHAY CRCW060310R0JNEA
TEPRO TMF12R0025F150L
LINEAR TECH LTC3833EFE
OPT
OPT
OPT
OPT
OPT
OPT
VISHAY SILICONIX SUD50N03-12P
VISHAY CRCW060310K0FKEA
IRC LR2010-01-R010-G
OPT
MILL-MAX 2501-2-00-80-00-00-07-0
KEYSTONE 575-4
CONNEX 112404
SAMTEC 2SN-BK-G
SAMTEC TMM-103-02-L-S
KEYSTONE 8833 (SNAP-ON)
