Linear Technology DC1516A Manual page 5

PARTS LIST
ITEM QTY REFERENCE
24 2 R4, R5
25 1 R7
26 2 R9, R17
27 1 RS1
28 1 U1
Additional Circuit Components
1 0 R6, R8, R16, R14, R19, R21, R25
2 0 C3
3 0 C4, C11
4 0 CIN3
5 0 COUT5, COUT6
6 0 D2
7 0 Q4, Q3
8 1 Q5
9 2 R20
10 1 R22
Hardware
1 10 E1 - E10
2 4 J1, J2, J3, J4
3 2 J6, J5
4 2 JP1 & JP2 (1 & 2)
5 2 JP1, JP2
6 4 MH1 - MH4
Demo Circuit 1516A-B (R
ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C8
2 1 C10
3 1 C2
4 1 C5
5 1 C6
6 1 C7
7 1 C9
8 2 CIN1, CIN2
9 2 CIN4, CIN5
10 2 COUT1, COUT2
11 2 COUT4, COUT3
12 1 D1
13 1 L1
14 1 Q1
15 1 Q2
PART DESCRIPTION
RES 10Ω 1/16W % 0603
RES CHIP 13.3k 1/16W 1% 0603
RES 0Ω 1/16W 0603
RES 0.000Ω 2512
IC LTC3833EFETSSOP20FE-CB
RES 0603
CAP 0805
CAP 0603
CAP 1210
CAP 1206
DIODE SMA
MOSFET POWER N-CH LFPAK
MOSFET N-CH DPAK-TO252AA
RES 10k 1/16W 1% 0603
RES 0.01Ω 2% 2010
TESTPOINT TURRET 094"
JACK BANANA
CONN BNC 5 PINS
SHUNT .079" CENTER
JMP 3-PIN 1 ROW 0.079CC
STAND-OFF NYLON 0.50"
)
SENSE
PART DESCRIPTION
CAP X7R 0.1μF 25V 20% 0603
CAP X7R 1μF 16V 10% 0603
CAP X7R 1000pF 16V 10% 0603
CAP X5R 4.7μF 16V 10% 0805
CAP C0G 68pF 50V 10% 0603
CAP X7R 0.01μF 16V 10% 0603
CAP C0G 470pF 50V 10% 0603
CAP X7R 10μF 25V 20% 1210
CAP SVPD 47μF 35V 20%
CAP X5R 100μF 6.3V 20% 1206
CAP POSCAP 330μF 2.5V 20% 7343
DIODE SCHOTTKY 30V SOD323
IND PWR 0.68μH L-7443330068
MOSFET POWER N-CH LFPAK
MOSFET POWER N-CH LFPAK
DEMO MANUAL DC1516A
MANUFACTURER/PART NUMBER
VISHAY CRCW060310R0JNEA
VISHAY CRCW060313K3FKEA
VISHAY CRCW06030000Z0EA
TEPRO RN5326
LINEAR TECH LTC3833EFE
OPT
OPT
OPT
OPT
OPT
OPT
OPT
VISHAY SILICONIX SUD50N03-12P
VISHAY CRCW060310K0FKEA
IRC LR2010-01-R010-G
MILL-MAX 2501-2-00-80-00-00-07-0
KEYSTONE 575-4
CONNEX 112404
SAMTEC 2SN-BK-G
SAMTEC TMM-103-02-L-S
KEYSTONE 8833 (SNAP-ON)
MANUFACTURER/PART NUMBER
AVX 06033C104MAT2A
AVX 0603YC105KAT2A
AVX 0603YC102KAT2A
KEMET C0805C475K4PAC
AVX 06035A680KAT2A
AVX 0603YC103KAT2A
AVX 06035A471KAT2A
TDK C3225X7R1E106M
SANYO 35SVPD47M
MURATA GRM31CR60J107ME39L
SANYO 2R5TPE330M9
CENTRAL SEMI CMDSH3-TR
WURTH 7443330068
RENESAS RJK0305DPB
RENESAS RJK0330DPB
dc1516af
5
