71" Cable Management Desk Organizer
Instruction Manual
SKU: DESK-SKIRT-71
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-skirt-60
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-SKIRT-71
Summary of Contents for Vivo DESK-SKIRT-71
- Page 1 71” Cable Management Desk Organizer Instruction Manual SKU: DESK-SKIRT-71 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-skirt-60 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 ASSEMBLY STEPS STEP 1 Connect the centers of T Joiners (C) to the ends of the Middle Bars (F). To distinquish Middle Bars from Upper/Lower Bars, note that the Middle Bars are shorter. Connect the Upper/Lower Bars (E) to the sides of the T Joiners (C). Then connect Joiners (G) and Side Bars (B) to open sides of Joiners to complete the frame assembly.
- Page 4 STEP 2 Open the flap and straps of Panel (A) and insert the frame, making sure the frame is fully inserted and the material is tightly stretched around it. Fasten Straps (A1) on inside of Panel (A) to secure the frame.
- Page 5 STEP 3 Place the Plastic Mounting Clips (D) in the center of each exposed portion of the steel bars. STEP 4 Center the assembled panel under the desktop and use a pencil to mark the locations of Plastic Mounting Clips (D). NOTE: Desktop must be at least 1” thick to prevent screws from poking out through the top and damaging the surface.
- Page 6 STEP 5 Drill pilot holes using a 1/8” (3mm) bit. Mount the assembled panel to the underside of the desk using (W-A) as shown into Plastic Mounting Clips (D). ST4.8x20mm Screws STEP 6 Route and organize the cables and secure them using the flap on Panel (A).
- Page 7 [ THIS PAGE INTENTIONALLY LEFT BLANK ]...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
